| 1 |
Circuit 15, status |
12D |
| 10 |
Instrument cluster message, request |
18E |
| 2 |
Alternator, signal |
2G |
| 3 |
Engine running, signal |
6E |
| 3 |
Engine running, signal |
11E |
| 4 |
Drivetrain operational, signal |
5E |
| 4 |
Drivetrain operational, signal |
10E |
| 5 |
Alternator operating rate, signal |
5E |
| 5 |
Alternator operating rate, signal |
10E |
| 6 |
Battery sensor, signal |
13E |
| 7 |
Consumer shutoff, request |
8E |
| 7 |
Consumer shutoff, request |
39F |
| 7 |
Consumer shutoff, request |
26D |
| 7 |
Consumer shutoff, request |
31D |
| 7 |
Consumer shutoff, request |
32G |
| 7 |
Consumer shutoff, request |
39D |
| 7 |
Consumer shutoff, request |
20D |
| 7 |
Consumer shutoff, request |
8C |
| 7 |
Consumer shutoff, request |
35G |
| 7 |
Consumer shutoff, request |
37H |
| 7 |
Consumer shutoff, request |
37D |
| 8 |
No-load current shutoff, signal |
20E |
| 8 |
No-load current shutoff, signal |
26E |
| 8 |
No-load current shutoff, signal |
31E |
| 8 |
No-load current shutoff, signal |
34D |
| 8 |
No-load current shutoff, signal |
37E |
| 8 |
No-load current shutoff, signal |
39E |
| 8 |
No-load current shutoff, signal |
22G |
| 8 |
No-load current shutoff, signal |
25G |
| 8 |
No-load current shutoff, signal |
27G |
| 8 |
No-load current shutoff, signal |
30G |
| 8 |
No-load current shutoff, signal |
32F |
| 8 |
No-load current shutoff, signal |
35F |
| 8 |
No-load current shutoff, signal |
37G |
| 8 |
No-load current shutoff, signal |
39F |
| 8 |
No-load current shutoff, signal |
18D |
| 8 |
No-load current shutoff, signal |
10J |
| 8 |
No-load current shutoff, signal |
7J |
| 8 |
No-load current shutoff, signal |
20H |
| 8 |
No-load current shutoff, signal |
4G |
| 8 |
No-load current shutoff, signal |
12C |
| 8 |
No-load current shutoff, signal |
16H |
| 8 |
No-load current shutoff, signal |
12H |
| 8 |
No-load current shutoff, signal |
16G |
| 8 |
No-load current shutoff, signal |
9E |
| 8 |
No-load current shutoff, signal |
14H |
| 8 |
No-load current shutoff, signal |
8C |
| 9 |
Quiescent current cutout relay, actuation |
10C |
| A1 |
Instrument cluster |
17C |
| A1p13 |
Multifunction display |
18B |
| A2 |
Radio |
23B |
| A2/56 |
Radio with auto pilot system |
26B |
| A40/3 |
COMAND control unit |
28B |
| A6n1 |
Stationary heater control unit |
31B |
| A76 |
Left front reversible emergency tensioning retractor |
7J |
| A76/1 |
Right front reversible emergency tensioning retractor |
7J |
| B84/3 |
Backup camera |
17G |
| B95 |
Battery sensor |
15B |
| CAN B |
Interior CAN |
9F |
| CAN B |
Interior CAN |
22F |
| CAN B |
Interior CAN |
12D |
| CAN B |
Interior CAN |
29F |
| CAN B |
Interior CAN |
37F |
| CAN E |
Chassis CAN |
5E |
| CAN E |
Chassis CAN |
13G |
| CAN E |
Chassis CAN |
8H |
| CAN E |
Chassis CAN |
7D |
| CAN E1 |
Chassis CAN 1 |
5F |
| CAN E1 |
Chassis CAN 1 |
8H |
| CAN E1 |
Chassis CAN 1 |
7D |
| CAN E2 |
Chassis CAN 2 |
13G |
| Code 218 |
Backup camera |
26G |
| Code 218 |
Backup camera |
16F |
| Code 220 |
PARKTRONIC |
13J |
| Code 228 |
Stationary heater |
30A |
| Code 235 |
Active Park Assist |
13J |
| Code 275 |
Memory package, electrically adjustable front seats |
32A |
| Code 414 |
Electric glass tilting/sliding roof |
38A |
| Code 432 |
Left and right front dynamic multicontour seats |
36H |
| Code 432 |
Left and right front dynamic multicontour seats |
35A |
| Code 443 |
Steering wheel heater |
31G |
| Code 475 |
Tire pressure monitor |
15J |
| Code 489 |
AIRMATIC (air suspension with continuously adjustable damping) |
10J |
| Code 494 |
USA version |
21G |
| Code 498 |
Japan version |
26H |
| Code 510 |
Audio 20 with CD changer |
22A |
| Code 511 |
Audio 50 APS incl. DVD changer |
25A |
| Code 512 |
COMAND APS with DVD changer |
27A |
| Code 523 |
Audio 20 radio |
22A |
| Code 525 |
Audio 50 APS radio (CD) |
25A |
| Code 526 |
COMAND with single DVD drive (without navigation) |
27A |
| Code 527 |
COMAND APS (with navigation) |
27A |
| Code 528 |
COMAND with DVD changer |
27B |
| Code 872 |
Left and right rear seat heaters |
28G |
| Code 881 |
Trunk lid/liftgate control |
33G |
| Code 889 |
KEYLESS-GO |
23G |
| F32k2 |
Quiescent current cutout relay |
9B |
| G2 |
Alternator |
2C |
| LIN B7 |
On-board electrical system LIN |
14E |
| LIN C1 |
Drive train LIN |
2E |
| M40/1 |
Active multicontour seat pneumatic pump |
37J |
| N10/1 |
Front SAM control unit with fuse and relay module |
7E |
| N10/2 |
Rear SAM control unit with fuse and relay module |
12E |
| N110 |
Weight Sensing System (WSS) control unit |
22H |
| N121 |
Trunk lid control unit |
34H |
| N121/1 |
Tailgate control unit |
34H |
| N2/10 |
Supplemental restraint system control unit |
9J |
| N22/7 |
Automatic air conditioning control and operating unit |
38G |
| N25/6 |
Rear seat heaters control unit |
29H |
| N25/7 |
Steering wheel heater control unit |
32H |
| N3/10 |
ME-SFI [ME] control unit |
5H |
| N3/9 |
CDI control unit |
2H |
| N32/1 |
Driver seat control unit |
33B |
| N32/19 |
Left front active multicontour seat control unit |
36B |
| N32/2 |
Front passenger seat control unit |
33B |
| N32/22 |
Right front active multicontour seat control unit |
36B |
| N51/3 |
AIRMATIC control unit |
11J |
| N62 |
Parking system control unit |
14J |
| N66/2 |
Backup camera control unit |
27H |
| N69/1 |
Left front door control unit |
20A |
| N69/2 |
Right front door control unit |
20A |
| N69/3 |
Left rear door control unit |
19H |
| N69/4 |
Right rear door control unit |
19H |
| N69/5 |
KEYLESS-GO control unit |
24H |
| N70 |
Overhead control panel control unit |
39A |
| N73 |
Electronic ignition switch control unit |
12A |
| N80 |
Steering column module control unit |
7A |
| N88 |
Tire pressure monitor control unit |
17J |
| U57 |
Valid for model 218.9 |
16F |
| U57 |
Valid for model 218.9 |
33H |
| U74 |
Valid for diesel engines |
1H |
| U75 |
Valid for gasoline engines |
4H |
