Remove/install front differential mount on rear axle carrier - AR35.10-P-0051LW

Model 205

Fig 1: Identifying Front Differential Mount Remove/Install Components

Courtesy of MERCEDES-BENZ USA

	Notes on self-locking nuts and bolts		AH00.00-N-0001-01A
	Notes on repair work on suspension components		AH00.00-P-0100-01A
	Remove/install
1	Remove rear muffler	Model 205 with engine 177	AR49.10-P-4952MNA
		Model 205 with engine 274, 276	AR49.10-P-4952LW
		Model 205 with engine 651	AR49.10-P-7100LWB
2	Lower rear axle carrier (4) at front		AR35.10-P-0015LW
3	Detach rear axle differential (50) from differential mount (8)	The spacer rings have to be installed again.
		Rear axle differential to front adapter	*BA35.10-P-1005-01H
4	Detach differential mount (8) from rear axle carrier (4) and remove differential mount (8)	Screw/bolt, adapter to front transverse bridge	*BA35.10-P-1004-01H
5	Install in the reverse order

REAR AXLE CARRIER

Number	Designation		Model 205
BA35.10-P-1004-01H	Screw/bolt, adapter to front transverse bridge	Nm	150

REAR AXLE CARRIER

Number	Designation			Model 205
BA35.10-P-1005-01H	Rear axle differential to front adapter	Rear axle differential (steel)	Nm	65
		Rear axle differential (aluminum)	Nm	40
