| A0 |
Use of wiring diagrams |
64L |
| A26/17 |
Head unit |
45L |
| A76 |
Left front reversible emergency tensioning retractor |
3A |
| A76/1 |
Right front reversible emergency tensioning retractor |
3L |
| Code 222 |
Electrically adjustable right front seat |
16A |
| Code 301 |
Smoker's package |
7F |
| Code 386 |
Comfort telephony |
51F |
| Code 876 |
Interior lights package |
21F |
| Code 877 |
Ambiance illumination |
31F |
| Code U25 |
Illuminated door sills |
12F |
| Code U25 |
Illuminated door sills |
56F |
| Code U63 |
Driving school package |
21F |
| E17/17 |
Left rear footwell lamp |
23L |
| E17/17 |
Left rear footwell lamp |
33L |
| E17/18 |
Right rear footwell lamp |
28L |
| E17/18 |
Right rear footwell lamp |
37L |
| E17/47 |
Left front illuminated door sill molding |
14L |
| E17/48 |
Right front illuminated door sill molding |
19L |
| E17/51 |
Left rear illuminated door sill molding |
58L |
| E17/52 |
Right rear illuminated door sill molding |
60L |
| N32/1 |
Driver seat control unit |
9A |
| N32/2 |
Front passenger seat control unit |
14A |
| R3 |
Front cigarette lighter with ashtray illumination |
9L |
| R3e1 |
Ashtray illumination |
8L |
| R3r1 |
Cigarette lighter heating element |
7L |
| S23/1 |
Front passenger seat partially electric seat adjustment switch |
49L |
| U12 |
Valid for left-hand drive vehicles |
12A |
| U13 |
Valid for right-hand drive vehicles |
7A |
| U2051 |
Valid for model 205.1 |
56F |
| U358 |
Valid without code (301) Smoker's package |
5F |
| W12/1 |
Right center console ground point |
27A |
| X18 |
Cockpit wiring harness and frame floor assembly electrical connector |
45H |
| X237/1 |
Mobile phone contact plate |
53L |
| X237/1x1 |
Mobile phone contact plate electrical connector 1 |
53H |
| X28/30 |
Front passenger airbag electrical connector |
48H |
| X58/1 |
Vehicle interior power outlet |
6L |
| X58/18 |
Right rear center console 12V socket |
41L |
| X6/4 |
Driver footwell lamp electrical connector |
25H |
| X6/4 |
Driver footwell lamp electrical connector |
34H |
| X6/5 |
Front passenger footwell lamp electrical connector |
29H |
| X6/5 |
Front passenger footwell lamp electrical connector |
38H |
| Z6/30 |
Circuit 31 connector sleeve |
15G |
| Z6/30 |
Circuit 31 connector sleeve |
27G |
| Z6/30 |
Circuit 31 connector sleeve |
36G |
| Z6/30 |
Circuit 31 connector sleeve |
53G |
| Z6/30 |
Circuit 31 connector sleeve |
59G |
| Z61/4z1 |
Right front seat circuit 31 connector sleeve |
50G |
