| A0 |
Use of wiring diagrams |
56L |
| B4/1 |
Fuel tank fuel level indicator fill level sensor, left |
15L |
| B4/2 |
Fuel tank fuel level indicator fill level sensor, right |
13L |
| B4/31 |
Fuel quality sensor |
20L |
| B4/7 |
Fuel pressure sensor |
18L |
| B4/7 |
Fuel pressure sensor |
10L |
| CAN C1 |
Drive train CAN |
40K |
| Code 933 |
Flexible Fuel Vehicle |
19D |
| Code U77 |
BLUETEC (SCR) diesel exhaust treatment |
34D |
| K40/5 |
Rear fuse and relay module |
3L |
| K40/5 |
Rear fuse and relay module |
31L |
| K40/5f442 |
Fuse 442 |
2L |
| K40/5f451 |
Fuse 451 |
33L |
| K40/8 |
Engine fuse and relay module |
25L |
| K40/8f101 |
Fuse 101 |
24L |
| M3 |
Fuel pump (FP) |
7L |
| N118 |
Fuel pump control unit |
4A |
| N118 |
Fuel pump control unit |
29A |
| N118 |
Fuel pump control unit |
45A |
| N118 |
Fuel pump control unit |
12A |
| N118 |
Fuel pump control unit |
20A |
| N118 |
Fuel pump control unit |
12A |
| N118/5 |
AdBlue® control unit |
36L |
| N3/10 |
ME-SFI [ME] control unit |
48L |
| N3/10 |
ME-SFI [ME] control unit |
53L |
| N3/9 |
CDI control unit |
44L |
| U1018 |
Valid for gasoline engine 276 |
46F |
| U161 |
Not valid for fuel tank (41.2 liters) |
14H |
| U2253 |
Not valid for model series 253 |
34D |
| U362 |
Valid for gasoline engine 274 |
47E |
| U39 |
Valid for gasoline engine 177 |
51E |
| U406 |
Valid for diesel engine 626 |
42F |
| U561 |
Valid for Delphi system |
42F |
| U562 |
Valid for Bosch system |
42E |
| U74 |
Valid for diesel engines |
16E |
| U74 |
Valid for diesel engines |
8F |
| U75 |
Valid for gasoline engines |
9E |
| U75 |
Valid for gasoline engines |
8E |
| W33/4 |
Fuel tank filler neck ground point |
3E |
| W6 |
Left wheel arch trunk ground point |
22H |
| W76 |
Fuel pump ground point |
3E |
| X101/3 |
Left rear frame floor assembly/underfloor electrical connector |
19H |
| X18/3 |
Vehicle interior/fuel tank electrical connector |
3H |
| X25/7 |
Engine compartment/frame floor assembly electrical connector |
23H |
| X26 |
Interior and engine wiring harness electrical connector |
17H |
| X26/10 |
Vehicle interior/engine electrical connector |
52H |
| X30/21 |
Drive train CAN (CAN C1) potential distributor electrical connector |
40L |
| Z6/29z1 |
Connector sleeve, ground connection for fuel pump |
12E |
| Z6/30 |
Circuit 31 connector sleeve |
21E |
| Z7/48z1 |
Circuit 87/2 connector sleeve |
23E |
