| 1 |
Central locking, status |
10F |
| 2 |
Circuit 15, status |
10F |
| 3 |
Door rotary tumbler switch, status |
10F |
| 3 |
Door rotary tumbler switch, status |
15D |
| 3 |
Door rotary tumbler switch, status |
15E |
| 3 |
Door rotary tumbler switch, status |
15H |
| 3 |
Door rotary tumbler switch, status |
15G |
| 4 |
Instrument illumination brightness control, status |
35B |
| 4 |
Instrument illumination brightness control, status |
11F |
| 4 |
Instrument illumination brightness control, status |
15F |
| 5 |
Circuit 58d, status |
5E |
| 5 |
Circuit 58d, status |
34L |
| 5 |
Circuit 58d, status |
44K |
| 5 |
Circuit 58d, status |
44J |
| 5 |
Circuit 58d, status |
41D |
| 5 |
Circuit 58d, status |
33D |
| 5 |
Circuit 58d, status |
33E |
| 5 |
Circuit 58d, status |
10B |
| 5 |
Circuit 58d, status |
15L |
| 5 |
Circuit 58d, status |
17J |
| 5 |
Circuit 58d, status |
19H |
| 5 |
Circuit 58d, status |
37H |
| 5 |
Circuit 58d, status |
41H |
| 5 |
Circuit 58d, status |
30E |
| 5 |
Circuit 58d, status |
23D |
| 5 |
Circuit 58d, status |
12F |
| 5 |
Circuit 58d, status |
9J |
| 5 |
Circuit 58d, status |
8L |
| 5 |
Circuit 58d, status |
3J |
| 5 |
Circuit 58d, status |
4G |
| 5 |
Circuit 58d, status |
3C |
| 5 |
Circuit 58d, status |
14C |
| 5 |
Circuit 58d, status |
|
| 6 |
Button/symbol illumination, actuation |
34H |
| 6 |
Button/symbol illumination, actuation |
38H |
| 6 |
Button/symbol illumination, actuation |
38K |
| 6 |
Button/symbol illumination, actuation |
46H |
| 6 |
Button/symbol illumination, actuation |
46F |
| 6 |
Button/symbol illumination, actuation |
37E |
| 6 |
Button/symbol illumination, actuation |
43B |
| 6 |
Button/symbol illumination, actuation |
45C |
| 6 |
Button/symbol illumination, actuation |
34B |
| 6 |
Button/symbol illumination, actuation |
33C |
| 6 |
Button/symbol illumination, actuation |
36B |
| 6 |
Button/symbol illumination, actuation |
28D |
| 6 |
Button/symbol illumination, actuation |
28B |
| 6 |
Button/symbol illumination, actuation |
21D |
| 6 |
Button/symbol illumination, actuation |
21B |
| 6 |
Button/symbol illumination, actuation |
22L |
| 6 |
Button/symbol illumination, actuation |
24J |
| 6 |
Button/symbol illumination, actuation |
22J |
| 6 |
Button/symbol illumination, actuation |
21H |
| 6 |
Button/symbol illumination, actuation |
6C |
| 6 |
Button/symbol illumination, actuation |
7J |
| 6 |
Button/symbol illumination, actuation |
38C |
| 6 |
Button/symbol illumination, actuation |
12J |
| 6 |
Button/symbol illumination, actuation |
15A |
| A1 |
Instrument cluster |
8E |
| A26/17 |
Head unit |
2E |
| A40/8 |
Audio/COMAND display |
2A |
| A40/9 |
Audio/COMAND control panel |
2J |
| A67 |
Inside rearview mirror |
46C |
| A67e3 |
Ambient lamp |
47C |
| A70/1 |
Analog clock |
32D |
| CAN A |
Telematics CAN |
2H |
| CAN A |
Telematics CAN |
2D |
| CAN B |
Interior CAN |
17H |
| CAN B |
Interior CAN |
37G |
| CAN B |
Interior CAN |
18E |
| CAN B |
Interior CAN |
24E |
| CAN B |
Interior CAN |
18E |
| CAN B |
Interior CAN |
33F |
| CAN B |
Interior CAN |
26F |
| CAN B |
Interior CAN |
18F |
| CAN B |
Interior CAN |
19G |
| CAN B |
Interior CAN |
28G |
| CAN B |
Interior CAN |
26G |
| CAN B |
Interior CAN |
18G |
| CAN B |
Interior CAN |
33G |
| CAN HMI |
User interface CAN |
5F |
| CAN HMI |
User interface CAN |
11F |
| CAN PER |
Peripherals CAN |
14C |
| Code 221 |
Fully electric driver seat adjustment without memory without electric head restraint adjustment |
15J |
| Code 222 |
Electrically adjustable right front seat |
31K |
| Code 235 |
Active Park Assist |
31E |
| Code 238 |
Active Lane Keeping Assist |
31E |
| Code 242 |
All-electric front passenger seat with memory (right) |
31K |
| Code 266 |
DISTRONIC PLUS TRANSVERSE SUPPORT |
31E |
| Code 275 |
Memory package |
15H |
| Code 301 |
Smoker's package |
31C |
| Code 463 |
Head-up display |
31F |
| Code 501 |
360 degree camera |
31F |
| Code 581 |
THERMOTRONIC automatic air conditioning |
44J |
| Code 876 |
Interior lights package |
21G |
| Code 876 |
Interior lights package |
18C |
| Code 876 |
Interior lights package |
33H |
| Code 876 |
Interior lights package |
37D |
| Code 876 |
Interior lights package |
35A |
| Code 876 |
Interior lights package |
39B |
| Code 876 |
Interior lights package |
25B |
| Code 881 |
Remote trunk closing |
25H |
| Code 881 |
Remote trunk closing |
46G |
| Code 890 |
EASY-PACK liftgate |
25J |
| Code 890 |
EASY-PACK liftgate |
46H |
| E13/3 |
Stowage compartment illumination |
39C |
| E17/11 |
Left front door door handle illumination |
21H |
| E17/12 |
Right front door door handle illumination |
33J |
| E17/13 |
Left rear door door handle illumination |
20D |
| E17/14 |
Right rear door door handle illumination |
26D |
| E17/15 |
Right front footwell lamp |
37E |
| E17/16 |
Left front footwell lamp |
37E |
| E17/17 |
Left rear footwell lamp |
37E |
| E17/18 |
Right rear footwell lamp |
37E |
| E20/18 |
Front center console cup holder ambiance illumination |
36B |
| Flex E |
Chassis FlexRay |
11C |
| Flex E |
Chassis FlexRay |
11G |
| LIN 1 |
Instrument panel LIN |
33D |
| LIN 1 |
Instrument panel LIN |
34E |
| LIN A2 |
Telephone keypad LIN |
4E |
| LIN B13 |
Roof LIN |
39D |
| LIN B5 |
Left front door LIN |
16L |
| LIN B5 |
Left front door LIN |
18K |
| LIN B6 |
Right front door LIN |
34K |
| LIN B8-3 |
AC operation LIN |
43K |
| LIN B8-3 |
AC operation LIN |
43J |
| LIN E1 |
Steering LIN |
8K |
| N10/6 |
Front SAM control unit |
35C |
| N10/8 |
Rear SAM control unit |
44F |
| N128 |
Electric parking brake control unit |
14A |
| N135 |
Steering wheel electronics |
7K |
| N22/1 |
Climate control control unit |
41J |
| N22/4 |
Rear air conditioning operating unit |
45J |
| N30/4 |
Electronic Stability Program control unit |
9B |
| N58/1 |
Climate control operating unit |
46K |
| N69/1 |
Left front door control unit |
19J |
| N69/2 |
Right front door control unit |
36J |
| N69/3 |
Left rear door control unit |
23B |
| N69/4 |
Right rear door control unit |
30B |
| N70 |
Overhead control panel control unit |
42B |
| N70e6 |
Left mounting console incident illumination |
41B |
| N70e7 |
Right mounting console incident illumination |
44B |
| N70e8 |
Eyeglass box illumination |
43B |
| N72/4 |
Left lower control panel |
6E |
| N72/5 |
Right lower control panel |
6F |
| N73 |
Electronic ignition switch control unit |
13E |
| N80 |
Steering column module control unit |
10K |
| R3 |
Front cigarette lighter with ashtray illumination |
33C |
| S1 |
Exterior lights switch |
33A |
| S110 |
Left multifunction steering wheel button group |
5H |
| S111 |
Right multifunction steering wheel button group |
6H |
| S15/1 |
Trunk lid release button |
23L |
| S15/3 |
Driver trunk lid/liftgate control button |
25L |
| S16/13 |
DIRECT SELECT lever |
12H |
| S1r1 |
Instrument illumination brightness control |
32A |
| S20 |
Driver-side power window and outside mirror adjustment switch group |
13J |
| S21/2 |
Passenger-side power window switch |
39H |
| S21/3 |
Left rear power window switch |
20C |
| S21/4 |
Right rear power window switch |
26C |
| S22 |
Left front seat adjustment switch group |
16J |
| S23 |
Right front seat adjustment switch group |
32K |
| S6/1 |
Driver-side instrument panel button group |
32E |
| S62/26 |
Trunk lid/liftgate control button |
46J |
| S76/15 |
Electric parking brake switch |
5C |
| S76/15 |
Electric parking brake switch |
16A |
| S85/5 |
Left front door central locking interior switch |
23H |
| S85/6 |
Right front door central locking interior switch |
39K |
| S88/10 |
Trunk lid emergency opening switch |
47F |
| U1 |
Valid for USA |
46E |
| U1253 |
Valid for model 253 |
26A |
| U1253 |
Valid for model 253 |
20A |
| U1253 |
Valid for model 253 |
46J |
| U1253 |
Valid for model 253 |
25K |
| U1253 |
Valid for model 253 |
18C |
| U1253 |
Valid for model 253 |
25C |
| U165 |
Valid for AMG |
13A |
| U2050 |
Valid for model 205.0 |
46E |
| U2050 |
Valid for model 205.0 |
25H |
| U2050 |
Valid for model 205.0 |
46H |
| U2050 |
Valid for model 205.0 |
26A |
| U2050 |
Valid for model 205.0 |
20A |
| U2050 |
Valid for model 205.0 |
18C |
| U2050 |
Valid for model 205.0 |
25C |
| U2051 |
Valid for model 205.1 |
25J |
| U2051 |
Valid for model 205.1 |
46H |
| U2051 |
Valid for model 205.1 |
26B |
| U2051 |
Valid for model 205.1 |
20B |
| U2051 |
Valid for model 205.1 |
18C |
| U2051 |
Valid for model 205.1 |
25C |
| U2051 |
Valid for model 205.1 |
46E |
| U2052 |
Valid for model 205.2 |
25J |
| U2052 |
Valid for model 205.2 |
46H |
| U2052 |
Valid for model 205.2 |
26B |
| U2052 |
Valid for model 205.2 |
20B |
| U2052 |
Valid for model 205.2 |
18D |
| U2052 |
Valid for model 205.2 |
25D |
| U25 |
Valid for automatic transmission |
11H |
| U366 |
Valid without code (881) Trunk lid control |
22K |
| U986 |
Not valid for AMG |
5B |
