| 1 |
Ambiance illumination settings, status |
18J |
| 1 |
Ambiance illumination settings, status |
17F |
| 2 |
Central locking, status |
16G |
| 3 |
Circuit 15, status |
17G |
| 4 |
Door rotary tumbler switch, status |
18E |
| 4 |
Door rotary tumbler switch, status |
18F |
| 4 |
Door rotary tumbler switch, status |
15D |
| 4 |
Door rotary tumbler switch, status |
15E |
| 5 |
Ambience illumination, request |
12H |
| 5 |
Ambience illumination, request |
27E |
| 5 |
Ambience illumination, request |
27F |
| 5 |
Ambience illumination, request |
4D |
| 5 |
Ambience illumination, request |
5F |
| 6 |
Ambience illumination, actuation |
15H |
| 6 |
Ambience illumination, actuation |
18G |
| 6 |
Ambience illumination, actuation |
28D |
| 6 |
Ambience illumination, actuation |
28C |
| 6 |
Ambience illumination, actuation |
28B |
| 6 |
Ambience illumination, actuation |
4K |
| 6 |
Ambience illumination, actuation |
3H |
| 6 |
Ambience illumination, actuation |
4G |
| 6 |
Ambience illumination, actuation |
17C |
| 6 |
Ambience illumination, actuation |
28K |
| 6 |
Ambience illumination, actuation |
28H |
| 6 |
Ambience illumination, actuation |
28G |
| 6 |
Ambience illumination, actuation |
7B |
| 6 |
Ambience illumination, actuation |
6B |
| 6 |
Ambience illumination, actuation |
3C |
| 6 |
Ambience illumination, actuation |
13J |
| 7 |
Dusk setting, signal |
17C |
| A26/17 |
Head unit |
21J |
| B38/2 |
Rain/light sensor with additional functions |
20B |
| B38/2b2 |
Light sensor |
20C |
| CAN B |
Interior CAN |
16G |
| CAN B |
Interior CAN |
20E |
| CAN B |
Interior CAN |
20F |
| CAN B |
Interior CAN |
7F |
| CAN B |
Interior CAN |
7E |
| CAN B |
Interior CAN |
12F |
| CAN B |
Interior CAN |
12E |
| CAN HMI |
User interface CAN |
19K |
| E17/11 |
Left front door door handle illumination |
7A |
| E17/12 |
Right front door door handle illumination |
29C |
| E17/13 |
Left rear door door handle illumination |
3H |
| E17/14 |
Right rear door door handle illumination |
28G |
| E17/15 |
Right front footwell lamp |
15J |
| E17/16 |
Left front footwell lamp |
15J |
| E17/17 |
Left rear footwell lamp |
15J |
| E17/18 |
Right rear footwell lamp |
15K |
| E17/43 |
Left front door ambiance illumination |
8B |
| E17/44 |
Right front door ambiance illumination |
28E |
| E17/45 |
Left rear door ambiance illumination |
3J |
| E17/46 |
Right rear door ambiance illumination |
29H |
| E17/47 |
Left front illuminated door sill molding |
12J |
| E17/48 |
Right front illuminated door sill molding |
12K |
| E17/51 |
Left rear illuminated door sill molding |
12L |
| E17/52 |
Right rear illuminated door sill molding |
12L |
| E20/18 |
Front center console cup holder ambiance illumination |
19G |
| E23/1 |
Left front door stowage compartment illumination |
2B |
| E23/2 |
Right front door stowage compartment illumination |
28B |
| E23/3 |
Left rear door stowage compartment illumination |
3K |
| E23/4 |
Right rear door stowage compartment illumination |
29K |
| E43/18 |
Driver-side ambiance illumination |
16B |
| E43/19 |
Passenger-side interior ambiance illumination |
16B |
| E43/20 |
Passenger-side exterior ambiance illumination |
16C |
| LIN B13 |
Roof LIN |
13G |
| LIN B16 |
Rain and light sensor LIN |
18D |
| N10/6 |
Front SAM control unit |
16E |
| N69/1 |
Left front door control unit |
5B |
| N69/2 |
Right front door control unit |
26B |
| N69/3 |
Left rear door control unit |
5G |
| N69/4 |
Right rear door control unit |
26G |
| N70 |
Overhead control panel control unit |
10H |
| N73 |
Electronic ignition switch control unit |
16J |
| U1253 |
Valid for model 253 |
1G |
| U1253 |
Valid for model 253 |
25G |
| U2050 |
Valid for model 205.0 |
1G |
| U2050 |
Valid for model 205.0 |
25G |
| U2051 |
Valid for model 205.1 |
29K |
| U2051 |
Valid for model 205.1 |
1K |
| U2051 |
Valid for model 205.1 |
12K |
| U2051 |
Valid for model 205.1 |
1G |
| U2051 |
Valid for model 205.1 |
25G |
| U2052 |
Valid for model 205.2 |
1H |
| U2052 |
Valid for model 205.2 |
25H |
