| 1 |
Circuit 15, status |
19D |
| 2 |
Seat climate control switch group, status |
11K |
| 2 |
Seat climate control switch group, status |
17G |
| 2 |
Seat climate control switch group, status |
20G |
| 2 |
Seat climate control switch group, status |
25K |
| 3 |
Seat ventilation, request |
13D |
| 3 |
Seat ventilation, request |
13F |
| 3 |
Seat ventilation, request |
23D |
| 3 |
Seat ventilation, request |
23F |
| 3 |
Seat ventilation, request |
19J |
| 4 |
Seat ventilation motors, actuation |
8E |
| 4 |
Seat ventilation motors, actuation |
28E |
| 4 |
Seat ventilation motors, actuation |
29F |
| 4 |
Seat ventilation motors, actuation |
5F |
| 5 |
Seat ventilation, status |
15D |
| 5 |
Seat ventilation, status |
15F |
| 5 |
Seat ventilation, status |
21D |
| 5 |
Seat ventilation, status |
21F |
| 5 |
Seat ventilation, status |
9K |
| 5 |
Seat ventilation, status |
26K |
| 5 |
Seat ventilation, status |
22K |
| 5 |
Seat ventilation, status |
14K |
| 5 |
Seat ventilation, status |
19G |
| 6 |
Vehicle speed, signal |
19C |
| 6 |
Vehicle speed, signal |
6B |
| A1 |
Instrument cluster |
2B |
| CAN B |
Interior CAN |
13B |
| CAN B |
Interior CAN |
16K |
| CAN B |
Interior CAN |
14G |
| CAN B |
Interior CAN |
22G |
| CAN B |
Interior CAN |
20K |
| CAN HMI |
User interface CAN |
4B |
| Code 221 |
Fully electric driver seat adjustment without memory without electric head restraint adjustment |
9C |
| Code 222 |
Electrically adjustable right front seat |
20C |
| Code 242 |
All-electric front passenger seat with memory (right) |
20F |
| Code 275 |
Memory package |
9F |
| LIN B28 |
Heater LIN |
14D |
| LIN B28 |
Heater LIN |
22D |
| LIN B28 |
Heater LIN |
18H |
| LIN B5 |
Left front door LIN |
10K |
| LIN B6 |
Right front door LIN |
25K |
| M18/10 |
Left front backrest seat ventilation motors |
5E |
| M18/11 |
Right front seat cushion seat ventilation motors |
29E |
| M18/12 |
Right front backrest seat ventilation motors |
29E |
| M18/9 |
Left front seat cushion seat ventilation motors |
5E |
| N10/8 |
Rear SAM control unit |
18D |
| N25/17 |
Front seat heater control unit |
18L |
| N25/4 |
Front passenger seat heater control unit |
18K |
| N25/5 |
Driver seat heater control unit |
18K |
| N32/1 |
Driver seat control unit |
11D |
| N32/1 |
Driver seat control unit |
11F |
| N32/2 |
Front passenger seat control unit |
25F |
| N32/2 |
Front passenger seat control unit |
25D |
| N69/1 |
Left front door control unit |
12J |
| N69/2 |
Right front door control unit |
23J |
| N73 |
Electronic ignition switch control unit |
7A |
| S51/1 |
Driver seat climate control switch group |
8J |
| S51/1s3 |
Left front seat ventilation switch |
8J |
| S51/2 |
Front passenger seat climate control switch group |
28J |
| S51/2s3 |
Right front seat ventilation switch |
28J |
| U285 |
Valid for partially electric seat adjustment unit |
17J |
