| A0 |
Color code key |
80L |
| A1 |
Instrument cluster |
15L |
| A2 |
Radio |
44L |
| A2/30-1 |
Cradle for navigation module |
49A |
| A32 |
AC housing |
15A |
| A34/7 |
Bluetooth® module |
52L |
| A40/11 |
Multifunction camera |
67A |
| A40/3 |
COMAND control unit |
44L |
| A40/3 |
COMAND control unit |
48L |
| A40/4 |
DVD player |
40L |
| A40/8 |
Audio/COMAND display |
19A |
| A40/9 |
Audio/COMAND control panel |
25A |
| A50/6 |
Dedicated Short-Range Communications control unit |
56L |
| A98 |
Panoramic sliding roof control module |
65L |
| A98/1 |
Sliding roof control module |
62A |
| B76/1 |
Condensation sensor for fuel filter with heating element |
27L |
| Code 238 |
Active Lane Keeping Assist |
6C |
| Code 301 |
Ashtray in place of stowage compartment with flap and power outlet |
41A |
| Code 311 |
Temperature-controlled cup holder |
36A |
| Code 386 |
Comfort telephony |
50H |
| Code 386 |
Comfort telephony |
50G |
| Code 413 |
Panoramic sliding sunroof |
63G |
| Code 414 |
Glass electric sliding roof |
60A |
| Code 430 |
On-road/off-road package |
34G |
| Code 430 |
On-road/off-road package |
28G |
| Code 443 |
Steering wheel heater |
6C |
| Code 476 |
Automatic lane detection |
64A |
| Code 489 |
AIRMATIC |
28H |
| Code 494 |
USA version |
46H |
| Code 498 |
Japan version |
46H |
| Code 498 |
Japan version |
55H |
| Code 498 |
Japan version |
51A |
| Code 508 |
Navigation module preinstallation |
46A |
| Code 509 |
Navigation module |
46A |
| Code 513 |
Speed Limit Assist |
64A |
| Code 518 |
Media Interface |
27A |
| Code 551 |
Anti-theft alarm system (ATA [EDW]) |
68G |
| Code 580 |
Automatic air conditioning |
13A |
| Code 581 |
Comfort automatic air conditioning |
21G |
| Code 581 |
Comfort automatic air conditioning |
13A |
| Code 864 |
Rear compartment entertainment |
38G |
| Code 866 |
Rear entertainment preinstallation |
38H |
| Code 872 |
Left and right rear seat heaters |
55A |
| Code 876 |
Interior lights package |
1G |
| Code 876 |
Interior lights package |
58G |
| Code 930 |
Tachograph preinstallation |
31A |
| Code 930 |
Tachograph preinstallation |
43B |
| E10/1 |
Left center air outlet symbol illumination |
2L |
| E10/1x1 |
Center vent symbol illumination electrical connector |
2J |
| E10/2 |
Left front side air outlet symbol illumination |
4L |
| E10/2x1 |
Left front side vent symbol illumination electrical connector |
4J |
| E10/3 |
Right front side air outlet symbol illumination |
6L |
| E10/3x1 |
Right front side vent symbol illumination electrical connector |
5J |
| E10/4 |
Right center air outlet symbol illumination |
3L |
| E10/4x1 |
Right center vent symbol illumination electrical connector |
3J |
| E17/15 |
Right front footwell lamp |
10L |
| E17/16 |
Left front footwell lamp |
11L |
| E36/2 |
Front center console illumination |
61L |
| E43/7 |
Driver-side instrument panel ambiance illumination |
7L |
| E43/8 |
Passenger-side instrument panel ambiance illumination |
8L |
| N10 |
SAM control unit |
76A |
| N125/1 |
Media interface control unit |
29A |
| N154 |
Digital tachograph control unit |
34A |
| N22/7 |
Automatic air conditioning control and operating unit |
16A |
| N26/6 |
ATA [EDW]/towing sensor/interior motion sensor control unit |
69L |
| N29/8 |
Booster blower electronic blower controller |
23L |
| N70 |
Overhead control panel control unit |
71A |
| N72 |
Lower control panel control unit |
30L |
| N72/1 |
Upper control panel control unit |
11A |
| N72/2 |
RCP [HBF] control unit |
58A |
| N72/3 |
Off-Road operating panel control unit |
36L |
| N73 |
Electronic ignition switch control unit |
19L |
| N80 |
Steering column module control unit |
7A |
| R3 |
Front cigarette lighter with ashtray illumination |
42A |
| R3 |
Front cigarette lighter with ashtray illumination |
45A |
| R3e1 |
Ashtray illumination |
43A |
| R3e1 |
Ashtray illumination |
46A |
| R3r1 |
Cigarette lighter heating element |
42A |
| R3r1 |
Cigarette lighter heating element |
45A |
| R3x1 |
Electrical connector for cigarette lighter with ashtray illumination |
42D |
| R3x1 |
Electrical connector for cigarette lighter with ashtray illumination |
45D |
| S17/9 |
Glove box lamp switch |
24L |
| S76/15 |
Electric parking brake switch |
12L |
| U1061 |
Not valid for cup holder |
58H |
| U12 |
Valid for left-hand drive vehicles |
74A |
| U154 |
Valid for 166.0 |
51B |
| U155 |
Valid for 166.8 |
43B |
| U2 |
Valid for all except USA |
55A |
| U20 |
Valid for all (except {{USA}} {{Japan}}) |
42H |
| U20 |
Valid for all (except {{USA}} {{Japan}}) |
42H |
| U34 |
Valid for automatic lane recognition |
6C |
| U631 |
Valid for COMAND |
17A |
| U631 |
Valid for COMAND |
46H |
| U631 |
Valid for COMAND |
42G |
| U631 |
Valid for COMAND |
46G |
| U865 |
Valid for Audio 20 |
42H |
| U880 |
Valid for engine 642 |
26G |
| W1/4 |
Cockpit ground point |
13G |
| W12 |
Ground point (center console) |
42G |
| W18/5 |
Roof ground point |
67G |
| X1/62 |
Vehicle interior electrical connector for navigation module/cradle for navigation module |
50C |
| X11/4 |
Diagnostic connector |
17L |
| X122/2 |
Rear air conditioning electrical connector |
23J |
| X133/2 |
Sliding roof electrical connector |
64J |
| X137/1 |
VICS and Electronic Toll Collection power supply electrical connector |
56J |
| X137/1 |
VICS and Electronic Toll Collection power supply electrical connector |
53C |
| X137/1 |
VICS and Electronic Toll Collection power supply electrical connector |
53A |
| X156 |
Illuminated cup holder separation point |
59L |
| X156/3 |
Cup holder connecting point |
37A |
| X237/1 |
Mobile phone contact plate |
52L |
| X29/6 |
Center console electrical connector |
33H |
| X29/6 |
Center console electrical connector |
25C |
| X29/6 |
Center console electrical connector |
38E |
| X29/6 |
Center console electrical connector |
60G |
| X29/6 |
Center console electrical connector |
58C |
| X39/37 |
Mobile phone electrical connector |
52J |
| X58/19 |
Left 2nd seat row socket |
39A |
| X58/20 |
Right 2nd seat row socket |
40A |
| Z50/3 |
Circuit 31 instrument panel connector sleeve |
5G |
| Z6/79 |
Front center console circuit 31 connector sleeve |
38C |
| Z61/7 |
Wiring harness connector sleeve for center console, terminal 58d |
58H |
| Z61/7 |
Wiring harness connector sleeve for center console, terminal 58d |
61G |
