| A0 |
Color code key |
80L |
| CAN B |
Interior CAN |
41K |
| CAN B |
Interior CAN |
45K |
| Code 233 |
DISTRONIC PLUS |
15G |
| Code 237 |
Active Blind Spot Assist |
15G |
| Code 238 |
Active Lane Keeping Assist |
15G |
| Code 494 |
USA version |
19G |
| Code 494 |
USA version |
35G |
| Code 889 |
KEYLESS-GO |
11G |
| Code B03 |
ECO start/stop function |
1J |
| Code B03 |
ECO start/stop function |
75H |
| Code U10 |
Weight sensing system (WSS) |
19G |
| F32 |
Front electrical prefuse box |
77L |
| M24 |
Rear window roller sun blind motor |
5L |
| M24x1 |
Rear window roller sun blind motor electrical connector |
5J |
| N10/1 |
Front SAM control unit with fuse and relay module |
69L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
4A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
11A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
28A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
20A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
38A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
44A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
52A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
60A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
69A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
75A |
| N10/2f68 |
Fuse 68 |
35A |
| N10/2f71 |
Fuse 71 |
30A |
| N10/2f72 |
Fuse 72 |
34A |
| N10/2f74 |
Fuse 74 |
12A |
| N10/2f76 |
Fuse 76 |
25A |
| N10/2f77 |
Fuse 77 |
22A |
| N10/2f78 |
Fuse 78 |
9A |
| N10/2f79 |
Fuse 79 |
18A |
| N10/2f80 |
Fuse 80 |
16A |
| N10/2kG |
Circuit 15R relay (2) |
26A |
| N110 |
Weight Sensing System (WSS) control unit |
21L |
| N110 |
Weight Sensing System (WSS) control unit |
21L |
| N28/1 |
Trailer recognition control unit |
41L |
| N30/4 |
Electronic Stability Program control unit |
72L |
| N30/4 |
Electronic Stability Program control unit |
72L |
| N62 |
Parking system control unit |
17L |
| N62/2 |
Video and radar sensor system control unit |
17L |
| N69/5 |
KEYLESS-GO control unit |
13L |
| R3 |
Front cigarette lighter with ashtray illumination |
31L |
| R3e1 |
Ashtray illumination |
31L |
| R3r1 |
Cigarette lighter heating element |
32L |
| R3x1 |
Front cigarette lighter with ashtray illumination electrical connector |
30J |
| S54/5 |
Left rear backrest inclination switch |
56L |
| S54/6 |
Right rear backrest inclination switch |
57L |
| S54/7 |
Left rear backrest lock switch |
58L |
| S54/8 |
Right rear backrest lock switch |
61L |
| S68/14 |
Center rear seat belt buckle switch |
51L |
| S68/14x1 |
Center rear seat belt buckle switch electrical connector |
51J |
| S68/5 |
Left rear seat belt buckle switch |
47L |
| S68/5x1 |
Left rear seat belt buckle switch electrical connector |
47J |
| S68/6 |
Right rear seat belt buckle switch |
54L |
| S68/6x1 |
Right rear seat belt buckle switch electrical connector |
53J |
| U108 |
Valid for rear seat belt buckles |
47G |
| U108 |
Valid for rear seat belt buckles |
47G |
| U19 |
Valid for standard equipment |
33G |
| U21 |
Valid for heated seats |
6G |
| U240 |
Valid for all except ECO start/stop function |
1J |
| U240 |
Valid for all except ECO start/stop function |
75G |
| U325 |
Valid for smoker package |
30G |
| U326 |
Valid for nonsmoker package |
28G |
| U438 |
Valid for seat ventilation |
8G |
| U46 |
Valid for rear window roller sun blind |
4G |
| U538 |
Valid for PARKTRONIC |
15H |
| U57 |
Valid for model 204.2 |
33G |
| U57 |
Valid for model 204.2 |
52H |
| U57 |
Valid for model 204.2 |
48H |
| U57 |
Valid for model 204.2 |
50H |
| U57 |
Valid for model 204.2 |
59H |
| U57 |
Valid for model 204.2 |
63G |
| U57 |
Valid for model 204.2 |
62G |
| U57 |
Valid for model 204.2 |
71G |
| U57 |
Valid for model 204.2 |
71G |
| U58 |
Valid for model 204.0 |
19H |
| U58 |
Valid for model 204.0 |
19H |
| U58 |
Valid for model 204.0 |
35H |
| U58 |
Valid for model 204.0 |
52J |
| U58 |
Valid for model 204.0 |
48J |
| U58 |
Valid for model 204.0 |
50J |
| U58 |
Valid for model 204.0 |
59J |
| U58 |
Valid for model 204.0 |
63G |
| U58 |
Valid for model 204.0 |
62G |
| U58 |
Valid for model 204.0 |
71H |
| U58 |
Valid for model 204.0 |
71G |
| U59 |
Valid for model 204.9 |
15H |
| U59 |
Valid for model 204.9 |
19H |
| U59 |
Valid for model 204.9 |
19J |
| U59 |
Valid for model 204.9 |
33G |
| U59 |
Valid for model 204.9 |
35H |
| U59 |
Valid for model 204.9 |
35G |
| U59 |
Valid for model 204.9 |
52J |
| U59 |
Valid for model 204.9 |
50J |
| U59 |
Valid for model 204.9 |
48J |
| U59 |
Valid for model 204.9 |
59J |
| U59 |
Valid for model 204.9 |
62G |
| U59 |
Valid for model 204.9 |
63H |
| U59 |
Valid for model 204.9 |
71H |
| U59 |
Valid for model 204.9 |
71G |
| U60 |
Valid for model 204.3 |
19G |
| U60 |
Valid for model 204.3 |
52J |
| U60 |
Valid for model 204.3 |
48J |
| U60 |
Valid for model 204.3 |
59J |
| U60 |
Valid for model 204.3 |
62H |
| U60 |
Valid for model 204.3 |
71H |
| U60 |
Valid for model 204.3 |
65G |
| U804 |
Valid for rear backrest adjustment |
55G |
| U856 |
Valid for rear socket |
23G |
| U925 |
Valid for 115V socket |
35G |
| U998 |
Valid for EASY-ENTRY |
65G |
| W18 |
Left front seat crossmember ground point |
49L |
| W18 |
Left front seat crossmember ground point |
56H |
| W19 |
Right front seat crossmember ground point |
23H |
| W19 |
Right front seat crossmember ground point |
29H |
| W19 |
Right front seat crossmember ground point |
31H |
| W19 |
Right front seat crossmember ground point |
57H |
| W6/1 |
Left taillamp trunk ground point |
33H |
| W6/1 |
Left taillamp trunk ground point |
49L |
| W7 |
Right wheelhouse trunk ground point |
4H |
| W7 |
Right wheelhouse trunk ground point |
33H |
| W7 |
Right wheelhouse trunk ground point |
50L |
| W7 |
Right wheelhouse trunk ground point |
53L |
| W7 |
Right wheelhouse trunk ground point |
60L |
| W7/1 |
Right taillamp trunk ground point |
50L |
| W7/1 |
Right taillamp trunk ground point |
53L |
| W7/1 |
Right taillamp trunk ground point |
60L |
| X30/32 |
Left vehicle floor interior CAN voltage distributor electrical connector |
45L |
| X55/4 |
Front passenger seat connector block |
21J |
| X58/1 |
Vehicle interior power outlet |
24L |
| X58/17 |
Front vehicle interior power outlet |
29L |
| X58/17x1 |
Electrical connector/front vehicle interior socket |
28J |
| X58/34 |
115 V socket |
39L |
| X58/34s1 |
Socket microswitch |
38K |
| X58/4 |
Load compartment socket |
34L |
