| A0 |
Color code key |
64L |
| A2 |
Radio |
15L |
| A2 |
Radio |
22L |
| A2/56 |
Radio with auto pilot system |
14L |
| A40/3 |
COMAND control unit |
18L |
| A40/3 |
COMAND control unit |
27L |
| A67 |
Inside rearview mirror |
35L |
| A67b1 |
Hands-free system microphone |
31K |
| A67e1 |
Left reading lamp |
33K |
| A67e2 |
Right reading lamp |
33K |
| A67e3 |
Ambient lamp |
34K |
| A67e4 |
Garage door opener indicator lamp |
36K |
| A67h1 |
Forward automatic dimming mirror light sensor |
37K |
| A67h2 |
Rearward automatic dimming mirror light sensor |
37K |
| A67h3 |
Automatic dimming mirror |
38K |
| A67n2 |
Garage door opener |
36J |
| A67n3 |
Compass module with display |
39J |
| A67s1 |
Garage door opener button 1 |
35K |
| A67s2 |
Garage door opener button 2 |
35K |
| A67s3 |
Garage door opener button 3 |
36K |
| A67s8 |
Compass display button |
39K |
| A67x1 |
Inside rearview mirror unit electrical connector |
30G |
| B38/1 |
Light sensor |
9L |
| B38/2 |
Rain/light sensor |
11L |
| Code 359 |
TELEAID emergency call system |
53A |
| Code 498 |
Japan version |
25F |
| Code 498 |
Japan version |
17F |
| Code 580 |
Automatic air conditioning |
5F |
| Code 581 |
Comfort automatic air conditioning |
5F |
| E14/1 |
Left sun visor mirror lamp |
41L |
| E14/2 |
Right sun visor mirror lamp |
43L |
| E15/3 |
Rear dome lamp |
45L |
| E15/3 |
Rear dome lamp |
47L |
| E15/3e1 |
Left rear reading lamp |
47K |
| E15/3e2 |
Right rear reading lamp |
48K |
| E15/3e3 |
Rear interior lamp |
46K |
| E15/3s1 |
Left rear reading lamp switch |
47K |
| E15/3s2 |
Right rear reading lamp switch |
48K |
| LIN 2 |
Wiper/inside rearview mirror LIN |
3B |
| LIN 2 |
Wiper/inside rearview mirror LIN |
11B |
| LIN 2 |
Wiper/inside rearview mirror LIN |
35B |
| N10/1 |
Front SAM control unit with fuse and relay module |
4L |
| N10/1 |
Front SAM control unit with fuse and relay module |
55L |
| N123/4 |
Emergency call system control unit |
58L |
| N70/3 |
Overhead control panel electronics |
5A |
| N70/3 |
Overhead control panel electronics |
12A |
| N70/3 |
Overhead control panel electronics |
20A |
| N70/3 |
Overhead control panel electronics |
28A |
| N70/3 |
Overhead control panel electronics |
36A |
| N70/3 |
Overhead control panel electronics |
44A |
| N70/3 |
Overhead control panel electronics |
51A |
| N70/3 |
Overhead control panel electronics |
60A |
| N70/3b1 |
Interior temperature sensor with integrated fan |
4A |
| N70/3e4 |
Left front interior lamp |
9A |
| N70/3e5 |
Right front interior lamp |
10A |
| N70/3s2 |
Rear dome lamp switch |
1A |
| N70/3s3 |
Interior lamp automatic function switch |
2A |
| N70/3s4 |
Front dome lamp switch |
6A |
| N70/3s6 |
Left front reading lamp switch |
7A |
| N70/3s7 |
Right front reading lamp switch |
8A |
| N70s8 |
Interior protection switch |
61A |
| N70s9 |
Towing sensor button |
63A |
| S101 |
Left front mirror lamp switch |
40L |
| S102 |
Right front mirror lamp switch |
42L |
| U12 |
Valid for left-hand drive vehicles |
22F |
| U12 |
Valid for left-hand drive vehicles |
27F |
| U129 |
Valid for panoramic sliding roof |
49A |
| U13 |
Valid for right-hand drive vehicles |
24F |
| U13 |
Valid for right-hand drive vehicles |
28F |
| U16 |
Valid for ATA [EDW] with tow-away protection and interior protection |
61K |
| U19 |
Valid for standard equipment |
8E |
| U195 |
Valid for rain/light sensor |
10E |
| U54 |
Valid for all except Japan |
25F |
| U54 |
Valid for all except Japan |
17F |
| U58 |
Valid for model 204.0 |
54F |
| U59 |
Valid for model 204.9 |
54F |
| U60 |
Valid for model 204.3 |
54F |
| U865 |
Valid for Audio 20 |
13F |
| U865 |
Valid for Audio 20 |
21F |
| U866 |
Valid for Audio 50 |
13F |
| U919 |
Valid for equipment AVANTGARDE and ELEGANCE |
46A |
| U920 |
Valid for equipment CLASSIC |
44A |
| U926 |
Valid for compass |
38G |
| W18/3 |
Left front seat crossmember ground point 2 |
55H |
| W6/1 |
Left taillamp trunk ground point |
55H |
| X18/37 |
Emergency call system button electrical connector |
54E |
| Z81 |
Circuit 58d connector sleeve |
56G |
