| A0 |
Color code key |
23L |
| A40/3 |
COMAND control unit |
10L |
| B84/10 |
Rear end 360° camera |
19L |
| B84/7 |
Left outside mirror 360° camera |
16L |
| B84/8 |
Right outside mirror 360° camera |
21L |
| B84/9 |
Front end 360° camera |
14L |
| CAN G |
Front end CAN |
6K |
| Code 498 |
Japan version |
8G |
| N10/2 |
Rear SAM control unit with fuse and relay module |
3L |
| N10/2f84 |
Fuse 84 |
2L |
| N148 |
360° camera control unit |
4A |
| N148 |
360° camera control unit |
12A |
| N148 |
360° camera control unit |
20A |
| U54 |
Valid for all except Japan |
8F |
| W6/1 |
Left taillamp trunk ground point |
2E |
| X169 |
Backup camera electrical connector |
18E |
| X30/49 |
Front end CAN potential distributor electrical connector |
6L |
