| A0 |
Color code key |
64L |
| A9 |
Refrigerant compressor |
8A |
| B22/10 |
Right rear level sensor |
25L |
| B4/7 |
Fuel pressure sensor |
56L |
| B4/7 |
Fuel pressure sensor |
61L |
| B4/7 |
Fuel pressure sensor |
59L |
| Code 468 |
Active roll stabilization |
19A |
| Code 468 |
Active roll stabilization |
49A |
| Code 489 |
AIRMATIC |
14A |
| Code 551 |
Anti-theft alarm system (ATA [EDW]) |
10A |
| Code 580 |
Automatic air conditioning |
1A |
| Code 581 |
Comfort automatic air conditioning |
1A |
| F58 |
Engine compartment fuse and relay module |
33A |
| F58 |
Engine compartment fuse and relay module |
4A |
| F58 |
Engine compartment fuse and relay module |
17A |
| F58 |
Engine compartment fuse and relay module |
39A |
| F58 |
Engine compartment fuse and relay module |
42A |
| F58 |
Engine compartment fuse and relay module |
48A |
| F58f215 |
Fuse 215 |
36A |
| F58f215 |
Fuse 215 |
45A |
| F58f216 |
Fuse 216 |
31A |
| F58f216 |
Fuse 216 |
42A |
| F58f217 |
Fuse 217 |
38A |
| F58f217 |
Fuse 217 |
47A |
| F58f240a |
Fuse 240a |
34A |
| F58f240a |
Fuse 240a |
43A |
| H3/1 |
Alarm siren |
13A |
| M1 |
Starter |
33L |
| M1 |
Starter |
35L |
| M1 |
Starter |
43L |
| M13/5 |
Coolant circulation pump |
1L |
| N118 |
Fuel pump control unit |
59A |
| N22/7 |
Automatic air conditioning control and operating unit |
4L |
| N22/7 |
Automatic air conditioning control and operating unit |
9L |
| N26/6 |
ATA [EDW]/towing sensor/interior motion sensor control unit |
12L |
| N51/3 |
AIRMATIC control unit |
17L |
| N51/6 |
Active roll stabilization control unit |
21L |
| N51/6 |
Active roll stabilization control unit |
52A |
| N71/1 |
Headlamp control unit |
25A |
| U1 |
Valid for USA |
57J |
| U1018 |
Valid for gasoline engine 276 |
29A |
| U1032 |
Valid for engine 278 and 157 |
29A |
| U1032 |
Valid for engine 278 and 157 |
34H |
| U1045 |
Not valid for diesel engine 642 |
49A |
| U1073 |
Valid for gasoline engine 276.9 |
34H |
| U2 |
Valid for all except USA |
57H |
| U391 |
Valid for gasoline engine 276.8 |
31H |
| U501 |
Valid for xenon headlamps |
23A |
| U74 |
Valid for diesel engines |
54A |
| U880 |
Valid for engine 642 |
5B |
| U880 |
Valid for engine 642 |
60H |
| U880 |
Valid for engine 642 |
44D |
| U880 |
Valid for engine 642 |
41A |
| U948 |
Valid for diesel engine 651 |
5B |
| U948 |
Valid for diesel engine 651 |
57H |
| U948 |
Valid for diesel engine 651 |
45D |
| U948 |
Valid for diesel engine 651 |
41A |
| U985 |
Not valid for AIRMATIC |
23A |
| W2 |
Right front ground point at lamp unit |
47E |
| X18 |
Vehicle interior and harness for taillamp electrical connector |
2H |
| X18 |
Vehicle interior and harness for taillamp electrical connector |
8H |
| X22/2 |
Automatic transmission/intelligent servo module electrical connector |
6E |
| X22/2 |
Automatic transmission/intelligent servo module electrical connector |
20E |
| X25/2 |
Engine compartment/vehicle interior electrical connector |
2F |
| X25/2 |
Engine compartment/vehicle interior electrical connector |
52E |
| X26 |
Interior and engine wiring harness electrical connector |
32K |
| X26/31 |
Engine/engine compartment electrical connector |
30H |
| X26/31 |
Engine/engine compartment electrical connector |
6E |
| X26/31 |
Engine/engine compartment electrical connector |
20E |
| Y86/2 |
Active roll stabilization intake throttle valve |
21A |
| Y86/2 |
Active roll stabilization intake throttle valve |
52L |
| Z6 |
Circuit 31 connector sleeve |
47L |
| Z7/35z1 |
Circuit 87 M1e connector sleeve |
36L |
| Z7/36z1 |
Circuit 87 M2e connector sleeve |
31L |
| Z7/38z1 |
Circuit 87 M1i connector sleeve |
37L |
| Z7/47 |
Circuit 87D1 connector sleeve |
46E |
| Z7/48 |
Circuit 87D2 connector sleeve |
30E |
| Z7/48 |
Circuit 87D2 connector sleeve |
41E |
| Z7/5z1 |
Circuit 87 connector sleeve |
46L |
| Z7/5z2 |
Circuit 87 connector sleeve |
41L |
| Z7/5z3 |
Circuit 87 connector sleeve |
44L |
| Z7/75 |
Circuit 87 D3 connector sleeve |
44E |
