| A0 |
Color code key |
72L |
| A1 |
Instrument cluster |
20A |
| A2/18 |
FM 1, AM, CL [ZV] and KEYLESS GO antenna amplifier |
18L |
| A40/8 |
Audio/COMAND display |
30A |
| A80 |
Intelligent servo module for DIRECT SELECT |
14L |
| A9 |
Refrigerant compressor |
59L |
| A9 |
Refrigerant compressor |
56L |
| B12 |
Refrigerant pressure sensor |
60L |
| CAN A |
Telematics CAN |
28K |
| CAN E1 |
Chassis CAN 1 |
4K |
| CAN E2 |
Chassis CAN 2 |
21K |
| Code 580 |
Automatic air conditioning |
40A |
| Code 581 |
Comfort automatic air conditioning |
40A |
| Code 581 |
Comfort automatic air conditioning |
61C |
| Code 876 |
Interior lights package |
23A |
| Code B03 |
ECO start/stop function |
6K |
| E13/1 |
Glove box lamp |
35A |
| E43/7 |
Driver-side instrument panel ambiance illumination |
24A |
| E43/8 |
Passenger-side instrument panel ambiance illumination |
26A |
| F4 |
Rear fuse box |
36L |
| F4 |
Rear fuse box |
41L |
| F4f114 |
Fuse 114 |
38K |
| F4f135 |
Fuse 135 |
35K |
| F4kB |
Heated rear window relay |
42L |
| F58 |
Engine compartment fuse and relay module |
46L |
| F58kS |
Wiper park position heater relay |
44L |
| M13/5 |
Coolant circulation pump |
50L |
| M2/35 |
Rear air distribution flap actuator motor |
69K |
| N10/8 |
Rear control unit |
25L |
| N128 |
Electric parking brake control unit |
32L |
| N22/7 |
Automatic air conditioning control and operating unit |
44A |
| N22/7 |
Automatic air conditioning control and operating unit |
53A |
| N22/7 |
Automatic air conditioning control and operating unit |
60A |
| N69/1 |
Left front door control unit |
11L |
| N73 |
Electronic ignition switch control unit |
12A |
| N80 |
Steering column module control unit |
4A |
| S1 |
Exterior lights switch |
38A |
| S76/15 |
Electric parking brake switch |
33A |
| U1045 |
Not valid for diesel engine 642 |
13G |
| U12 |
Valid for left-hand drive vehicles |
9G |
| U13 |
Valid for right-hand drive vehicles |
9G |
| U501 |
Valid for xenon headlamps |
36A |
| U679 |
Valid for version without xenon headlamps |
36A |
| U75 |
Valid for gasoline engines |
56H |
| U880 |
Valid for engine 642 |
13G |
| U880 |
Valid for engine 642 |
53H |
| U948 |
Valid for diesel engine 651 |
56H |
| X122/2 |
Rear air conditioning electrical connector |
68G |
| X18 |
Vehicle interior and harness for taillamp electrical connector |
7G |
| X22/2 |
Automatic transmission/intelligent servo module electrical connector |
14H |
| X22/2 |
Automatic transmission/intelligent servo module electrical connector |
54J |
| X25/2 |
Engine compartment/vehicle interior electrical connector |
12H |
| X25/2 |
Engine compartment/vehicle interior electrical connector |
48H |
| X26 |
Interior and engine wiring harness electrical connector |
57K |
| X26/31 |
Engine/engine compartment electrical connector |
57J |
| X30/19 |
Vehicle floor chassis CAN E1 potential distributor electrical connector |
4L |
| X30/30 |
Vehicle floor chassis CAN E2 potential distributor electrical connector |
21L |
| X30/47 |
Telematics CAN voltage distributor electrical connector |
28L |
| X35/1 |
Left front door electrical connector |
10H |
| X35/2 |
Right front door electrical connector |
10J |
| Z216 |
Multi-color ambiance illumination connector sleeve |
24D |
| Z232 |
Ambiance illumination connector sleeve |
26E |
| Z35/20 |
Chassis CAN high connector sleeve 1 |
4D |
| Z35/21 |
Chassis CAN low connector sleeve 1 |
3D |
| Z35/7 |
CAN bus high cockpit bus node |
20D |
| Z35/8 |
CAN bus low cockpit bus node |
19D |
| Z44/2 |
Buffer battery connector sleeve |
7H |
| Z68/1 |
Instrument panel circuit 31 climate control LIN connector sleeve |
63E |
| Z68/2 |
Instrument panel climate control LIN positive line connector sleeve |
62E |
| Z68/3 |
Vehicle interior LIN bus ground line connector sleeve |
63H |
| Z68/4 |
Vehicle interior LIN bus positive line connector sleeve |
62H |
| Z68/9 |
Vehicle interior LIN bus data connector sleeve |
64H |
