| 1 |
Multifunction steering wheel button group, signal |
5K |
| 1 |
Multifunction steering wheel button group, signal |
12J |
| 1 |
Multifunction steering wheel button group, signal |
13H |
| 1 |
Multifunction steering wheel button group, signal |
3K |
| 1 |
Multifunction steering wheel button group, signal |
7G |
| 10 |
Wheel rotation direction, signal |
6E |
| 10 |
Wheel rotation direction, signal |
12E |
| 11 |
Switch-on request, signal |
14C |
| 12 |
Audio/COMAND display, signal |
15C |
| 13 |
RTTD signal |
21K |
| 13 |
RTTD signal |
16H |
| 14 |
Traffic data, signal |
21G |
| 14 |
Traffic data, signal |
17F |
| 15 |
DAB band III, signal |
16D |
| 15 |
DAB band III, signal |
32D |
| 15 |
DAB band III, signal |
32B |
| 15 |
DAB band III, signal |
36D |
| 15 |
DAB band III, signal |
40B |
| 15 |
DAB band III, signal |
40D |
| 2 |
Audio/COMAND controller, request |
12F |
| 3 |
Sound system amplifier, actuation |
26E |
| 4 |
Voice input, signal |
15H |
| 5 |
GPS, signal |
17G |
| 5 |
GPS, signal |
21H |
| 6 |
Wheel speed, signal |
6E |
| 6 |
Wheel speed, signal |
12E |
| 7 |
VICS, signal |
17E |
| 7 |
VICS, signal |
16D |
| 7 |
VICS, signal |
18A |
| 8 |
Position data, signal |
18F |
| 8 |
Position data, signal |
22F |
| 9 |
FM antenna, signal |
12E |
| 9 |
FM antenna, signal |
13D |
| 9 |
FM antenna, signal |
12D |
| 9 |
FM antenna, signal |
9D |
| 9 |
FM antenna, signal |
7B |
| 9 |
FM antenna, signal |
12A |
| 9 |
FM antenna, signal |
31F |
| 9 |
FM antenna, signal |
31J |
| 9 |
FM antenna, signal |
30J |
| A1 |
Instrument cluster |
13J |
| A2/118 |
Windshield antenna |
31L |
| A2/18 |
FM 1, AM, CL [ZV] and KEYLESS GO antenna amplifier |
11B |
| A2/19 |
FM 2 and DAB antenna amplifier |
10D |
| A2/19 |
FM 2 and DAB antenna amplifier |
38D |
| A2/19 |
FM 2 and DAB antenna amplifier |
38B |
| A2/32 |
Rear window antenna |
5B |
| A2/32 |
Rear window antenna |
41G |
| A2/32 |
Rear window antenna |
29L |
| A2/37 |
VICS control unit |
20D |
| A2/5 |
Global positioning system antenna splitter |
20H |
| A2/52 |
Emergency call system antenna |
23G |
| A2/71 |
Rear window antenna amplifier 1 |
8B |
| A2/89 |
TV antenna splitter |
35D |
| A2/94 |
ETC/DSRC antenna |
19A |
| A28/11 |
Multifunction antenna |
23K |
| A40/3 |
COMAND control unit |
14E |
| A40/8 |
Audio/COMAND display |
14A |
| A40/9 |
Audio/COMAND control panel |
11H |
| A50/6 |
Dedicated Short-Range Communications control unit |
17A |
| A67b1 |
Hands-free system microphone |
15J |
| A90/4 |
Tuner unit |
19K |
| A90/4 |
Tuner unit |
30C |
| A94/2 |
TV 2 antenna amplifier |
30G |
| CAN A |
Telematics CAN |
14D |
| CAN A |
Telematics CAN |
11G |
| CAN B |
Interior CAN |
13J |
| CAN B |
Interior CAN |
10F |
| CAN E1 |
Chassis CAN 1 |
7H |
| CAN E1 |
Chassis CAN 1 |
5F |
| CAN E2 |
Chassis CAN 2 |
10K |
| Code 348 |
Emergency call/assistance system |
18H |
| Code 537 |
Digital radio |
29A |
| Code 537 |
Digital radio |
33D |
| Code 537 |
Digital radio |
37A |
| Code 537 |
Digital radio |
37D |
| Code 537 |
Digital radio |
40G |
| Code 537 |
Digital radio |
29G |
| Code 537 |
Digital radio |
28K |
| Code 537 |
Digital radio |
31K |
| Code 810 |
Sound system |
26D |
| Code 811 |
Extended sound system |
26E |
| Code 865 |
TV tuner (digital) |
33D |
| LIN E1 |
Steering LIN |
4K |
| LVDS |
Low voltage differential signal |
15D |
| MOST |
Media Oriented System Transport |
19F |
| MOST |
Media Oriented System Transport |
16J |
| MOST |
Media Oriented System Transport |
20B |
| MOST |
Media Oriented System Transport |
27B |
| N10/1 |
Front SAM control unit with fuse and relay module |
8E |
| N112/2 |
Telematics services communication module |
19F |
| N135 |
Steering wheel electronics |
3K |
| N30/4 |
Electronic Stability Program control unit |
3E |
| N30/7 |
Premium Electronic Stability Program control unit |
3E |
| N40/3 |
Sound system amplifier control unit |
27E |
| N80 |
Steering column module control unit |
7J |
| S110 |
Left multifunction steering wheel button group |
2H |
| S111 |
Right multifunction steering wheel button group |
4H |
| U136 |
Valid for Vehicle Information and Communication System (VICS) |
18D |
| U165 |
Valid for AMG |
1E |
| U203 |
Valid without DISTRONIC PLUS |
1D |
| U57 |
Valid for model 218.9 |
7B |
| U57 |
Valid for model 218.9 |
33D |
| U57 |
Valid for model 218.9 |
37C |
| U57 |
Valid for model 218.9 |
31K |
| U58 |
Valid for model 218.3 |
10B |
| U58 |
Valid for model 218.3 |
37A |
| U58 |
Valid for model 218.3 |
28K |
| U8 |
Valid for code B54 COM module and subscription for real-time traffic data |
18F |
| U8 |
Valid for code B54 COM module and subscription for real-time traffic data |
22F |
| U816 |
Valid for satellite digital audio radio (SDAR) |
18K |
| U9 |
Not valid for code B54 COM module and subscription for real-time traffic data |
4B |
| U9 |
Not valid for code B54 COM module and subscription for real-time traffic data |
7B |
| U9 |
Not valid for code B54 COM module and subscription for real-time traffic data |
9D |
| ZU9 |
Not valid for code B54 COM module and subscription for real-time traffic data |
10B |
| U9 |
Not valid for code B54 COM module and subscription for real-time traffic |
29A |
| U9 |
Not valid for code B54 COM module and subscription for real-time traffic data |
29G |
| U9 |
Not valid for code B54 COM module and subscription for real-time traffic data |
33E |
| U9 |
Not valid for code B54 COM module and subscription for real-time traffic data |
37B |
| U9 |
Not valid for code B54 COM module and subscription for real-time traffic data |
37D |
| U9 |
Not valid for code B54 COM module and subscription for real-time traffic data |
40G |
| U9 |
Not valid for code B54 COM module and subscription for real-time traffic data |
28K |
| U9 |
Not valid for code B54 COM module and subscription for real-time traffic data |
31K |
| U909 |
Valid for DISTRONIC PLUS |
1D |
| U986 |
Not valid for AMG |
1D |
