| CAN PER |
Peripherals CAN |
27K |
| K40/5 |
Rear fuse and relay module |
19L |
| K40/5f426 |
Fuse 426 |
16L |
| K40/5f449 |
Fuse 449 |
18L |
| K40/6 |
Left fuse and relay module |
23L |
| K40/6f214 |
Fuse 214 |
22L |
| M76/1 |
Left electric parking brake actuator motor |
12L |
| M76/2 |
Right electric parking brake actuator motor |
14L |
| N10/6 |
Front SAM control unit |
3L |
| N128 |
Electric parking brake control unit |
7A |
| N128 |
Electric parking brake control unit |
12A |
| N128 |
Electric parking brake control unit |
27A |
| N128 |
Electric parking brake control unit |
20A |
| S76/15 |
Electric parking brake switch |
7L |
| U12 |
Valid for left-hand drive vehicles |
9F |
| U13 |
Valid for right-hand drive vehicles |
9G |
| W3/8 |
Right rear wheel well ground point |
10E |
| W34 |
Left footwell ground point |
10G |
| W34/3 |
Right footwell ground point |
10G |
| X18/35 |
Cockpit wiring harness and frame floor assembly electrical connector |
6F |
| X30/27 |
Peripherals CAN (CAN PER) potential distributor electrical connector |
27L |
| X62/32 |
Rear axle electrical connector, left distributor |
11F |
| X62/33 |
Rear axle electrical connector, right distributor |
13F |
| Z81/5z1 |
Circuit 58d connector sleeve |
5G |
