| A0 |
Use of wiring diagrams |
56L |
| A98 |
Panoramic sliding roof control module |
21A |
| A98/1 |
Sliding roof control module |
17A |
| B11/15 |
Radiator sensor for engine diagnosis |
4L |
| B44/2 |
Right front door interior protection sensor |
17L |
| B44/2 |
Right front door interior protection sensor |
47L |
| B44/4 |
Right rear interior protection sensor |
21L |
| B44/4 |
Right rear interior protection sensor |
51L |
| Code 401 |
Seat climate control for driver and front passenger |
32F |
| Code 401 |
Seat climate control for driver and front passenger |
36F |
| Code 494 |
USA version |
1F |
| Code 551 |
Anti-theft alarm system (ATA [EDW]) |
6F |
| Code 551 |
Anti-theft alarm system (ATA [EDW]) |
41F |
| Code 873 |
Seat heater for driver and front passenger |
32F |
| Code 873 |
Seat heater for driver and front passenger |
36F |
| Code 882 |
Interior protection and tow-away protection |
6F |
| Code 882 |
Interior protection and tow-away protection |
11F |
| Code 917 |
PZEV emission USA |
1F |
| Code ME04 |
Hybrid drive 20 KW VARIANT |
28F |
| H3/1 |
Alarm siren |
9L |
| H3/1 |
Alarm siren |
13L |
| H3/1 |
Alarm siren |
43L |
| H4/16 |
Sound generator |
30L |
| N10/6 |
Front SAM control unit |
26L |
| N127 |
Drivetrain control unit |
4A |
| N25/4 |
Front passenger seat heater control unit |
34L |
| N25/4 |
Front passenger seat heater control unit |
38L |
| N26/6 |
ATA [EDW]/towing sensor/interior motion sensor control unit |
29A |
| N70 |
Overhead control panel control unit |
13A |
| U12 |
Valid for left-hand drive vehicles |
36G |
| U13 |
Valid for right-hand drive vehicles |
1A |
| U13 |
Valid for right-hand drive vehicles |
23F |
| U2054 |
Valid for model 205.4 |
11F |
| U2054 |
Valid for model 205.4 |
13C |
| U362 |
Valid for gasoline engine 274 |
2K |
| U606 |
Not valid for convertible |
12C |
| W15/7 |
Right front footwell ground point |
26A |
| X28/30 |
Front passenger airbag electrical connector |
34H |
| X35/2 |
Right front door electrical connector |
17H |
| X35/2 |
Right front door electrical connector |
47H |
| X55/16 |
Right seat separation point |
38H |
| Z6/30 |
Circuit 31 connector sleeve |
4G |
| Z6/30 |
Circuit 31 connector sleeve |
29H |
