| A0 |
Color code key |
80L |
| A103/1 |
AdBlue® tank module |
76A |
| A6 |
Stationary heater unit |
17A |
| A93/2 |
Right 3rd seat row backrest release unit |
53A |
| B4/31 |
Fuel quality sensor |
34L |
| B51/6 |
Right pop-out window anti-pinch protection contact strip |
58A |
| B51/6x1 |
Right pop-out window anti-pinch protection contact strip electrical connector |
58D |
| B76/1 |
Condensation sensor for fuel filter with heating element |
13A |
| Code 228 |
Stationary heater |
31G |
| Code 228 |
Stationary heater |
31H |
| Code 228 |
Stationary heater |
14A |
| Code 293 |
Left and right rear sidebag |
40G |
| Code 494 |
USA version |
64C |
| Code 550 |
Trailer hitch |
64A |
| Code 580 |
Automatic air conditioning |
25A |
| Code 847 |
3rd seat row |
51B |
| Code 890 |
Tailgate control |
59A |
| Code 929 |
Engine for ethanol fuel |
34G |
| Code B03 |
ECO start/stop function |
48A |
| Code B03 |
ECO start/stop function |
77G |
| Code ME05 |
HYBRID DRIVE 80 KW VARIANT (INCLUDING PLUGIN) |
27G |
| Code ME05 |
HYBRID DRIVE 80 KW VARIANT (INCLUDING PLUGIN) |
28A |
| Code ME05 |
HYBRID DRIVE 80 KW VARIANT (INCLUDING PLUGIN) |
56G |
| Code U77 |
BLUETEC (SCR) diesel exhaust treatment |
70A |
| E1 |
Left front lamp unit |
25L |
| E4 |
Right rear lamp unit |
74L |
| K109 |
Vacuum pump relay (+) |
29L |
| K109/1 |
Vacuum pump relay (-) |
30L |
| K114 |
ECO start/stop function additional battery relay |
78L |
| K114 |
ECO start/stop function additional battery relay |
50A |
| M13/5 |
Coolant circulation pump |
27A |
| M14/10 |
Tank cap central locking actuator |
73L |
| M5/2 |
Headlamp cleaning system pump |
22A |
| M6/1 |
Wiper motor |
24A |
| N118 |
Fuel pump control unit |
37L |
| N118/5 |
AdBlue® control unit |
72A |
| N121/1 |
Tailgate control unit |
62A |
| N128 |
Electric parking brake control unit |
37A |
| N14/3 |
Glow output stage |
15L |
| N28/1 |
Trailer recognition control unit |
67A |
| N51/3 |
AIRMATIC control unit |
70L |
| N69/4 |
Right rear door control unit |
42A |
| N83/1 |
DC/DC converter control unit |
65L |
| N83/5 |
Charger |
61L |
| N88 |
Tire pressure monitor control unit |
34A |
| R12/11 |
Left rear sidebag squib |
42L |
| R12/12 |
Right rear sidebag squib |
44L |
| R2/10 |
Wiper park heater |
22L |
| R2/10x1 |
Wiper park position heater electrical connector |
22J |
| R2/11 |
Spray nozzle hose heater |
20L |
| R4 |
Spark plugs |
2L |
| R4 |
Spark plugs |
3L |
| R4 |
Spark plugs |
5L |
| R4 |
Spark plugs |
6L |
| R4 |
Spark plugs |
7L |
| R4 |
Spark plugs |
12L |
| R4 |
Spark plugs |
11L |
| R4 |
Spark plugs |
9L |
| R7/1 |
AdBlue® pressure line heating element |
74A |
| S10/4 |
Right rear brake wear sensor |
46L |
| S10/4x1 |
Right rear brake wear sensor electrical connector |
46K |
| S158/5 |
Left 3rd seat row folding backrest switch (load compartment) |
55A |
| S158/8 |
Right 3rd seat row folding backrest switch (load compartment) |
57A |
| S68/14 |
Center rear seat belt buckle switch |
54L |
| S68/14x1 |
Center rear seat belt buckle switch electrical connector |
53K |
| S68/16 |
Left third row seat belt buckle switch |
45A |
| S68/17 |
Right third row seat belt buckle switch |
47A |
| S68/5 |
Left rear seat belt buckle switch |
52L |
| S68/5x1 |
Left rear seat belt buckle switch electrical connector |
52K |
| S68/6 |
Right rear seat belt buckle switch |
55L |
| S68/6x1 |
Right rear seat belt buckle switch electrical connector |
55K |
| T1/1 |
Cylinder 1 ignition coil |
2K |
| T1/1 |
Cylinder 1 ignition coil |
4A |
| T1/2 |
Cylinder 2 ignition coil |
3K |
| T1/2 |
Cylinder 2 ignition coil |
5A |
| T1/3 |
Cylinder 3 ignition coil |
4K |
| T1/3 |
Cylinder 3 ignition coil |
6A |
| T1/4 |
Cylinder 4 ignition coil |
6K |
| T1/4 |
Cylinder 4 ignition coil |
8A |
| T1/5 |
Cylinder 5 ignition coil |
7K |
| T1/5 |
Cylinder 5 ignition coil |
9A |
| T1/6 |
Cylinder 6 ignition coil |
8K |
| T1/6 |
Cylinder 6 ignition coil |
10A |
| T1/7 |
Cylinder 7 ignition coil |
10K |
| T1/8 |
Cylinder 8 ignition coil |
12K |
| U1018 |
Valid for gasoline engine 276 |
2A |
| U1032 |
Valid for engine 278 and 157 |
1G |
| U12 |
Valid for left-hand drive vehicles |
23A |
| U1502 |
Valid without code 847 3rd seat row |
43H |
| U154 |
Valid for 166.0 |
75G |
| U154 |
Valid for 166.0 |
40A |
| U154 |
Valid for 166.0 |
51A |
| U154 |
Valid for 166.0 |
51G |
| U154 |
Valid for 166.0 |
47G |
| U154 |
Valid for 166.0 |
59A |
| U154 |
Valid for 166.0 |
77H |
| U155 |
Valid for 166.8 |
44A |
| U155 |
Valid for 166.8 |
51A |
| U155 |
Valid for 166.8 |
59B |
| U19 |
Valid for standard equipment |
23G |
| U2 |
Valid for all except USA |
64C |
| U215 |
Valid for model series 292 |
40A |
| U215 |
Valid for model series 292 |
51H |
| U215 |
Valid for model series 292 |
68H |
| U215 |
Valid for model series 292 |
77H |
| U217 |
Not valid for model series 166.8 |
41G |
| U259 |
Valid for ADS+ |
68G |
| U28 |
Valid for headlamp cleaning system |
21A |
| U437 |
Not valid for code 4U7 Start/stop voltage dip protection |
48A |
| U437 |
Not valid for code 4U7 Start/stop voltage dip protection |
77H |
| U481 |
Valid for rear seat belt status indication |
51H |
| U708 |
Valid for spray nozzle hose heater |
19G |
| U74 |
Valid for diesel engines |
31H |
| U74 |
Valid for diesel engines |
36H |
| U75 |
Valid for gasoline engines |
31H |
| U75 |
Valid for gasoline engines |
36G |
| U880 |
Valid for engine 642 |
13H |
| U948 |
Valid for diesel engine 651 |
13G |
| U948 |
Valid for diesel engine 651 |
12A |
| U974 |
Not valid for hybrid drive |
40H |
| W11 |
Combustion engine ground point |
7G |
| W17/6 |
Rear seat crossmember ground point |
45G |
| W7 |
Right rear center section ground point |
67G |
| W9 |
Left front ground point (at lamp unit) |
24G |
| X18/3 |
Vehicle interior/fuel tank electrical connector |
33J |
| X18/3 |
Vehicle interior/fuel tank electrical connector |
35J |
| X18/3 |
Vehicle interior/fuel tank electrical connector |
31D |
| X30/47 |
Telematics CAN voltage distributor electrical connector |
49L |
| X30/54 |
Rear hybrid CAN (CAN L) potential distributor electrical connector |
58L |
| X35/4 |
Right rear door electrical connector |
43D |
| X36/6 |
Fuel tank filter electrostatic discharge electrical connector |
30A |
| X55/22 |
Right 3rd seat row connector block |
52D |
| X55/5 |
Left rear seat adjustment unit connector block |
41J |
| X55/6 |
Right rear seat adjustment connector block |
43J |
| X58/4 |
Load compartment socket |
76L |
| X62/33 |
Rear axle electrical connector, right distributor |
46J |
| X88/11 |
Spray nozzle heater electrical connector |
18K |
| Y16 |
Stationary heater switchover valve |
19A |
| Y23 |
Stationary heater fuel pump |
32L |
| Z6/8 |
Ground connection connector sleeve |
10J |
