| A40/8 |
Audio/COMAND display |
40K |
| A40/9 |
Audio/COMAND control panel |
43K |
| A67 |
Inside rearview mirror |
19C |
| A8/1 |
Transmitter key |
33L |
| B38/1 |
Light sensor |
8C |
| B38/2 |
Rain/light sensor |
8D |
| CAN A |
Telematics CAN |
|
| CAN B |
Interior CAN |
|
| CAN B |
Interior CAN |
|
| CAN B |
Interior CAN |
|
| CAN B |
Interior CAN |
|
| CAN B |
Interior CAN |
|
| CAN B |
Interior CAN |
|
| CAN C |
Drive train CAN |
|
| CAN E |
Chassis CAN |
|
| CAN E |
Chassis CAN |
|
| Code 220 |
PARKTRONIC (PTS) |
|
| Code 242 |
Electrically adjustable front passenger seat with memory function |
|
| Code 275 |
Memory function (driver seat, steering column, outside mirror) |
|
| Code 345 |
Rain sensor |
|
| Code 414 |
Electric glass tilting/sliding roof |
|
| Code 423 |
5-speed automatic transmission |
|
| Code 427 |
7-speed automatic transmission |
|
| Code 494 |
USA version |
|
| Code 540 |
Electric roller sun blind for rear window |
|
| Code 581 |
Comfort automatic air conditioning |
|
| Code 581 |
Comfort automatic air conditioning |
|
| Code 873 |
Heated seats for driver and front passenger seat |
|
| Code 954 |
AVANTGARDE |
|
| Code 954 |
AVANTGARDE |
|
| Code 954 |
AVANTGARDE |
|
| Code 954 |
AVANTGARDE |
|
| Code 954 |
AVANTGARDE |
|
| Code 955 |
ELEGANCE |
|
| Code 955 |
ELEGANCE |
|
| Code 955 |
ELEGANCE |
|
| Code 955 |
ELEGANCE |
|
| Code 955 |
ELEGANCE |
|
| E10/1 |
Left center air outlet symbol illumination |
9E |
| E10/2 |
Left front side air outlet symbol illumination |
9E |
| E10/3 |
Right front side air outlet symbol illumination |
9E |
| E10/4 |
Right center air outlet symbol illumination |
9E |
| E10/5 |
Rear air outlet symbol illumination |
11E |
| E17/11 |
Left front door door handle illumination |
2H |
| E17/12 |
Right front door door handle illumination |
2J |
| E17/13 |
Left rear door door handle illumination |
12K |
| E17/14 |
Right rear door door handle illumination |
12L |
| LIN 1 |
Instrument panel LIN |
|
| LIN 1 |
Instrument panel LIN |
|
| LIN 1 |
Instrument panel LIN |
|
| LIN 2 |
Wiper/inside rearview mirror LIN |
|
| LIN 2 |
Wiper/inside rearview mirror LIN |
|
| LIN B5 |
Left door LIN |
|
| LIN B5 |
Left door LIN |
|
| LIN B6 |
Right door LIN |
|
| LIN B8 |
Climate control LIN |
|
| LIN E1 |
Steering LIN |
|
| N10/1 |
Front SAM control unit with fuse and relay module |
15A |
| N10/2 |
Rear SAM control unit with fuse and relay module |
37B |
| N15/5 |
Electronic selector lever module control unit |
22K |
| N22/4 |
Rear automatic air conditioning operating unit |
34G |
| N22/7 |
Automatic air conditioning control and operating unit |
37K |
| N26/9 |
Special-purpose vehicle multifunction control unit |
32B |
| N3/10 |
ME-SFI [ME] control unit |
25J |
| N3/9 |
CDI control unit |
28J |
| N69/1 |
Left front door control unit |
7H |
| N69/2 |
Right front door control unit |
7J |
| N69/3 |
Left rear door control unit |
15H |
| N69/4 |
Right rear door control unit |
15J |
| N70 |
Overhead control panel control unit |
34A |
| N70/3 |
Overhead control panel electronics |
3A |
| N72/1 |
Upper control panel control unit |
21B |
| N73 |
Electronic ignition switch control unit |
32J |
| N80 |
Steering column module control unit |
28A |
| S1 |
Exterior lights switch |
13D |
| S110 |
Left multifunction steering wheel button group |
23A |
| S111 |
Right multifunction steering wheel button group |
24A |
| S15/3 |
Driver tailgate control button |
10H |
| S20 |
Driver-side power window and outside mirror adjustment switch group |
2D |
| S21/2 |
Passenger-side power window switch |
10H |
| S21/3 |
Left rear power window switch |
19K |
| S21/4 |
Right rear power window switch |
19K |
| S22 |
Left front seat adjustment switch group |
2K |
| S23 |
Right front seat adjustment switch group |
2K |
| S6/1 |
Instrument panel switch group |
6B |
| S85/5 |
Left front door central locking interior switch |
10K |
| S85/6 |
Right front door central locking interior switch |
10K |
| S88/10 |
Trunk lid emergency opening switch |
40B |
| U113 |
Valid for 2-zone THERMATIC |
36J |
| U114 |
Valid for 3-zone THERMOTRONIC |
36J |
| U52 |
Valid for Japan |
41E |
| U54 |
Valid for all except Japan |
41E |
| U540 |
Valid for special-purpose vehicles |
31A |
| U631 |
Valid for COMAND |
41E |
| U74 |
Valid for diesel engines |
27J |
| U75 |
Valid for gasoline engines |
24J |
| U865 |
Valid for Audio 20 |
38E |
| U866 |
Valid for Audio 50 |
38E |
