Notes on sealant path for front cover to cylinder head xxx - AH01.30-P-1000-02A

WARNING: This page does not describe the selected car, but rather 203 other vehicles, including the 2020 Mercedes-Benz SLC300, 2020 Mercedes-Benz SL550, 2020 Mercedes-Benz SL450, 2020 Mercedes-Benz S65 AMG, and 2020 Mercedes-Benz GLA250. However, it is still accessible from the selected car via links, so may be relevant.

ENGINE 668.914/940/941/942

Clean sealing surfaces and apply sealant only to the specified areas in a bead measuring 2.0 mm 0.5 mm. (See illustration below) The sealant must be applied within 10 minutes.

Engine 668.914/940/941/942

Fig 1: Identifying Front Cover To Cylinder Head Sealant Applying Area
G10037234Courtesy of MERCEDES-BENZ USA
