| A0 |
Color code key |
32L |
| A89 |
DISTRONIC electric controller unit |
11L |
| A9/1 |
AIRMATIC compressor |
9A |
| B92 |
Front long-range radar sensor |
11L |
| Code 239 |
|
9J |
| Code 23P |
Driver assistance package |
9J |
| Code 489 |
AIRMATIC |
7A |
| Code 551 |
Anti-theft alarm system (ATA [EDW]) |
5J |
| Code 640 |
High Performance LED |
17G |
| Code 641 |
Dynamic LED headlamps, left-hand traffic |
17H |
| Code 642 |
Dynamic LED headlamps, right-hand traffic |
17H |
| Code B03 |
ECO start/stop function |
5J |
| Code B03 |
ECO start/stop function |
7J |
| Code B08 |
Horn (Asia) |
13G |
| Code ME05 |
HYBRID DRIVE 80 KW VARIANT (INCLUDING PLUGIN) |
1G |
| E1 |
Left front lamp unit |
19L |
| E2 |
Right front lamp unit |
19L |
| E2 |
Right front lamp unit |
23L |
| H2 |
Left fanfare horn |
15L |
| H2/1 |
Right fanfare horn |
16L |
| M13/11 |
Coolant run-on pump |
5A |
| M43/7 |
Low temperature circuit circulation pump 2 |
4L |
| M44 |
Charge air cooler circulation pump |
17A |
| N82/2 |
Battery management system control unit |
25A |
| N83/1 |
DC/DC converter control unit |
21A |
| S62/42 |
Right engine hood contact switch |
8L |
| S62/43 |
Left engine hood contact switch |
6L |
| U1018 |
Valid for gasoline engine 276 |
15A |
| U1019 |
Valid for gasoline engine 278 |
15A |
| U1028 |
Valid for engine 157 |
15B |
| U1032 |
Valid for engine 278 and 157 |
4A |
| U225 |
Valid for all except China |
13H |
| U437 |
Valid without code (4U7) Start/stop voltage dip protection |
7J |
| U880 |
Valid for engine 642 |
10A |
| U880 |
Valid for engine 642 |
19A |
| W52/11 |
Upper right front longitudinal member ground point |
11G |
| W52/16 |
Right rear longitudinal member ground point |
27G |
| X174/4 |
Engine compartment/vehicle front electrical connector |
8H |
| X192/1 |
Coolant run-on pump electrical connector |
6C |
| X22/2 |
Automatic transmission/intelligent servo module electrical connector |
11D |
| Y3/8 |
Fully integrated transmission control unit |
12A |
| Y73/1 |
Low-temperature circuit switchover valve |
3L |
