| A0 |
Color code key |
80L |
| A1 |
Instrument cluster |
10L |
| A105 |
Touchpad |
50A |
| A2 |
Radio |
41L |
| A32 |
AC housing |
12A |
| A40/11 |
Multifunction camera |
67A |
| A40/3 |
COMAND control unit |
41L |
| A40/4 |
DVD player |
37L |
| A40/8 |
Audio/COMAND display |
22A |
| A40/9 |
Audio/COMAND control panel |
31A |
| A50/6 |
Dedicated Short-Range Communications control unit |
54L |
| A90/5 |
Multimedia connection unit |
45L |
| A98 |
Panoramic sliding roof control module |
63L |
| A98/1 |
Sliding roof control module |
62A |
| B76/1 |
Condensation sensor for fuel filter with heating element |
25L |
| Code 22P |
Track package |
64A |
| Code 238 |
Active Lane Keeping Assist |
2C |
| Code 301 |
Ashtray in place of stowage compartment with flap and power outlet |
45A |
| Code 311 |
Temperature-controlled cup holder |
39A |
| Code 386 |
Comfort telephony |
47G |
| Code 413 |
Panoramic sliding sunroof |
61G |
| Code 414 |
Glass electric sliding roof |
59A |
| Code 430 |
On-road/off-road package |
31G |
| Code 430 |
On-road/off-road package |
26G |
| Code 443 |
Steering wheel heater |
2C |
| Code 489 |
AIRMATIC |
26H |
| Code 498 |
Japan version |
52H |
| Code 505 |
Radio 20 NTG5, non-navigation-capable |
19A |
| Code 505 |
Radio 20 NTG5, non-navigation-capable |
28A |
| Code 505 |
Radio 20 NTG5, non-navigation-capable |
39H |
| Code 522 |
Audio 20 radio |
19A |
| Code 522 |
Audio 20 radio |
28A |
| Code 522 |
Audio 20 radio |
39H |
| Code 531 |
COMAND APS |
39G |
| Code 531 |
COMAND APS |
48A |
| Code 531 |
COMAND APS |
19B |
| Code 531 |
COMAND APS |
28B |
| Code 551 |
Anti-theft alarm system (ATA [EDW]) |
66G |
| Code 580 |
Automatic air conditioning |
9A |
| Code 581 |
Automatic air conditioning |
1G |
| Code 581 |
Automatic air conditioning |
9A |
| Code 640 |
High Performance LED |
64A |
| Code 641 |
Dynamic LED headlamps, left-hand traffic |
64B |
| Code 642 |
Dynamic LED headlamps, right-hand traffic |
64B |
| Code 864 |
Rear compartment entertainment |
35G |
| Code 872 |
Left and right rear seat heaters |
54A |
| Code 876 |
Interior lights package |
17G |
| Code 876 |
Interior lights package |
57G |
| Code 930 |
Tachograph preinstallation |
34A |
| Code 9U1 |
|
70A |
| Code E64 |
|
70A |
| E10/1 |
Left center air outlet symbol illumination |
20L |
| E10/1x1 |
Center vent symbol illumination electrical connector |
20J |
| E10/2 |
Left front side air outlet symbol illumination |
21L |
| E10/2x1 |
Left front side vent symbol illumination electrical connector |
21J |
| E10/3 |
Right front side air outlet symbol illumination |
23L |
| E10/3x1 |
Right front side vent symbol illumination electrical connector |
22J |
| E17/15 |
Right front footwell lamp |
5L |
| E17/16 |
Left front footwell lamp |
6L |
| E20/2 |
Front center console cup holder illumination |
58L |
| E36/2 |
Front center console illumination |
60L |
| E43/7 |
Driver-side instrument panel ambiance illumination |
19L |
| E43/8 |
Passenger-side instrument panel ambiance illumination |
18L |
| M4/13 |
COMAND fan motor |
26A |
| N10 |
SAM control unit |
73L |
| N154 |
Digital tachograph control unit |
37A |
| N167 |
E-Call Russia (GLONASS) control unit |
73A |
| N167x1 |
E-Call Russia (GLONASS) control unit electrical connector 1 |
71C |
| N22/7 |
Automatic air conditioning control and operating unit |
17A |
| N26/6 |
ATA [EDW]/towing sensor/interior motion sensor control unit |
68L |
| N29/8 |
Booster blower electronic blower controller |
2L |
| N70 |
Overhead control panel control unit |
77A |
| N72 |
Lower control panel control unit |
28L |
| N72/1 |
Upper control panel control unit |
7A |
| N72/2 |
RCP [HBF] control unit |
57A |
| N72/3 |
Off-Road operating panel control unit |
33L |
| N72/4 |
Transmission modes control panel |
33L |
| N73 |
Electronic ignition switch control unit |
15L |
| N80 |
Steering column module control unit |
3A |
| R3 |
Front cigarette lighter with ashtray illumination |
47A |
| R3e1 |
Ashtray illumination |
47A |
| R3r1 |
Cigarette lighter heating element |
46A |
| R3x1 |
Electrical connector for cigarette lighter with ashtray illumination |
46D |
| R5/1 |
Cup holder |
41A |
| S17/9 |
Glove box lamp switch |
4L |
| S76/15 |
Electric parking brake switch |
8L |
| U12 |
Valid for left-hand drive vehicles |
70G |
| U135 |
Valid for Electronic Toll Collection |
52G |
| U154 |
Valid for 166.0 |
61H |
| U155 |
Valid for 166.8 |
62H |
| U2 |
Valid for all except USA |
54A |
| U215 |
Valid for model series 292 |
61J |
| U34 |
Valid for automatic lane recognition |
2C |
| U557 |
Not valid for on-road/off-road package |
31H |
| U880 |
Valid for engine 642 |
24G |
| W1/4 |
Cockpit ground point |
9G |
| W12 |
Ground point (center console) |
47G |
| W18/5 |
Roof ground point |
67G |
| X11/4 |
Diagnostic connector |
12L |
| X120 |
Radio fan electrical connector |
25C |
| X122/2 |
Rear air conditioning electrical connector |
2J |
| X13 |
Cigarette lighter electrical connector |
53A |
| X133/2 |
Sliding roof electrical connector |
63J |
| X133/2 |
Sliding roof electrical connector |
62C |
| X137/1 |
VICS and Electronic Toll Collection power supply electrical connector |
53J |
| X137/1 |
VICS and Electronic Toll Collection power supply electrical connector |
55J |
| X156 |
Illuminated cup holder separation point |
58J |
| X156/3 |
Cup holder connecting point |
40D |
| X237/1 |
Mobile phone contact plate |
49L |
| X29/6 |
Center console electrical connector |
30H |
| X29/6 |
Center console electrical connector |
32C |
| X29/6 |
Center console electrical connector |
43E |
| X29/6 |
Center console electrical connector |
59G |
| X29/6 |
Center console electrical connector |
51C |
| X29/6 |
Center console electrical connector |
57C |
| X39/37 |
Mobile phone electrical connector |
49J |
| X58/19 |
Left 2nd seat row socket |
43A |
| X58/20 |
Right 2nd seat row socket |
44A |
| Z50/3 |
Circuit 31 instrument panel connector sleeve |
18G |
| Z6/79 |
Front center console circuit 31 connector sleeve |
43C |
| Z61/7 |
Wiring harness connector sleeve for center console, terminal 58d |
60G |
| Z61/7 |
Wiring harness connector sleeve for center console, terminal 58d |
57L |
