| A0 |
Color code key |
56L |
| B19/11 |
Temperature sensor upstream of turbocharger |
19L |
| B96 |
Intake port shutoff Hall sensor |
21L |
| F58 |
Engine compartment fuse and relay module |
10L |
| F58f216 |
Fuse 216 |
9L |
| F58f217 |
Fuse 217 |
7L |
| G2 |
Alternator |
41J |
| M16/6 |
Throttle valve actuator |
28L |
| M4/7 |
Fan motor |
13J |
| N14/3 |
Glow output stage |
42J |
| N3/9 |
CDI control unit |
4A |
| N3/9 |
CDI control unit |
20A |
| N3/9 |
CDI control unit |
27A |
| N3/9 |
CDI control unit |
5L |
| N3/9 |
CDI control unit |
12A |
| N3/9 |
CDI control unit |
36A |
| N3/9 |
CDI control unit |
44A |
| U963 |
Valid for piezo fuel injector |
14G |
| U963 |
Valid for piezo fuel injector |
33F |
| U964 |
Valid for all except piezo fuel injector |
30F |
| W2 |
Right front ground point at lamp unit |
3H |
| W2 |
Right front ground point at lamp unit |
30L |
| X26/31 |
Engine/engine compartment electrical connector |
3E |
| Y123 |
Left switchable engine mount |
12J |
| Y123/1 |
Right switchable engine mount |
12J |
| Y130 |
Engine oil pump valve |
17L |
| Y131 |
Oil spray nozzle shutoff valve |
36L |
| Y133 |
Coolant pump switchover valve |
37L |
| Y27/9 |
Exhaust gas recirculation actuator |
25L |
| Y31/5 |
Boost pressure control pressure transducer |
15L |
| Y74 |
Pressure regulator valve |
2L |
| Y77/1 |
Boost pressure control pressure transducer |
32L |
| Y93 |
Boost pressure control flap pressure transducer |
34L |
| Y94 |
Quantity control valve |
39L |
| Z203/3 |
Alternator LIN signal connector sleeve |
40G |
| Z6 |
Circuit 31 connector sleeve |
31G |
| Z6/25 |
Sensor voltage supply connector sleeve |
20G |
| Z6/25 |
Sensor voltage supply connector sleeve |
26G |
| Z6/28 |
Sensor ground connector sleeve |
22G |
| Z6/34 |
Sensor ground connector sleeve |
18G |
| Z7/47 |
Circuit 87D1 connector sleeve |
4G |
| Z7/48 |
Circuit 87D2 connector sleeve |
6G |
| Z7/5z1 |
Circuit 87 connector sleeve |
4C |
| Z7/5z1 |
Circuit 87 connector sleeve |
38G |
| Z7/5z2 |
Circuit 87 connector sleeve |
6C |
| Z7/5z2 |
Circuit 87 connector sleeve |
32E |
