| A0 |
Color code key |
56L |
| A2 |
Radio |
33L |
| A2/53 |
Mobile phone and stationary heater radio remote control antenna splitter |
15L |
| A2/56 |
Radio with auto pilot system |
41L |
| A28/11 |
Multifunction antenna |
10L |
| A28/11 |
Multifunction antenna |
12L |
| A28/11 |
Multifunction antenna |
25L |
| A28/13 |
Compensator/cellular telephone system UMTS |
19L |
| A40/3 |
COMAND control unit |
37L |
| A6 |
Stationary heater unit |
4A |
| A6 |
Stationary heater unit |
12A |
| A6 |
Stationary heater unit |
20A |
| A6 |
Stationary heater unit |
28A |
| A6 |
Stationary heater unit |
36A |
| A6 |
Stationary heater unit |
44A |
| A6/1 |
Stationary heater radio remote control receiver |
7L |
| A6b1 |
Stationary heater temperature sensor |
48A |
| A6f1 |
Stationary heater thermal fuse |
47A |
| A6m2 |
Stationary heater combustion air blower |
53C |
| A6n1 |
Stationary heater control unit |
5A |
| A6r4 |
Stationary heater glow plug/flame monitor unit |
51C |
| A6r5 |
Stationary heater fuel preheating system heating element |
46A |
| A6y1 |
Stationary heater switchover valve |
52C |
| CAN B |
Interior CAN |
45K |
| Code 386 |
Mobile phone |
12E |
| N10/2 |
Rear SAM control unit with fuse and relay module |
3L |
| N10/2 |
Rear SAM control unit with fuse and relay module |
29L |
| N10/2f73 |
Fuse 73 |
5L |
| N10/2f75 |
Fuse 75 |
2L |
| N10/2f82 |
Fuse 82 |
28L |
| U314 |
Valid for STH radio remote control |
5G |
| U501 |
Valid for xenon headlamps |
48D |
| U679 |
Valid for version without xenon headlamps |
48E |
| W16/4 |
Right wheelhouse ground point |
2E |
| W16/4 |
Right wheelhouse ground point |
47H |
| W7/1 |
Right taillamp trunk ground point |
6H |
| W7/1 |
Right taillamp trunk ground point |
19H |
| W7/1 |
Right taillamp trunk ground point |
50H |
| X30/33 |
Right vehicle floor interior CAN voltage distributor electrical connector |
45L |
| X39/37 |
Mobile phone electrical connector |
22L |
| X39/37 |
Mobile phone electrical connector |
24L |
| X62/33 |
Rear axle electrical connector, right distributor |
49H |
| Y16 |
Stationary heater switchover valve |
47L |
| Y23 |
Stationary heater fuel pump |
49L |
