| 1 |
Multifunction steering wheel button group, signal |
10H |
| 1 |
Multifunction steering wheel button group, signal |
8K |
| 1 |
Multifunction steering wheel button group, signal |
2J |
| 1 |
Multifunction steering wheel button group, signal |
2G |
| 10 |
Infrared, signal |
22D |
| 2 |
Switch-on request, signal |
17C |
| 2 |
Switch-on request, signal |
27D |
| 2 |
Switch-on request, signal |
27H |
| 3 |
Audio/COMAND controller, request |
10D |
| 3 |
Audio/COMAND controller, request |
9A |
| 4 |
Audio/COMAND display, signal |
13C |
| 4 |
Audio/COMAND display, signal |
15A |
| 5 |
FM antenna, signal |
19D |
| 5 |
FM antenna, signal |
20D |
| 5 |
FM antenna, signal |
27H |
| 5 |
FM antenna, signal |
13H |
| 5 |
FM antenna, signal |
14K |
| 5 |
FM antenna, signal |
13L |
| 5 |
FM antenna, signal |
19A |
| 6 |
DAB band III, signal |
29J |
| 6 |
DAB band III, signal |
30J |
| 6 |
DAB band III, signal |
29G |
| 7 |
Voice input, signal |
9D |
| 8 |
Audio, signal |
27D |
| 8 |
Audio, signal |
17H |
| 8 |
Audio, signal |
22F |
| 9 |
DAB, communication |
17H |
| 9 |
DAB, communication |
27H |
| A1 |
Instrument cluster |
10J |
| A2 |
Radio |
11E |
| A2/18 |
FM, AM and CL [ZV] antenna amplifier |
21B |
| A2/19 |
Rear window antenna FM antenna amplifier |
16J |
| A2/19 |
Rear window antenna FM antenna amplifier |
31G |
| A2/51 |
Rear spoiler antenna |
23B |
| A2/71 |
Rear window antenna amplifier 1 |
19B |
| A2/98 |
FM/TMC antenna splitter |
13J |
| A40/3 |
COMAND control unit |
17E |
| A40/8 |
Audio/COMAND display |
16A |
| A40/9 |
Audio/COMAND control panel |
6A |
| A67b1 |
Hands-free system microphone |
5C |
| A8/7 |
Remote control |
24D |
| A94/1 |
TV 1 antenna amplifier |
27K |
| A94/1 |
TV 1 antenna amplifier |
16L |
| A95/2 |
DAB band III antenna amplifier |
30K |
| CAN A |
Telematics CAN |
16D |
| CAN A |
Telematics CAN |
10D |
| CAN A |
Telematics CAN |
8B |
| CAN B |
Interior CAN |
10H |
| CAN E |
Chassis CAN |
5K |
| Code 255 |
AMG Performance Media |
9A |
| Code 508 |
Navigation module preinstallation |
12J |
| Code 509 |
Navigation module |
12J |
| Code 510 |
Audio 20 with CD changer |
8E |
| Code 512 |
COMAND APS with DVD changer |
15E |
| Code 512 |
COMAND APS with DVD changer |
4C |
| Code 527 |
COMAND APS |
15E |
| Code 527 |
COMAND APS |
4C |
| Code 810 |
Sound system |
28D |
| Code 867 |
SPLITVIEW |
21D |
| H8/3 |
Radio frequency headphones |
23F |
| LIN E1 |
Steering LIN |
2H |
| LVDS |
Low voltage differential signal |
13D |
| LVDS |
Low voltage differential signal |
14B |
| MOST |
Media Oriented System Transport |
22J |
| MOST |
Media Oriented System Transport |
26F |
| MOST |
Media Oriented System Transport |
22H |
| N125/3 |
AMG Performance Media control unit |
11A |
| N135 |
Steering wheel electronics |
2G |
| N40/3 |
Sound system amplifier control unit |
29D |
| N80 |
Steering column module control unit |
2J |
| N87/3 |
Digital Audio Broadcasting control unit |
29H |
| S110 |
Left multifunction steering wheel button group |
2D |
| S111 |
Right multifunction steering wheel button group |
3D |
| U545 |
Not valid for model 204.9 |
15J |
| U57 |
Valid for model 204.2 |
29K |
| U57 |
Valid for model 204.2 |
18B |
| U58 |
Valid for model 204.0 |
26K |
| U58 |
Valid for model 204.0 |
20B |
| U59 |
Valid for model 204.9 |
26K |
| U59 |
Valid for model 204.9 |
18B |
| U59 |
Valid for model 204.9 |
15K |
| U59 |
Valid for model 204.9 |
22B |
| U60 |
Valid for model 204.3 |
20B |
| U60 |
Valid for model 204.3 |
30F |
| X39/6 |
Headphones electrical connector (cabled) |
23G |
