| A0 |
Color code key |
64L |
| Code 494 |
USA version |
32H |
| Code 494 |
USA version |
12H |
| Code 494 |
USA version |
22H |
| Code 494 |
USA version |
40H |
| Code B03 |
ECO start/stop function |
1J |
| E1 |
Left front lamp unit |
7L |
| E1 |
Left front lamp unit |
11L |
| E1 |
Left front lamp unit |
29L |
| E1e1 |
Left high beam |
6L |
| E1e1 |
Left high beam |
26L |
| E1e2 |
Left low beam |
8L |
| E1e2 |
Left low beam |
27L |
| E1e3 |
Left front standing and parking lamp |
7L |
| E1e3 |
Left front standing and parking lamp |
27L |
| E1e5 |
Left front turn signal lamp |
6L |
| E1e5 |
Left front turn signal lamp |
26L |
| E1e6 |
Left front side-marker lamp |
33L |
| E1m1 |
Left headlamp range adjustment actuator motor |
11L |
| E1m1 |
Left headlamp range adjustment actuator motor |
31L |
| E2 |
Right front lamp unit |
19L |
| E2 |
Right front lamp unit |
35L |
| E2 |
Right front lamp unit |
38L |
| E2e1 |
Right high beam |
17L |
| E2e1 |
Right high beam |
35L |
| E2e2 |
Right low beam |
18L |
| E2e2 |
Right low beam |
36L |
| E2e3 |
Right front standing and parking lamp |
17L |
| E2e3 |
Right front standing and parking lamp |
35L |
| E2e5 |
Right front turn signal lamp |
16L |
| E2e5 |
Right front turn signal lamp |
34L |
| E2e6 |
Right front side-marker lamp |
42L |
| E2m1 |
Right headlamp range adjustment actuator motor |
21L |
| E2m1 |
Right headlamp range adjustment actuator motor |
39L |
| E6/1 |
Left front side-marker lamp |
14L |
| E6/2 |
Right front side-marker lamp |
24L |
| N10/1 |
Front SAM control unit with fuse and relay module |
12A |
| N10/1 |
Front SAM control unit with fuse and relay module |
4A |
| N10/1 |
Front SAM control unit with fuse and relay module |
20A |
| N10/1 |
Front SAM control unit with fuse and relay module |
28A |
| N10/1 |
Front SAM control unit with fuse and relay module |
36A |
| N10/1 |
Front SAM control unit with fuse and relay module |
44A |
| N10/1 |
Front SAM control unit with fuse and relay module |
52A |
| N10/1 |
Front SAM control unit with fuse and relay module |
59A |
| N10/1f29 |
Fuse 29 |
29A |
| N10/1f30 |
Fuse 30 |
23A |
| N10/1f5 |
Fuse 5 |
45A |
| N10/1kJ |
Circuit 15 relay |
24A |
| S1 |
Exterior lights switch |
47L |
| S1e4 |
Switch illumination |
47L |
| S1s10 |
Rear fog light button |
47K |
| S1s11 |
Front fog lamp button |
47J |
| S1s8 |
Headlamp range controller |
44K |
| U12 |
Valid for left-hand drive vehicles |
4H |
| U12 |
Valid for left-hand drive vehicles |
15H |
| U13 |
Valid for right-hand drive vehicles |
4H |
| U13 |
Valid for right-hand drive vehicles |
15H |
| U2 |
Valid for all except USA |
10H |
| U2 |
Valid for all except USA |
20H |
| U2 |
Valid for all except USA |
30H |
| U2 |
Valid for all except USA |
38H |
| U2 |
Valid for all except USA |
42G |
| U240 |
Valid for all except ECO start/stop function |
1J |
| U248 |
Valid for headlamp range adjustment for halogen headlamps |
10H |
| U248 |
Valid for headlamp range adjustment for halogen headlamps |
20H |
| U248 |
Valid for headlamp range adjustment for halogen headlamps |
30H |
| U248 |
Valid for headlamp range adjustment for halogen headlamps |
38H |
| U248 |
Valid for headlamp range adjustment for halogen headlamps |
43G |
| U255 |
Valid for front fog lamps |
52K |
| U57 |
Valid for model 204.2 |
4G |
| U58 |
Valid for model 204.0 |
5G |
| U59 |
Valid for model 204.9 |
25G |
| U60 |
Valid for model 204.3 |
5G |
| U971 |
Valid for daytime running lamps |
52K |
| W16/3 |
Left major assembly compartment ground point |
14H |
| W16/4 |
Right wheelhouse ground point |
20H |
| W16/4 |
Right wheelhouse ground point |
24H |
| W16/4 |
Right wheelhouse ground point |
38H |
| W9 |
Left front ground point (at lamp unit) |
10H |
| W9 |
Left front ground point (at lamp unit) |
29H |
| X18 |
Vehicle interior and harness for taillamp electrical connector |
48G |
| Z50/1 |
Circuit 58d instrument panel connector sleeve |
50G |
