| 1 |
Engine running, signal |
4E |
| 1 |
Engine running, signal |
6B |
| 1 |
Engine running, signal |
18G |
| 1 |
Engine running, signal |
16H |
| 10 |
Reverse gear, status |
4E |
| 11 |
Intelligent Light System, status |
6E |
| 11 |
Intelligent Light System, status |
16J |
| 12 |
Yaw rate, lateral and longitudinal acceleration sensor, signal |
4E |
| 12 |
Yaw rate, lateral and longitudinal acceleration sensor, signal |
8B |
| 12 |
Yaw rate, lateral and longitudinal acceleration sensor, signal |
19E |
| 12 |
Yaw rate, lateral and longitudinal acceleration sensor, signal |
27B |
| 13 |
Active curve illumination actuator motor, actuation |
1J |
| 13 |
Active curve illumination actuator motor, actuation |
9J |
| 14 |
Active curve illumination actuator motor, actuation |
4F |
| 14 |
Active curve illumination actuator motor, actuation |
6F |
| 15 |
Light distribution actuator motor, actuation |
1J |
| 15 |
Light distribution actuator motor, actuation |
9J |
| 16 |
Increase light output, request |
2L |
| 16 |
Increase light output, request |
8L |
| 17 |
Xenon bulb with integrated ignition module, actuation |
2K |
| 17 |
Xenon bulb with integrated ignition module, actuation |
8K |
| 18 |
Rear fog light button, status |
3E |
| 18 |
Rear fog light button, status |
16G |
| 18 |
Rear fog light button, status |
16K |
| 19 |
Automatic high beams function, status |
|
| 2 |
Drivetrain operational, signal |
4E |
| 2 |
Drivetrain operational, signal |
7B |
| 2 |
Drivetrain operational, signal |
19G |
| 2 |
Drivetrain operational, signal |
17H |
| 20 |
Exterior lights switch, status |
15K |
| 21 |
Ambient brightness, signal |
15E |
| 21 |
Ambient brightness, signal |
16G |
| 22 |
Automatic high beams enable, status |
|
| 22 |
Automatic high beams enable, status |
|
| 23 |
Optical headlamp range adjustment, status |
|
| 24 |
Automatic high beams, status |
5E |
| 24 |
Automatic high beams, status |
7F |
| 25 |
Offroad lights, status |
|
| 25 |
Offroad lights, status |
|
| 26 |
Off-Road package transmission mode controller, status |
3E |
| 26 |
Off-Road package transmission mode controller, status |
17G |
| 26 |
Off-Road package transmission mode controller, status |
18J |
| 3 |
Wheel speed, signal |
7B |
| 3 |
Wheel speed, signal |
13F |
| 3 |
Wheel speed, signal |
18E |
| 4 |
Vehicle speed, signal |
6E |
| 5 |
Steering wheel angle, signal |
3E |
| 5 |
Steering wheel angle, signal |
7B |
| 5 |
Steering wheel angle, signal |
18E |
| 5 |
Steering wheel angle, signal |
18A |
| 6 |
Combination switch, status |
3E |
| 6 |
Combination switch, status |
18D |
| 6 |
Combination switch, status |
20A |
| 6 |
Combination switch, status |
17H |
| 7 |
Cornering illumination, request |
2G |
| 7 |
Cornering illumination, request |
8G |
| 8 |
Cornering illumination, actuation |
2J |
| 8 |
Cornering illumination, actuation |
8J |
| 9 |
Gear range, status |
19G |
| 9 |
Gear range, status |
26K |
| A1 |
Instrument cluster |
11E |
| A1e3 |
High beam indicator lamp |
10D |
| A1p13 |
Multifunction display |
12E |
| A40/11 |
Multifunction camera |
5A |
| B24/15 |
Yaw rate sensor for lateral and longitudinal acceleration |
30B |
| CAN B |
Interior CAN |
17H |
| CAN B |
Interior CAN |
12J |
| CAN C |
Drive train CAN |
25L |
| CAN E1 |
Chassis CAN 1 |
17D |
| CAN E1 |
Chassis CAN 1 |
23F |
| CAN E1 |
Chassis CAN 1 |
23F |
| CAN E2 |
Chassis CAN 2 |
8F |
| CAN E2 |
Chassis CAN 2 |
5D |
| CAN E2 |
Chassis CAN 2 |
11B |
| CAN E2 |
Chassis CAN 2 |
14F |
| CAN E2 |
Chassis CAN 2 |
11A |
| CAN E2 |
Chassis CAN 2 |
2C |
| CAN H |
Vehicle dynamics CAN |
28C |
| Code 430 |
On-road/off-road package |
19K |
| Code 494 |
USA version |
25H |
| E1 |
Left front lamp unit |
6H |
| E1e10 |
Left xenon bulb with integrated ignition module |
7K |
| E1e9 |
Left cornering illumination |
7J |
| E1m2 |
Left active curve illumination actuator motor |
8J |
| E1m3 |
Left light distribution actuator motor |
8K |
| E1n4 |
Left xenon light power supply module |
7L |
| E1n7 |
Actuation module for left front exterior lights LED |
7H |
| E2 |
Right front lamp unit |
3H |
| E2e10 |
Right xenon bulb with integrated ignition module |
2K |
| E2e9 |
Right cornering illumination |
2J |
| E2m2 |
Right active curve illumination actuator motor |
1J |
| E2m3 |
Right light distribution actuator motor |
1K |
| E2n4 |
Right xenon light power supply module |
2L |
| E2n7 |
Actuation module for right front exterior lights LED |
2H |
| LIN B12 |
Center console switch LIN |
18K |
| LIN G1 |
Left headlamp LIN |
7G |
| LIN G1 |
Left headlamp LIN |
6G |
| LIN G1 |
Left headlamp LIN |
7F |
| LIN G2 |
Right headlamp LIN |
3G |
| LIN G2 |
Right headlamp LIN |
3G |
| LIN G2 |
Right headlamp LIN |
3F |
| N10 |
SAM control unit |
17J |
| N3/10 |
ME-SFI [ME] control unit |
30H |
| N3/9 |
CDI control unit |
24H |
| N3/9 |
CDI control unit |
27H |
| N30/4 |
Electronic Stability Program control unit |
25B |
| N49 |
Steering wheel angle sensor |
17A |
| N71/1 |
Headlamp control unit |
5E |
| N72/3 |
Off-Road operating panel control unit |
20K |
| N72/3s1 |
Off-Road package transmission mode controller |
19L |
| N73 |
Electronic ignition switch control unit |
17E |
| N80 |
Steering column module control unit |
19A |
| S1 |
Exterior lights switch |
14K |
| S1s10 |
Rear fog light button |
12K |
| S4 |
Combination switch |
21A |
| U1018 |
Valid for gasoline engine 276 |
29J |
| U1032 |
Valid for engine 278 and 157 |
29J |
| U175 |
Valid for all except {{USA}} and {{Canada}} |
2J |
| U175 |
Valid for all except {{USA}} and {{Canada}} |
7J |
| U2 |
Valid for all except USA |
22J |
| U2 |
Valid for all except USA |
22J |
| U74 |
Valid for diesel engines |
22G |
| U75 |
Valid for gasoline engines |
28G |
| U880 |
Valid for engine 642 |
22J |
| U948 |
Valid for diesel engine 651 |
22J |
| U948 |
Valid for diesel engine 651 |
22J |
| U948 |
Valid for diesel engine 651 |
25J |
| U948 |
Valid for diesel engine 651 |
25J |
| Y3/8n4 |
Fully integrated transmission control unit |
20H |
