| 1 |
Central locking, status |
11G |
| 10 |
Exit and warning lamp, request |
6G |
| 10 |
Exit and warning lamp, request |
6D |
| 11 |
Exit and warning lamp, actuation |
3J |
| 11 |
Exit and warning lamp, actuation |
3B |
| 11 |
Exit and warning lamp, actuation |
3C |
| 12 |
Tailgate rotary tumbler switch, status |
12E |
| 12 |
Tailgate rotary tumbler switch, status |
25J |
| 13 |
Anti-theft alarm system, status |
12E |
| 14 |
Ambient lamp, request |
27G |
| 15 |
Ambient lamp, actuation |
29H |
| 16 |
Illuminated door sill molding, request |
27G |
| 17 |
Illuminated door sill molding actuation |
28G |
| 18 |
Load compartment illumination, actuation |
3E |
| 19 |
Liftgate control button symbol illumination, actuation |
28K |
| 2 |
Circuit 15, status |
11G |
| 3 |
Crash, signal |
11K |
| 3 |
Crash, signal |
11H |
| 4 |
Interior lamp, request |
15C |
| 5 |
Rear dome lamp, actuation |
21C |
| 5 |
Rear dome lamp, actuation |
23C |
| 5 |
Rear dome lamp, actuation |
19C |
| 5 |
Rear dome lamp, actuation |
25D |
| 6 |
Footwell lamp, actuation |
21G |
| 6 |
Footwell lamp, actuation |
18G |
| 6 |
Footwell lamp, actuation |
13G |
| 6 |
Footwell lamp, actuation |
21K |
| 6 |
Footwell lamp, actuation |
18K |
| 6 |
Footwell lamp, actuation |
16G |
| 6 |
Footwell lamp, actuation |
23G |
| 7 |
OFF delay time, status |
10D |
| 7 |
OFF delay time, status |
27G |
| 8 |
Automatic function switch, status |
11D |
| 9 |
Door rotary tumbler switch, status |
9F |
| 9 |
Door rotary tumbler switch, status |
9D |
| A1 |
Instrument cluster |
10A |
| CAN B |
Interior CAN |
7F |
| CAN B |
Interior CAN |
10H |
| CAN B |
Interior CAN |
19F |
| CAN B |
Interior CAN |
7E |
| CAN B |
Interior CAN |
10C |
| CAN B |
Interior CAN |
19E |
| CAN B |
Interior CAN |
26F |
| CAN B |
Interior CAN |
26E |
| CAN E1 |
Chassis CAN 1 |
12K |
| Code 551 |
Anti-theft alarm system (ATA [EDW]) |
28A |
| Code 876 |
Interior lights package |
20J |
| Code 876 |
Interior lights package |
29F |
| Code 876 |
Interior lights package |
17J |
| Code 876 |
Interior lights package |
1C |
| Code 876 |
Interior lights package |
25C |
| Code 890 |
Tailgate control |
28J |
| E15/12 |
Left dome lamp, 2nd seat row |
22C |
| E15/13 |
Right dome lamp, 2nd seat row |
24D |
| E15/3 |
Rear dome lamp |
26D |
| E15/3e3 |
Rear interior lamp |
26D |
| E15/4 |
Central load compartment dome lamp |
20C |
| E17/15 |
Right front footwell lamp |
12H |
| E17/16 |
Left front footwell lamp |
12H |
| E17/17 |
Left rear footwell lamp |
21L |
| E17/17 |
Left rear footwell lamp |
24H |
| E17/18 |
Right rear footwell lamp |
18L |
| E17/18 |
Right rear footwell lamp |
15H |
| E17/3 |
Left front door exit and warning lamp |
2K |
| E17/4 |
Right front door exit and warning lamp |
2K |
| E17/47 |
Left front illuminated door sill molding |
29G |
| E17/48 |
Right front illuminated door sill molding |
29G |
| E17/5 |
Left rear door exit and warning lamp |
2B |
| E17/5 |
Left rear door exit and warning lamp |
2D |
| E17/6 |
Right rear door exit and warning lamp |
2C |
| E17/6 |
Right rear door exit and warning lamp |
2E |
| E18/1 |
Load compartment lamp |
2E |
| E40 |
Tailgate ambient lamp |
30J |
| LIN B13 |
Roof LIN |
12C |
| M14/7 |
Tailgate central locking motor |
23J |
| M14/7s1 |
Tailgate rotary tumbler switch |
23J |
| N10 |
SAM control unit |
10D |
| N10/8 |
Rear control unit |
27H |
| N2/10 |
Supplemental restraint system control unit |
14J |
| N26/6 |
ATA [EDW]/towing sensor/interior motion sensor control unit |
30B |
| N32/1 |
Driver seat control unit |
18G |
| N32/2 |
Front passenger seat control unit |
21G |
| N69/1 |
Left front door control unit |
5H |
| N69/2 |
Right front door control unit |
5H |
| N69/3 |
Left rear door control unit |
5A |
| N69/4 |
Right rear door control unit |
5A |
| N70 |
Overhead control panel control unit |
16B |
| N70e4 |
Left front interior lamp |
14A |
| N70e5 |
Right front interior lamp |
18A |
| N70s3 |
Interior lamp automatic function switch |
16A |
| N73 |
Electronic ignition switch control unit |
10J |
| S62/36 |
Tailgate control button |
29L |
| S62/36e1 |
Liftgate control button symbol illumination |
29L |
| U1037 |
Valid for vehicle model designation 166.0 |
20J |
| U1037 |
Valid for vehicle model designation 166.0 |
17J |
| U1037 |
Valid for vehicle model designation 166.0 |
1C |
| U1038 |
Valid for vehicle model designation 166.8 |
1A |
| U1038 |
Valid for vehicle model designation 166.8 |
25C |
| U1038 |
Valid for vehicle model designation 166.8 |
1E |
| U1038 |
Valid for vehicle model designation 166.8 |
14G |
| U1038 |
Valid for vehicle model designation 166.8 |
24G |
