| A0 |
Color code key |
64L |
| A93/3 |
Left 2nd seat row release unit |
39L |
| A93/3 |
Left 2nd seat row release unit |
51L |
| A93/4 |
Right 2nd seat row release unit |
13L |
| A93/4 |
Right 2nd seat row release unit |
18L |
| Code 293 |
Left and right rear sidebag |
25A |
| Code 293 |
Left and right rear sidebag |
58A |
| Code 843 |
Electric EASY-ENTRY |
9G |
| Code 843 |
Electric EASY-ENTRY |
40G |
| Code 872 |
Left and right rear seat heaters |
1A |
| Code 872 |
Left and right rear seat heaters |
31A |
| F4 |
Rear fuse box |
16L |
| F4 |
Rear fuse box |
45L |
| F4f107 |
Fuse 107 |
15L |
| F4f107 |
Fuse 107 |
44L |
| M53/12 |
Left 2nd seat row head restraint motor |
36L |
| M53/13 |
Center 2nd seat row head restraint motor |
38L |
| M53/14 |
Right 2nd seat row head restraint motor |
6L |
| N10 |
SAM control unit |
22A |
| N10 |
SAM control unit |
55A |
| N10/8 |
Rear control unit |
4A |
| N10/8 |
Rear control unit |
12A |
| N10/8 |
Rear control unit |
19A |
| N10/8 |
Rear control unit |
33A |
| N10/8 |
Rear control unit |
52A |
| N10/8 |
Rear control unit |
44A |
| N2/10 |
Supplemental restraint system control unit |
28A |
| N2/10 |
Supplemental restraint system control unit |
61A |
| R12/11 |
Left rear sidebag squib |
60L |
| R12/12 |
Right rear sidebag squib |
27L |
| R13/5 |
Left rear seat sitting surface heated cushion |
32L |
| R13/6 |
Left rear backrest heated cushion |
34L |
| R13/7 |
Right rear seat sitting surface heated cushion |
3L |
| R13/8 |
Right rear backrest heater pad |
4L |
| S159/1 |
Right 2nd seat row easy entry/exit switch |
11L |
| S159/1x1 |
Right 2nd seat row easy entry/exit switch electrical connector |
10K |
| S159/1x1 |
Right 2nd seat row easy entry/exit switch electrical connector |
41K |
| S159/2 |
Left 2nd seat row easy entry/exit switch |
42L |
| S162/1 |
Left 2nd seat row folding backrest switch |
53L |
| S162/2 |
Right 2nd seat row folding backrest switch |
20L |
| S68/14 |
Center rear seat belt buckle switch |
49L |
| S68/14x1 |
Center rear seat belt buckle switch electrical connector |
49K |
| S68/5 |
Left rear seat belt buckle switch |
48L |
| S68/5x1 |
Left rear seat belt buckle switch electrical connector |
47K |
| S68/6 |
Right rear seat belt buckle switch |
8L |
| S68/6x1 |
Right rear seat belt buckle switch electrical connector |
8K |
| U155 |
Valid for 166.8 |
1A |
| U155 |
Valid for 166.8 |
31A |
| U158 |
Valid for 3rd seat row |
26A |
| U158 |
Valid for 3rd seat row |
60A |
| U481 |
Valid for rear seat belt status indication |
9G |
| U481 |
Valid for rear seat belt status indication |
40G |
| W17 |
Right rear seat ground point |
11C |
| W17 |
Right rear seat ground point |
28D |
| W17/1 |
Left rear seat ground point |
42C |
| W17/1 |
Left rear seat ground point |
61D |
| X55/5 |
Left rear seat adjustment unit connector block |
47F |
| X55/5 |
Left rear seat adjustment unit connector block |
32F |
| X55/6 |
Right rear seat adjustment connector block |
2F |
| X55/6 |
Right rear seat adjustment connector block |
17F |
| Z51/6 |
Circuit 58d vehicle interior connector sleeve |
21D |
| Z51/6 |
Circuit 58d vehicle interior connector sleeve |
54D |
| Z61/12 |
Left circuit 31 2nd seat row connector sleeve |
41H |
| Z61/13 |
Right circuit 31 2nd seat row connector sleeve |
10H |
| Z61/22 |
Left 2nd seat row seat heater ground line connector sleeve |
34H |
| Z61/23 |
Right 2nd seat row seat heater ground line connector sleeve |
4H |
