| 1 |
Gear range, status |
7F |
| 2 |
Air conditioning, status |
6E |
| 2 |
Air conditioning, status |
10A |
| B11/4 |
Coolant temperature sensor |
2C |
| B17/8 |
Charge air temperature sensor |
7H |
| B28/7 |
Pressure sensor downstream of throttle valve actuator |
5K |
| CAN B |
Interior CAN |
11B |
| CAN C |
Drive train CAN |
8F |
| CAN C |
Drive train CAN |
7D |
| L5 |
Crankshaft position sensor |
4J |
| M16/6 |
Throttle valve actuator |
5D |
| N15/3 |
ETC [EGS] control unit |
9F |
| N22/1 |
AAC [KLA] control unit |
14A |
| N3/10 |
ME-SFI [ME] control unit |
4E |
| N92/1 |
ECI ignition module, right cylinder bank |
3H |
| N92/2 |
ECI ignition module, left cylinder bank |
3H |
| N93 |
Central gateway control unit |
8A |
| R4 |
Spark plugs |
1J |
| Y62y1 |
Cylinder 1 fuel injection valve |
1E |
| Y62y10 |
Cylinder 10 fuel injection valve |
1G |
| Y62y11 |
Cylinder 11 fuel injection valve |
1G |
| Y62y12 |
Cylinder 12 fuel injection valve |
1H |
| Y62y2 |
Cylinder 2 fuel injection valve |
1E |
| Y62y3 |
Cylinder 3 fuel injection valve |
1E |
| Y62y4 |
Cylinder 4 fuel injection valve |
1F |
| Y62y5 |
Cylinder 5 fuel injection valve |
1F |
| Y62y6 |
Cylinder 6 fuel injection valve |
1F |
| Y62y7 |
Cylinder 7 fuel injection valve |
1F |
| Y62y8 |
Cylinder 8 fuel injection valve |
1G |
| Y62y9 |
Cylinder 9 fuel injection valve |
1G |
