| A16/5 |
Knock sensor 1 |
1L |
| A16/5x1 |
Knock sensor connector 1 |
1J |
| A16/6 |
Knock sensor 2 |
3L |
| A16/6x1 |
Knock sensor connector 2 |
3J |
| B11/17 |
Coolant temperature sensor |
14L |
| B16/13 |
Temperature sensor upstream of turbocharger |
32L |
| B16/13x1 |
Temperature sensor connector upstream of turbocharger |
32J |
| B17/13 |
Charge air temperature sensor |
34L |
| B2/12 |
Hot film mass air flow sensor |
27L |
| B28/17 |
Intake manifold pressure sensor |
41L |
| B4/16 |
Rail pressure sensor |
36L |
| B40/6 |
Engine oil level sensor |
29L |
| B40/9 |
Engine oil temperature sensor |
13L |
| B5/6 |
Boost pressure sensor |
37L |
| B5/9 |
Low-pressure turbocharger boost pressure sensor |
42L |
| B50/5 |
Fuel temperature sensor |
33L |
| B6/23 |
Camshaft sensor |
31L |
| B60/3 |
Exhaust back pressure sensor |
39L |
| F55/1 |
Fuse block (9 fuses) |
59L |
| F55/1f5 |
Fuse 5 (7.5/10 A) motors circuit 87 (5) |
58K |
| F55/1f6 |
Fuse 6 (7.5/10 A) motors circuit 87 (6) |
59K |
| F57 |
Starter/alternator fuse (300 A) |
64L |
| F59 |
Fuse box |
74L |
| F59.1 |
Tml. 30 preglow relay/secondary air injection pump fuse (80/40 A) |
73K |
| G2/7 |
Alternator with LIN bus |
66L |
| K40/9 |
Fuse/relay box (SRB) |
56L |
| L5/10 |
Crankshaft sensor |
4L |
| M16/45 |
Throttle valve actuator |
16L |
| M72/1 |
Intake port shutoff actuator |
19L |
| N14/8 |
Glow output stage |
67A |
| N14/8 |
Glow output stage |
73A |
| N3/28 |
CDI control unit |
4A |
| N3/28 |
CDI control unit |
12A |
| N3/28 |
CDI control unit |
28A |
| N3/28 |
CDI control unit |
20A |
| N3/28 |
CDI control unit |
36A |
| N3/28 |
CDI control unit |
44A |
| N3/28 |
CDI control unit |
52A |
| N3/28 |
CDI control unit |
61A |
| R39/3 |
Vent line heater element |
25L |
| R48/2 |
Thermostat heating element |
7L |
| R53/3 |
Fuel filter heater with water level sensor |
72L |
| R9/1 |
Cylinder 1 glow plug |
68L |
| R9/2 |
Cylinder 2 glow plug |
69L |
| R9/3 |
Cylinder 3 glow plug |
70L |
| R9/4 |
Cylinder 4 glow plug |
70L |
| W11/1 |
Engine ground point |
73E |
| W2 |
Right front lamp unit ground point |
54L |
| X195 |
Glow plugs connector |
68H |
| X26/54 |
Engine wiring harness connector 2 |
74H |
| X26/55 |
Engine wiring harness connector 1 |
53H |
| Y127/1 |
Oil spray nozzles valve |
12L |
| Y133 |
Regulated oil pressure pump valve |
62L |
| Y19/10 |
Coolant pump switchover valve |
9L |
| Y27/15 |
Exhaust gas recirculation positioner |
23L |
| Y27/16 |
Exhaust gas recirculation cooling solenoid valve |
6L |
| Y74/5 |
Pressure regulator valve |
52L |
| Y76/14 |
Cylinder 1 injector |
47L |
| Y76/15 |
Cylinder 2 injector |
45L |
| Y76/16 |
Cylinder 3 injector |
44L |
| Y76/17 |
Cylinder 4 injector |
46L |
| Y77/6 |
Boost pressure positioner |
50L |
| Y77/7 |
Waste gate pressure transducer |
10L |
| Y93/1 |
Boost pressure control flap pressure transducer |
48L |
| Y94/3 |
Quantity control valve |
61L |
| Z203/3 |
Connector sleeve / LIN bus |
66E |
| Z6/113 |
Ground connector sleeve |
51G |
| Z6/118 |
Sensor ground connector sleeve |
39G |
| Z6/119 |
Sensor ground connector sleeve |
13G |
| Z6/119 |
Sensor ground connector sleeve |
29G |
| Z6/120 |
Sensor ground connector sleeve |
33E |
| Z6/121 |
Sensor ground connector sleeve |
21G |
| Z7/106 |
5V output connector sleeve |
38G |
| Z7/107 |
5V output connector sleeve |
22E |
| Z7/109 |
Tml. 87 connector sleeve |
11G |
| Z7/109 |
Tml. 87 connector sleeve |
49G |
| Z7/109 |
Tml. 87 connector sleeve |
48G |
| Z7/109 |
Tml. 87 connector sleeve |
62G |
| Z7/109 |
Tml. 87 connector sleeve |
58E |
| Z7/110 |
Tml. 87 connector sleeve |
25G |
| Z7/110 |
Tml. 87 connector sleeve |
6E |
| Z7/110 |
Tml. 87 connector sleeve |
55E |
| Z7/110 |
Tml. 87 connector sleeve |
67E |
