| A26/1 |
Driver door IR receiver |
5L |
| E17/10 |
Front passenger entrance/exit lamp |
12L |
| E17/10 |
Front passenger entrance/exit lamp |
16L |
| E17/9 |
Driver entrance/exit lamp |
10L |
| E17/9 |
Driver entrance/exit lamp |
14L |
| F55/1 |
Fuse block (9 fuses) |
2L |
| F55/1f1 |
Fuse 1 (25 A), driver door control unit |
1K |
| F55/3 |
Fuse block (9 fuses) |
39L |
| F55/3f1 |
Fuse 1 (5 A), mirror adjustment, heated rear window relay |
39K |
| M10/1 |
Driver door power window motor |
3L |
| M14/6 |
Driver door ZV actuator |
7L |
| M21/6 |
Driver-side outside mirror |
50L |
| M21/6 |
Driver-side outside mirror |
55L |
| M21/7 |
Passenger-side outside mirror |
26L |
| N10 |
SAM control unit |
33L |
| N69/1 |
Driver door control unit |
4A |
| N69/1 |
Driver door control unit |
12A |
| N69/1 |
Driver door control unit |
20A |
| N69/1 |
Driver door control unit |
28A |
| N69/1 |
Driver door control unit |
37A |
| N69/1 |
Driver door control unit |
44A |
| N69/1 |
Driver door control unit |
50A |
| S47 |
Driver door control panel |
41L |
| S47 |
Driver door control panel |
47L |
| U70 |
Valid for USA, Canada |
35H |
| U72 |
Valid for all except USA, Canada |
4G |
| U72 |
Valid for all except USA, Canada |
35H |
| W43/1 |
Left firewall ground point |
17H |
| W71/1 |
Driver seat frame ground point 1 |
2H |
| X141/4 |
Driver-side outside mirror connector |
52H |
| X141/5 |
Passenger-side outside mirror connector |
22H |
| X30/24 |
Interior CAN bus connector |
36L |
| X34/35 |
Driver entrance/exit lamp connector |
9J |
| X34/35 |
Driver entrance/exit lamp connector |
13J |
| X34/36 |
Front passenger entrance/exit lamp connector |
11J |
| X34/36 |
Front passenger entrance/exit lamp connector |
15J |
| X35/1 |
Driver door/MWH connector 1 |
32H |
| X35/2 |
Front passenger door connector |
13F |
| X35/41 |
Driver door/MWH connector 2 |
1E |
| X35/43 |
Driver door/MWH connector 3 |
13D |
| Z36/22 |
Rear Parktronic warning element power supply connector sleeve |
18G |
| Z36/22 |
Rear Parktronic warning element power supply connector sleeve |
52E |
| Z36/23 |
Rear Parktronic warning element ground connector sleeve |
19G |
| Z36/23 |
Rear Parktronic warning element ground connector sleeve |
53E |
| Z36/24 |
Rear Parktronic warning element signal connector sleeve |
21G |
| Z36/24 |
Rear Parktronic warning element signal connector sleeve |
54E |
| Z82/15 |
Driver door ZV connector sleeve |
7G |
