| A99/1 |
Right electric step |
23L |
| A99/1 |
Right electric step |
49L |
| A99/1m1 |
Step motor |
24L |
| A99/1m1 |
Step motor |
50L |
| A99/1s1 |
Step "Retracted" switch |
22L |
| A99/1s1 |
Step "Retracted" switch |
48L |
| A99/1s2 |
Step "Extended" switch |
23L |
| A99/1s2 |
Step "Extended" switch |
48L |
| A99/1s3 |
Anti-pinch protection switch |
23L |
| A99/1s3 |
Anti-pinch protection switch |
49L |
| A99/2 |
Left electric step |
10L |
| A99/2 |
Left electric step |
35L |
| A99/2m1 |
Step motor |
11L |
| A99/2m1 |
Step motor |
36L |
| A99/2s1 |
Step "Retracted" switch |
8L |
| A99/2s1 |
Step "Retracted" switch |
34L |
| A99/2s2 |
Step "Extended" switch |
9L |
| A99/2s2 |
Step "Extended" switch |
35L |
| A99/2s3 |
Anti-pinch protection switch |
9L |
| A99/2s3 |
Anti-pinch protection switch |
35L |
| F55/4 |
Fuse block (9 fuses) |
2L |
| F55/4f8 |
Fuse 17 (25 A), PSM |
1K |
| F55/4f9 |
Fuse 18 (25 A), PSM |
2K |
| F55/7 |
Fuse block (9 fuses) |
16L |
| F55/7 |
Fuse block (9 fuses) |
29L |
| F55/7 |
Fuse block (9 fuses) |
42L |
| F55/7 |
Fuse block (9 fuses) |
55L |
| F55/7f7 |
Fuse 43 (10 A), right electric step |
29K |
| F55/7f7 |
Fuse 43 (10 A), right electric step |
55K |
| F55/7f8 |
Fuse 44 (10 A), left electric step |
15K |
| F55/7f8 |
Fuse 44 (10 A), left electric step |
41K |
| F55/7f9 |
Fuse 45 (5 A), electric step control |
17K |
| F55/7f9 |
Fuse 45 (5 A), electric step control |
42K |
| F55/7f9 |
Fuse 45 (5 A), electric step control |
56K |
| H13/3 |
Right step warning buzzer |
60L |
| H13/4 |
Left step warning buzzer |
21L |
| H13/4 |
Left step warning buzzer |
46L |
| K117/1 |
Right step relay 1 |
32L |
| K117/1 |
Right step relay 1 |
58L |
| K117/2 |
Right step relay 2 |
27L |
| K117/2 |
Right step relay 2 |
52L |
| K117/3 |
Left step relay 1 |
19L |
| K117/3 |
Left step relay 1 |
44L |
| K117/4 |
Left step relay 2 |
13L |
| K117/4 |
Left step relay 2 |
39L |
| N26/15 |
PSM control unit |
12A |
| N26/15 |
PSM control unit |
4A |
| N26/15 |
PSM control unit |
20A |
| N26/15 |
PSM control unit |
28A |
| N26/15 |
PSM control unit |
36A |
| N26/15 |
PSM control unit |
44A |
| N26/15 |
PSM control unit |
52A |
| N26/15 |
PSM control unit |
60A |
| U84 |
Valid for right load compartment sliding door electric step |
8A |
| U84 |
Valid for right load compartment sliding door electric step |
47A |
| U85 |
Valid for left load compartment sliding door electric step |
8A |
| U85 |
Valid for left load compartment sliding door electric step |
34A |
| W71/1 |
Driver seat frame ground point 1 |
5E |
| W71/2 |
Driver seat frame ground point 2 |
10H |
| W71/2 |
Driver seat frame ground point 2 |
14H |
| W71/2 |
Driver seat frame ground point 2 |
20H |
| W71/2 |
Driver seat frame ground point 2 |
24H |
| W71/2 |
Driver seat frame ground point 2 |
28H |
| W71/2 |
Driver seat frame ground point 2 |
33H |
| W71/2 |
Driver seat frame ground point 2 |
36H |
| W71/2 |
Driver seat frame ground point 2 |
40H |
| W71/2 |
Driver seat frame ground point 2 |
45H |
| W71/2 |
Driver seat frame ground point 2 |
49H |
| W71/2 |
Driver seat frame ground point 2 |
54H |
| W71/2 |
Driver seat frame ground point 2 |
59H |
| X30/24 |
Interior CAN bus connector |
5L |
| X30/39 |
PSM control unit CAN-B preinstallation connector |
7L |
| Z227/1 |
Right step connector sleeve |
24E |
| Z227/1 |
Right step connector sleeve |
50E |
| Z227/2 |
Left step connector sleeve |
10E |
| Z227/2 |
Left step connector sleeve |
36E |
| Z7/142 |
Left step tml. 30 connector sleeve |
16G |
