| A0 |
Color code key |
96L |
| E15/63 |
Right passenger compartment overhead control panel reading spotlight 1 |
31L |
| E15/63 |
Right passenger compartment overhead control panel reading spotlight 1 |
43L |
| E15/63 |
Right passenger compartment overhead control panel reading spotlight 1 |
54L |
| E15/63 |
Right passenger compartment overhead control panel reading spotlight 1 |
66L |
| E15/63 |
Right passenger compartment overhead control panel reading spotlight 1 |
78L |
| E15/63 |
Right passenger compartment overhead control panel reading spotlight 1 |
89L |
| E15/64 |
Right passenger compartment overhead control panel reading spotlight 2 |
32L |
| E15/64 |
Right passenger compartment overhead control panel reading spotlight 2 |
44L |
| E15/64 |
Right passenger compartment overhead control panel reading spotlight 2 |
56L |
| E15/64 |
Right passenger compartment overhead control panel reading spotlight 2 |
67L |
| E15/64 |
Right passenger compartment overhead control panel reading spotlight 2 |
79L |
| E15/64 |
Right passenger compartment overhead control panel reading spotlight 2 |
91L |
| E15/65 |
Blue LED ambiance lamp, right passenger compartment grab handle |
14L |
| E15/65 |
Blue LED ambiance lamp, right passenger compartment grab handle |
16L |
| E15/65 |
Blue LED ambiance lamp, right passenger compartment grab handle |
18L |
| E15/65 |
Blue LED ambiance lamp, right passenger compartment grab handle |
20L |
| E15/65 |
Blue LED ambiance lamp, right passenger compartment grab handle |
22L |
| F55/61 |
Fuse block 6, Arobus (9 fuses) |
3A |
| F55/61f5 |
Electrical fuse 32, reading lamps |
3B |
| H4/98 |
Right passenger compartment overhead control panel speaker |
23L |
| H4/98 |
Right passenger compartment overhead control panel speaker |
35L |
| H4/98 |
Right passenger compartment overhead control panel speaker |
47L |
| H4/98 |
Right passenger compartment overhead control panel speaker |
59L |
| H4/98 |
Right passenger compartment overhead control panel speaker |
70L |
| H4/98 |
Right passenger compartment overhead control panel speaker |
82L |
| K15/62 |
Passenger compartment overhead control panel reading lamps relay |
5L |
| S15/66 |
Right passenger compartment overhead control panel reading spotlight 1 button |
34L |
| S15/66 |
Right passenger compartment overhead control panel reading spotlight 1 button |
45L |
| S15/66 |
Right passenger compartment overhead control panel reading spotlight 1 button |
57L |
| S15/66 |
Right passenger compartment overhead control panel reading spotlight 1 button |
69L |
| S15/68 |
Right passenger compartment overhead control panel speaker button |
25L |
| S15/68 |
Right passenger compartment overhead control panel speaker button |
37L |
| S15/68 |
Right passenger compartment overhead control panel speaker button |
49L |
| S15/68 |
Right passenger compartment overhead control panel speaker button |
60L |
| S15/68 |
Right passenger compartment overhead control panel speaker button |
72L |
| S15/68 |
Right passenger compartment overhead control panel speaker button |
84L |
| S15/69 |
Right passenger compartment overhead control panel "Service" button |
28L |
| S15/69 |
Right passenger compartment overhead control panel "Service" button |
39L |
| S15/69 |
Right passenger compartment overhead control panel "Service" button |
51L |
| S15/69 |
Right passenger compartment overhead control panel "Service" button |
63L |
| S15/69 |
Right passenger compartment overhead control panel "Service" button |
75L |
| S15/69 |
Right passenger compartment overhead control panel "Service" button |
86L |
| W71/1 |
Driver seat frame ground point 1 |
4H |
| W71/1 |
Driver seat frame ground point 1 |
28A |
| X145/1 |
Body manufacturer electrical connector |
2L |
| X15/60 |
Left passenger compartment overhead control panel electrical connector |
37H |
| X15/60 |
Left passenger compartment overhead control panel electrical connector |
48H |
| X15/60 |
Left passenger compartment overhead control panel electrical connector |
60H |
| X15/60 |
Left passenger compartment overhead control panel electrical connector |
72H |
| X15/60 |
Left passenger compartment overhead control panel electrical connector |
83H |
| X15/61 |
Left passenger compartment stowage compartment electrical connector |
8H |
| X15/62 |
Ambiance illumination button electrical connector |
9H |
| X15/63 |
Left passenger compartment ambiance illumination electrical connector |
11H |
| X15/64 |
Right passenger compartment stowage compartment electrical connector |
14E |
| X15/65 |
Right passenger compartment ambiance illumination electrical connector |
12H |
| X15/69 |
Right passenger compartment overhead control panel electrical connector |
25H |
