| A0 |
Color code key |
96L |
| Code BA9 |
Preinstallation for rail vehicle/veh. with interaxle differential lock |
63G |
| Code BB9 |
|
80A |
| Code EK1 |
Terminal strip for electrical connection |
75G |
| Code H72 |
Electric roof ventilator |
72G |
| Code MA4 |
Low-emission vehicle Euro 5b+ Gr. III |
41G |
| Code MA6 |
Low-emission vehicle, Euro 6 Gr. III |
41J |
| Code MB6 |
Low-emission vehicle, Euro 6 Gr. 1 |
41J |
| Code MH3 |
Low-emission engine EPA 13/CARB |
8F |
| Code MH5 |
Low-emission engine EPA 14/CARB |
8F |
| Code MH7 |
Low-emission engine EPA 16/CARB |
8G |
| Code MP6 |
Euro VI engine version |
41H |
| Code MP6 |
Euro VI engine version |
45G |
| Code MS0 |
Radiator fan, electric |
53G |
| Code MZ2 |
Natural gas engine M271 |
29F |
| Code MZ2 |
Natural gas engine M271 |
33F |
| Code MZ2 |
Natural gas engine M271 |
35E |
| Code ZU7 |
Canada national version |
2A |
| Code ZU8 |
USA national version |
2A |
| F55/1 |
Fuse block (1, 9-pin) |
4A |
| F55/1 |
Fuse block (1, 9-pin) |
12A |
| F55/1 |
Fuse block (1, 9-pin) |
27A |
| F55/1 |
Fuse block (1, 9-pin) |
35A |
| F55/1 |
Fuse block (1, 9-pin) |
51A |
| F55/1 |
Fuse block (1, 9-pin) |
43A |
| F55/1 |
Fuse block (1, 9-pin) |
19A |
| F55/1f5 |
Motors terminal 87 (5) fuse 5 |
4B |
| F55/1f5 |
Motors terminal 87 (5) fuse 5 |
25B |
| F55/1f6 |
Motors terminal 87 (6) fuse 6 |
5B |
| F55/1f6 |
Motors terminal 87 (6) fuse 6 |
26B |
| K23/3 |
Blower stage 2 fan relay |
69L |
| K27 |
Fuel pump relay |
34L |
| K40/9 |
Fuse and relay module |
19L |
| K40/9 |
Fuse and relay module |
37L |
| K40/9 |
Fuse and relay module |
51L |
| K40/9 |
Fuse and relay module |
66L |
| K40/9 |
Fuse and relay module |
82L |
| K40/9 |
Fuse and relay module |
90L |
| K41 |
Circuit 15 relief relay |
71L |
| K41/3 |
Circuit 15 relief relay 2 |
73L |
| K88 |
Body manufacturer circuit 15 relay |
76L |
| M91 |
Electric fan |
54L |
| N118/5 |
Fuel pump control unit |
66A |
| N28/1 |
Trailer connection unit [AAG] control unit |
90A |
| N28/1 |
Trailer connection unit [AAG] control unit |
90A |
| N28/4 |
Trailer recognition control unit |
90A |
| N3/28 |
CDI control unit |
43L |
| N3/29 |
ME-SFI [ME] control unit |
30L |
| N3/29 |
ME-SFI [ME] control unit |
57L |
| N3/33 |
CDI control unit |
15L |
| N3/35 |
CDI control unit |
15L |
| N3/35 |
CDI control unit |
16L |
| N3/35 |
CDI control unit |
47L |
| N30/4 |
ESP® control unit |
83A |
| S9/1 |
Stop lamp switch |
78L |
| S9/1 |
Stop lamp switch |
93L |
| S9/3 |
Stop lamp switch |
85L |
| U15 |
Valid for vehicles without ESP |
86A |
| U211 |
|
77G |
| U72 |
Valid for all except USA, Canada |
21A |
| U72 |
Valid for all except USA, Canada |
87B |
| U72 |
Valid for all except USA, Canada |
65H |
| U72 |
Valid for all except USA, Canada |
81H |
| U72 |
Valid for all except USA, Canada |
88H |
| X190 |
Rail vehicle electrical connector |
64L |
| X26/44 |
Engine wiring harness electrical connector |
61H |
| X26/47 |
Engine wiring harness electrical connector |
59H |
| X26/61 |
Engine wiring harness electrical connector |
2H |
| X26/61 |
Engine wiring harness electrical connector |
12H |
| X26/61 |
Engine wiring harness electrical connector |
23H |
| X26/61 |
Engine wiring harness electrical connector |
40H |
| X26/65 |
Engine wiring harness electrical connector 4 |
5H |
| X26/65 |
Engine wiring harness electrical connector 4 |
26H |
| Y27/13 |
Exhaust gas recirculation cooling solenoid valve |
10L |
| Y94/3 |
Quantity control valve |
28L |
| Z3/65 |
Tml. 15 connector sleeve |
66E |
| Z7/108 |
Circuit 87 connector sleeve |
7L |
| Z7/109 |
Circuit 87 connector sleeve |
6L |
| Z7/109 |
Circuit 87 connector sleeve |
26L |
| Z7/112 |
Circuit 87 connector sleeve, ignition coils |
59L |
| Z7/157 |
Circuit 87 (1) connector sleeve |
4L |
| Z7/157 |
Circuit 87 (1) connector sleeve |
25L |
| Z7/158 |
Circuit 87 (2) connector sleeve |
3L |
| Z7/158 |
Circuit 87 (2) connector sleeve |
24L |
| Z7/164 |
Circuit 87 (3) connector sleeve |
12L |
| Z7/164 |
Circuit 87 (3) connector sleeve |
40L |
| Z7/76 |
Circuit 87 connector sleeve |
18E |
| Z7/76 |
Circuit 87 connector sleeve |
50E |
| Z7/77 |
Circuit 87 connector sleeve |
19G |
| Z7/77 |
Circuit 87 connector sleeve |
51F |
| Z7/93 |
Circuit 87 connector sleeve |
61L |
| Z94 |
Stop lamp switch connector sleeve |
82E |
| Z94 |
Stop lamp switch connector sleeve |
90E |
