| AO |
Color code key |
168L |
| A32/1 |
Rear heater/air conditioner air recirculation unit |
24L |
| A32/1 |
Rear heater/air conditioner air recirculation unit |
20L |
| A32/1 |
Rear heater/air conditioner air recirculation unit |
32L |
| A32/1a1 |
Rear heater blower regulator |
21K |
| A32/1a1 |
Rear heater blower regulator |
26K |
| A32/1a1 |
Rear heater blower regulator |
33K |
| A32/1m2 |
Rear heater water valve motor |
19K |
| A32/1m2 |
Rear heater water valve motor |
24K |
| A32/1m2 |
Rear heater water valve motor |
31K |
| A32/1r1 |
Rear heater water valve potentiometer |
24K |
| A32/1r1 |
Rear heater water valve potentiometer |
20K |
| A32/1H |
Rear heater water valve potentiometer |
32K |
| A32/2 |
Rear automatic air conditioning air recirculation unit |
109L |
| A32/2a1 |
Blower regulator |
111L |
| A32/2b1 |
Evaporator temperature sensor |
108L |
| A32/2m2 |
Blending air flap actuator motor |
109L |
| A32/2r2 |
Blend air flap potentiometer |
110L |
| A32/2y1 |
Refrigerant shutoff valve |
|
| A9/7 |
2nd refrigerant compressor |
28L |
| B12/6 |
Roof refrigerant pressure sensor |
105L |
| B27/1 |
Motion detector |
114L |
| Code BR9 |
|
59A |
| Code EN6 |
Audio 10 |
3A |
| Code EN6 |
Audio 10 |
143A |
| Code EN7 |
Audio 15 |
3A |
| Code EN7 |
Audio 15 |
143A |
| Code ERO |
Radio preinstallation |
8A |
| Code ERO |
Radio preinstallation |
137A |
| Code EV3 |
|
37A |
| Code FY9 |
|
161A |
| Code H08 |
Uprated roof air conditioner |
22A |
| Code H08 |
Uprated roof air conditioner |
100A |
| Code H11 |
Warm air auxiliary heater |
115F |
| Code H13 |
Additional heat exchanger in passenger/load compartment |
17A |
| Code H13 |
Additional heat exchanger in passenger/load compartment |
22A |
| Code H13 |
Additional heat exchanger in passenger/load compartment |
29A |
| Code H13 |
Additional heat exchanger in passenger/load compartment |
100A |
| Code H18 |
|
29A |
| Code HH2 |
Electric auxiliary air heater |
17A |
| Code HH2 |
Electric auxiliary air heater |
22B |
| Code HH2 |
Electric auxiliary air heater |
100B |
| Code HH7 |
|
22B |
| Code HH7 |
|
100B |
| Code HH9 |
Semi-automatic air conditioning, TEMPMATIC |
22B |
| Code HH9 |
Semi-automatic air conditioning, TEMPMATIC |
29B |
| Code HH9 |
Semi-automatic air conditioning, TEMPMATIC |
100B |
| Code JW3 |
Shutoff for backup warning system |
87A |
| Code L71 |
Cargo area illumination via motion detector |
113D |
| Code LB7 |
|
90F |
| Code LD4 |
Load/passenger compartment comfort illumination |
113H |
| Code M53 |
Constant rpm control |
68J |
| Code M53 |
Constant rpm control |
76B |
| Code M53 |
Constant rpm control |
80C |
| Code M53 |
Constant rpm control |
80B |
| Code MT4 |
Variable electronic rpm regulator |
68J |
| Code MT4 |
Variable electronic rpm regulator |
76A |
| Code MT4 |
Variable electronic rpm regulator |
80C |
| Code MT4 |
Variable electronic rpm regulator |
80B |
| Code MW1 |
Engine run-on control (MWS) |
131A |
| Code MW1 |
Engine run-on control (MWS) |
65A |
| Code N05 |
Countershaft power take-off (2c) without flange |
66J |
| Code N05 |
Countershaft power take-off (2c) without flange |
73J |
| Code N05 |
Countershaft power take-off (2c) without flange |
72A |
| Code N07 |
Countershaft power take-off (2b) with flange |
66J |
| Code N07 |
Countershaft power take-off (2b) with flange |
73J |
| Code N07 |
Countershaft power take-off (2b) with flange |
72B |
| Code P57 |
|
42A |
| Code PB2 |
VMC retarder master code |
59A |
| Code T16 |
Right sliding door |
155D |
| Code T19 |
Left sliding door |
148D |
| Code ZG1 |
All-wheel drive, engageable |
124F |
| Code ZG3 |
Engageable all-wheel drive with gear reduction |
126F |
| Code ZK4 |
Mixto |
95A |
| Code ZU1 |
Minibus |
1H |
| Code ZU1 |
Minibus |
7H |
| Code ZU7 |
Canada national version |
80A |
| Code ZU8 |
USA national version |
80A |
| E15/3 |
Rear dome lamp |
15L |
| E15/3 |
Rear dome lamp |
96L |
| E15/32 |
Rear load compartment lamp |
15L |
| E15/32 |
Rear load compartment lamp |
98L |
| El 6/11 |
Retarder indicator lamp |
64A |
| E42/1 |
Left front rotating beacon |
93L |
| E42/2 |
Right rear rotating beacon |
91L |
| F55/1 |
Fuse block (1, 9-pin) |
53L |
| F55/1f5 |
Motors terminal 87 (5) fuse 5 |
51K |
| F55/2 |
Fuse block 2 (9-pin) |
116A |
| F55/2f4 |
Air heater timer/FleetBoard fuse 13 |
119B |
| F55/2f8 |
Motion detector/comfort illumination fuse 17 |
114B |
| F55/3 |
Fuse block 3 (9-pin) |
48L |
| F55/3f8 |
Terminal 15 dumper vehicle/cargo liftgate/PARKTRONIC electrical fuse 8 |
47K |
| H4/3 |
Left rear side wall speaker |
6L |
| H4/4 |
Right rear side wall speaker |
13L |
| H4/44 |
Right rear side wall tweeter |
11L |
| H4/45 |
Left rear side wall tweeter |
5L |
| H4/79 |
Left sliding door tweeter |
153L |
| H4/80 |
Right sliding door tweeter |
159L |
| H4/83 |
Left sliding door bass midrange speaker |
154L |
| H4/84 |
Right sliding door bass midrange speaker |
160L |
| H4/89 |
Left rear end tweeter |
2L |
| H4/90 |
Right rear end tweeter |
8L |
| H4/91 |
Left rear end bass and mid-range speaker |
4L |
| H4/92 |
Right rear end bass and mid-range speaker |
10L |
| K121 |
Backup warning system OFF relay |
89L |
| K23/2 |
Blower stage 1 fan relay |
35L |
| K23/3 |
Blower stage 2 fan relay |
36L |
| K9/5 |
Roof additional fan relay |
103L |
| K95 |
Cargo lift gate relay |
39L |
| M88 |
All-wheel drive actuator motor |
129A |
| N10 |
SAM control unit |
15A |
| N10 |
SAM control unit |
97A |
| N118/2 |
CNG interface control unit |
57L |
| N133 |
All-wheel drive control unit |
125A |
| N26/15 |
Parameterizable special module (PSM) control unit |
62L |
| N26/15 |
Parameterizable special module (PSM) control unit |
71L |
| N26/15 |
Parameterizable special module (PSM) control unit |
83L |
| N26/15 |
Parameterizable special module (PSM) control unit |
134A |
| N34 |
Heater timer |
117L |
| N69/5 |
KEYLESS-ENTRY & SLIDE control unit |
163L |
| N73 |
Electronic ignition lock (EZS) control unit |
133L |
| N87/8 |
Radio/radio with navigation |
5A |
| N87/8 |
Radio/radio with navigation |
146A |
| S157/1 |
Rotating beacon switch |
93A |
| S161 |
Power take-off switch |
74A |
| S1 61/1 |
Working speed control ON switch |
78A |
| S1 61/1 |
Working speed control ON switch |
85A |
| S1 61/2 |
Power take-off limit switch |
74L |
| S162 |
Working speed control button |
68A |
| S162 |
Working speed control button |
81A |
| S165 |
Dumper vehicle switch |
44A |
| S167 |
Cargo lift gate switch |
40A |
| S191/1 |
Selector lever retarder switch |
62A |
| S191/1x1 |
Selector lever retarder switch electrical connector |
60D |
| S193 |
Gas/gasoline selection switch |
52A |
| S194 |
KEYLESS-ENTRY & SLIDE button |
163A |
| S198 |
Engine run-on button |
136L |
| S199 |
Backup warning system OFF button |
88A |
| S76/11 |
All-wheel drive engagement button |
125L |
| S76/12 |
All-wheel drive gear ratio button |
129L |
| S98 |
AC control and operating unit |
20A |
| S98 |
AC control and operating unit |
26A |
| S98 |
AC control and operating unit |
33A |
| S98 |
AC control and operating unit |
103A |
| S98 |
AC control and operating unit |
107A |
| U200 |
Valid without code N05 (Countershaft power take-off (2c) without flange) |
68J |
| U200 |
Valid without code N05 (Countershaft power take-off (2c) without flange) |
76B |
| U200 |
Valid without code N05 (Countershaft power take-off (2c) without flange) |
80D |
| U200 |
Valid without code N05 (Countershaft power take-off (2c) without flange) |
80B |
| U201 |
Valid without code N07 (Countershaft power take-off (2b) with flange) |
68J |
| U201 |
Valid without code N07 (Countershaft power take-off (2b) with flange) |
76B |
| U201 |
Valid without code N07 (Countershaft power take-off (2b) with flange) |
80D |
| U201 |
Valid without code N07 (Countershaft power take-off (2b) with flange) |
80B |
| U202 |
Valid without code M53 (Constant rpm control) |
66J |
| U202 |
Valid without code M53 (Constant rpm control) |
73J |
| U202 |
Valid without code M53 (Constant rpm control) |
72B |
| U203 |
Valid without code MT4 (Variable electronic rpm regulator) |
66J |
| U203 |
Valid without code MT4 (Variable electronic rpm regulator) |
73J |
| U203 |
Valid without code MT4 (Variable electronic rpm regulator) |
72B |
| U30 |
Valid for long cab version |
14G |
| U31 |
Valid for panel van version with head liner |
14G |
| U31 |
Valid for panel van version with head liner |
113H |
| U32 |
Valid for MPV version |
14H |
| U32 |
Val id for MPV version |
113H |
| U34 |
Valid for panel van version without head liner |
14H |
| U72 |
Valid for all except USA, Canada |
42A |
| U72 |
Valid for all except USA, Canada |
65A |
| U72 |
Valid for all except USA, Canada |
106H |
| U72 |
Valid for all except USA, Canada |
90A |
| W29/8 |
Left D-pillar ground point |
90H |
| W38 |
Roof ground point |
93H |
| X100/14 |
Right sliding door electrical connector |
155J |
| X100/16 |
Left sliding door electrical connector |
149J |
| X100/19 |
Right sliding door electrical connector (8-pin) |
155H |
| X100/2 |
MWH [HLS]/right sliding door electrical connector |
155H |
| X100/21 |
Left sliding door electrical connector (8-pin) |
149H |
| X100/4 |
MWH [HLS]/Ieft sliding door electrical connector |
149H |
| X167 |
Dumper vehicle electrical connector |
44L |
| X168 |
Cargo liftgate electrical connector |
40L |
| X178 |
Front roof electrical connector |
121L |
| X18/23 |
Cockpit and roof electrical connector |
3E |
| X18/51 |
Cockpit and roof electrical connector 2 |
14E |
| X18/55 |
MWH [HLS]/cockpit electrical connector 3 |
18F |
| X18/60 |
MWH [HLS]/cockpit electrical connector 4 |
123E |
| X18/64 |
MWH [HLS]/cockpit electrical connector 5 |
149E |
| X18/74 |
Cockpit and roof electrical connector 4 |
95E |
| X18/74 |
Cockpit and roof electrical connector 4 |
92E |
| X18/75 |
Cockpit and roof electrical connector 5 |
102E |
| X26/44 |
Engine wiring harness electrical connector |
27H |
| X26/61 |
Engine wiring harness electrical connector |
27J |
| X26/65 |
Engine wiring harness electrical connector 4 |
27J |
| X35/108 |
Actuator/left sliding door central locking electrical connector (8-pin) |
149J |
| X35/109 |
Actuator/right sliding door central locking electrical connector (8-pin) |
155J |
| X39/67 |
Radio preinstallation electrical connector |
10A |
| X39/67 |
Radio preinstallation electrical connector |
140A |
| X64/14 |
Roof double auxiliary fan electrical connector |
102H |
| Y113 |
Power take-off solenoid valve |
67L |
| Z103/8 |
Interior lights ON connector sleeve |
98G |
| Z103/9 |
Interior lights/contact switch (door) connector sleeve |
95G |
| Z129 |
Dumper vehicle connector sleeve |
45D |
| Z129/2 |
Dumper vehicle connector sleeve |
45H |
| Z221/1 |
2nd refrigerant compressor connector sleeve |
28D |
| Z223 |
Retarder connector sleeve |
64H |
| Z28/1 |
Left rear speaker connector sleeve (signal +) |
3G |
| Z28/2 |
Left rear speaker connector sleeve |
5G |
| Z28/3 |
Right rear speaker connector sleeve |
9G |
| Z28/4 |
Right rear speaker connector sleeve |
11G |
| Z28/76 |
Left sliding door speaker connector sleeve |
152G |
| Z28/77 |
Left sliding door speaker connector sleeve |
154G |
| Z28/78 |
Right sliding door speaker connector sleeve |
159G |
| Z28/79 |
Right sliding door speaker connector sleeve |
160G |
| Z28/80 |
Left sliding door/rear end speaker connector sleeve |
141E |
| Z28/81 |
Left sliding door/rear end speaker connector sleeve |
142E |
| Z28/82 |
Right sliding door/rear end speaker connector sleeve |
143E |
| Z28/83 |
Right sliding door/rear end speaker connector sleeve |
144E |
| Z3/63 |
Working speed control (ADR) circuit 15 connector sleeve |
71C |
| Z3/63 |
Working speed control (ADR) circuit 15 connector sleeve |
83C |
| Z47/15 |
Rotating beacon connector sleeve |
92G |
| Z6/112 |
Temperature sensor ground connection connector sleeve |
109G |
| Z7/117 |
Circuit 87 connector sleeve |
51H |
