| A2/101 |
Keyless Entry right sliding door antenna |
43L |
| A2/102 |
Keyless Entry left sliding door antenna |
33L |
| A2/103 |
Keyless Entry driver door antenna |
21L |
| A2/104 |
Keyless Entry front passenger door antenna |
9L |
| B48/7 |
Airbag system driver door pressure sensor |
18L |
| El 7/10 |
Front passenger entrance/exit lamp |
12L |
| F55/1 |
Fuse block (9 fuses) |
53A |
| F55/1f1 |
Fuse 1 (25 A), driver door control unit |
53B |
| H4/25 |
Bass mi drange speaker |
57L |
| H4/26 |
Bass mi drange speaker |
59L |
| M10/2 |
Front passenger door power window motor |
65L |
| M14/5 |
Front passenger door ZV actuator |
6L |
| M21/7 |
Passenger-side outside mirror |
27L |
| N10 |
SAM control unit |
5A |
| N10 |
SAM control unit |
65A |
| N2/15 |
Highline airbag control unit |
16A |
| N69/1 |
Driver door control unit |
15L |
| N69/1 |
Driver door control unit |
54L |
| N69/5 |
Keyless Entry control unit |
10A |
| N69/5 |
Keyless Entry control unit |
21A |
| N69/5 |
Keyless Entry control unit |
32A |
| N69/5 |
Keyless Entry control unit |
42A |
| N69/6 |
Right sliding door control unit |
45L |
| N69/7 |
Left sliding door control unit |
35L |
| N87/1 |
Radio/radio with navigation |
57A |
| N87/6 |
Radio/radio with navigation NG |
57A |
| S159/1 |
Right sliding door button |
51L |
| S159/2 |
Left s sliding door button |
41L |
| S166/3 |
Left rear-end door switch |
39L |
| S166/4 |
Right rear-end door switch |
49L |
| S21/2 |
Front passenger power window switch |
4L |
| S47 |
Driver door control panel |
23L |
| U1 |
Valid for left-hand drive vehicles |
8B |
| U1 |
Valid for left-hand drive vehicles |
19B |
| U2 |
Valid for right-hand drive vehicles |
8B |
| U2 |
Valid for right-hand drive vehicles |
19B |
| U72 |
Valid for all except USA, Canada |
8A |
| U72 |
Valid for all except USA, Canada |
19A |
| U72 |
Valid for all except USA, Canada |
30A |
| W26 |
Ground point (airbag) |
19A |
| W43/1 |
Left firewall ground point |
12A |
| W71/1 |
Driver seat frame ground point 1 |
53E |
| X100/13 |
Right sliding door connector |
42H |
| X100/15 |
Left s sliding door connector |
32H |
| X100/2 |
HLS/right sliding door connector |
42E |
| X100/4 |
HLS/left sliding door connector |
32E |
| X141/5 |
Passenger-side outside mirror connector |
25H |
| X18/49 |
HLS/COC connector 2 |
56G |
| X18/49 |
HLS/COC connector 2 |
56G |
| X18/56 |
HLS/COC connector |
1E |
| X18/69 |
HLS/roof connector |
39E |
| X18/69 |
HLS/roof connector |
49E |
| X30/26 |
Interior CAN bus connector |
35A |
| X30/26 |
Interior CAN bus connector |
45A |
| X34/36 |
Front passenger entrance/exit lamp connector |
12H |
| X35/2 |
Front passenger door connector |
3E |
| X35/41 |
Driver door/MWH connector 2 |
52J |
| X35/42 |
Front passenger door connector |
59J |
| X35/43 |
Driver door/MWH connector 3 |
14H |
| X39/67 |
Radio preinstallation connector |
60A |
| X8/21 |
Right roof/rear-end door connector |
49H |
| X8/22 |
Left roof/rear-end door connector |
39H |
| Z28/68 |
Left cockpit speaker connector sleeve |
56E |
| Z28/69 |
Left cockpit speaker connector sleeve |
58E |
| Z28/70 |
Right cockpit speaker connector sleeve |
59E |
| Z28/71 |
Right cockpit speaker connector sleeve |
60E |
| Z78/5 |
Right closing assist connector sleeve |
45F |
| Z78/6 |
Left closing assist connector sleeve |
35F |
| Z81/5 |
Tml. 58d connector sleeve |
1G |
| Z82/16 |
Front passenger door ZV connector sleeve |
6G |
