| A9 |
Refrigerant compressor |
3L |
| A9 |
Refrigerant compressor |
22L |
| A9 |
Refrigerant compressor |
31L |
| A9 |
Refrigerant compressor |
53L |
| A9 |
Refrigerant compressor |
46L |
| A9 |
Refrigerant compressor |
71L |
| A9/7 |
2nd refrigerant compressor |
9L |
| A9/7 |
2nd refrigerant compressor |
24L |
| A9/7 |
2nd refrigerant compressor |
33L |
| A9/7 |
2nd refrigerant compressor |
55L |
| A9/7 |
2nd refrigerant compressor |
73L |
| B4/7 |
Fuel pressure sensor |
79L |
| B76 |
Fuel filter water level sensor |
15L |
| F55/1 |
Fuse block (9 fuses) |
27A |
| F55/1 |
Fuse block (9 fuses) |
48A |
| F55/1 |
Fuse block (9 fuses) |
63A |
| F55/1f5 |
Fuse 5 (7.5/10 A) motors circuit 87 (5) |
26B |
| F55/1f5 |
Fuse 5 (7.5/10 A) motors circuit 87 (5) |
48B |
| F55/1f5 |
Fuse 5 (7.5/10 A) motors circuit 87 (5) |
62B |
| F55/1f6 |
Fuse 6 (7.5/10 A) motors circuit 87 (6) |
27B |
| F55/1f6 |
Fuse 6 (7.5/10 A) motors circuit 87 (6) |
48B |
| F55/1f6 |
Fuse 6 (7.5/10 A) motors circuit 87 (6) |
64B |
| F79 |
Fuse (20 A)/fuel filter heater |
30A |
| F79 |
Fuse (20 A)/fuel filter heater |
52A |
| G2/2 |
Alternator |
10L |
| G2/8 |
Alternator |
44L |
| K40/9 |
Fuse/relay box (SRB) |
12A |
| K40/9 |
Fuse/relay box (SRB) |
16A |
| K40/9 |
Fuse/relay box (SRB) |
36A |
| K40/9 |
Fuse/relay box (SRB) |
39A |
| K40/9 |
Fuse/relay box (SRB) |
57A |
| K40/9 |
Fuse/relay box (SRB) |
76A |
| M1 |
Starter |
13L |
| M1 |
Starter |
16L |
| M1 |
Starter |
36L |
| M1 |
Starter |
38L |
| M1 |
Starter |
58L |
| M1 |
Starter |
77L |
| N118/5 |
Fuel pump control unit |
79A |
| N3/20 |
CDI control unit |
7L |
| N3/20 |
CDI control unit |
7L |
| N3/21 |
CDI control unit |
6L |
| N30/4 |
ESP control unit |
66A |
| R39/1 |
Vent line heater element |
11L |
| R53 |
Fuel filter heater with water level sensor |
29L |
| R53 |
Fuel filter heater with water level sensor |
51L |
| R53/1 |
Fuel filter heater with water level sensor |
51L |
| S98 |
AAC [KLA] control and operating unit |
5A |
| S98 |
AAC [KLA] control and operating unit |
23A |
| S98 |
AAC [KLA] control and operating unit |
32A |
| S98 |
AAC [KLA] control and operating unit |
45A |
| S98 |
AAC [KLA] control and operating unit |
54A |
| S98 |
AAC [KLA] control and operating unit |
72A |
| U60 |
Valid for CNG gaseous fuel engine |
41D |
| U64 |
Val id for engine 651 |
59A |
| U65 |
Valid for engine 642 (140 kW) |
59A |
| U70 |
Valid for USA, Canada |
5H |
| U70 |
Valid for USA, Canada |
50H |
| U72 |
Valid for all except USA, Canada |
5H |
| U72 |
Valid for all except USA, Canada |
5H |
| U72 |
Va Ii d for all except USA, Canada |
25A |
| U72 |
Valid for all except USA. Canada |
50H |
| W2 |
Right front lamp unit ground point |
67E |
| W9/6 |
Left front lamp unit ground point |
2E |
| W9/6 |
Left front lamp unit ground point |
28E |
| W9/6 |
Left front lamp unit ground point |
50E |
| W9/6 |
Left front lamp unit ground point |
69E |
| W9/7 |
Left front ground point 2 |
29E |
| W9/7 |
Left front ground point 2 |
51E |
| X18/55 |
HLS/COC connector 3 |
4E |
| X18/55 |
HLS/COC connector 3 |
24E |
| X18/55 |
HLS/COC connector 3 |
33E |
| X18/55 |
HLS/COC connector 3 |
43E |
| X18/55 |
HLS/COC connector 3 |
55E |
| X18/55 |
HLS/COC connector 3 |
73E |
| X18/56 |
HLS/COC connector |
3E |
| X18/56 |
HLS/COC connector |
4E |
| X18/56 |
HLS/COC connector |
21E |
| X18/56 |
HLS/COC connector |
30E |
| X18/56 |
HLS/COC connector |
43F |
| X18/56 |
HLS/COC connector |
45E |
| X18/56 |
HLS/COC connector |
53E |
| X18/56 |
HLS/COC connector |
70E |
| X26/38 |
Engine wiring harness connector |
1H |
| X26/44 |
Engine wiring harness connector |
15H |
| X26/46 |
Engine wiring harness connector 1 |
26H |
| X26/47 |
Engine wiring harness connector |
38H |
| X26/50 |
Engine wiring harness connector 1 |
47H |
| X26/55 |
Engine wiring harness connector 1 |
60H |
| X26/61 |
Engine wiring harness connector |
60H |
| Y10/2 |
Power steering pump ECO valve |
66L |
| Y74/5 |
Pressure regulator valve |
68L |
| Y77/8 |
Boost pressure positioner |
70L |
| Y94/3 |
Quantity control valve |
27L |
| Y94/3 |
Quantity control valve |
64L |
| Z221/1 |
2nd refrigerant compressor connector sleeve |
7D |
| Z221/1 |
2nd refrigerant compressor connector sleeve |
23D |
| Z221/1 |
2nd refrigerant compressor connector sleeve |
32D |
| Z221/1 |
2nd refrigerant compressor connector sleeve |
54D |
| Z221/1 |
2nd refrigerant compressor connector sleeve |
72D |
| Z3/64 |
Tml. 15 (fused) connector sleeve |
14L |
| Z6/113 |
Ground connector sleeve |
2L |
| Z6/113 |
Ground connector sleeve |
28L |
| Z6/113 |
Ground connector sleeve |
50L |
| Z6/113 |
Ground connector sleeve |
69L |
| Z6/113 |
Ground connector sleeve |
67L |
| Z7/109 |
Tml. 87 connector sleeve |
26L |
| Z7/109 |
Tml. 87 connector sleeve |
62L |
| Z7/110 |
Tml. 87 connector sleeve |
35L |
| Z7/110 |
Tml. 87 connector sleeve |
75L |
| Z7/112 |
Ignition coil tml. 87 connector sleeve |
40L |
| Z7/113 |
Injection valve tml. 87 connector sleeve |
41L |
| Z7/115 |
Sensor tml. 87 connector sleeve |
39L |
| Z7/117 |
Tml. 87 connector sleeve |
42E |
| Z7/123 |
Sensor tml. 87 connector sleeve |
48L |
| Z7/123 |
Sensor tml. 87 connector sleeve |
60L |
| Z7/124 |
Sensor tml. 87 connector sleeve |
49L |
| Z7/124 |
Sensor tml. 87 connector sleeve |
65L |
| Z7/157 |
Circuit 87 connector sleeve (1) |
65L |
| Z7/158 |
Circuit 87 connector sleeve (2) |
63L |
| Z7/164 |
Circuit 87 connector sleeve (3) |
60L |
| Z7/48 |
Tml. 87 connector sleeve |
12L |
| Z7/76 |
Tml. 87 connector sleeve |
60A |
| Z7/77 |
Tml. 87 connector sleeve |
11E |
| Z7/77 |
Tml. 87 connector sleeve |
18E |
| Z7/77 |
Tml. 87 connector sleeve |
40E |
| Z7/82 |
Tml. 87 connector sleeve |
19E |
| Z7/92 |
Tml. 87 connector sleeve |
19L |
| Z7/93 |
Tml. 87 connector sleeve |
18L |
| Z7/94 |
Tml. 87 connector sleeve |
20L |
| Z7/95 |
Tml. 87 connector sleeve |
21L |
| Z7/96 |
Tml. 87 connector sleeve |
17L |
| Z7/98 |
Tml. 87 connector sleeve |
17E |
| Z7/98 |
Tml. 87 connector sleeve |
39E |
