| A32/1 |
Rear heater/air conditioner air recirculation unit |
27L |
| A32/1a1 |
Rear heater blower regulator |
28L |
| A32/1m2 |
Rear heater water valve motor |
26L |
| A32/1r1 |
Rear heater water valve potentiometer |
27L |
| A9/7 |
2nd refrigerant compressor |
31L |
| A96 |
Backup camera monitor |
39A |
| B84/3 |
Backup camera |
39L |
| E15/3 |
Rear dome lamp |
11L |
| E15/32 |
Rear load compartment lamp |
13L |
| El 6/11 |
Retarder indicator lamp |
50L |
| F55/3 |
Fuse block (9 fuses) |
20L |
| F55/3f8 |
Fuse 8 (10 A), three-way dump truck/cargo lift gate tml. 15 |
20K |
| H4/3 |
Left rear side wall speaker |
4L |
| H4/4 |
Right rear side wall speaker |
8L |
| H4/44 |
Right rear side wall tweeter |
7L |
| H4/45 |
Left rear side wall tweeter |
3L |
| H4/81 |
Left side wall tweeter |
1L |
| H4/82 |
Right side wall tweeter |
5L |
| H4/85 |
Left side wall bass midrange speaker |
2L |
| H4/86 |
Right side wall bass midrange speaker |
6L |
| K121 |
Backup warning OFF relay |
34L |
| K23/2 |
Blower stage 1 fan relay |
59L |
| K23/3 |
Blower stage 2 fan relay |
61L |
| K95 |
Cargo lift gate relay |
22L |
| N10 |
SAM control unit |
12A |
| N118/2 |
CNG interface control unit |
55A |
| N26/15 |
PSM control unit |
44A |
| N26/15 |
PSM control unit |
51A |
| N87/6 |
Radio/radio with navigation NG |
3A |
| S161 |
PTO switch |
43L |
| S161/1 |
ADR ON switch |
45L |
| S161/2 |
Power take-off limit switch |
51L |
| S162 |
ADR button |
41L |
| S165 |
Three-way dump truck switch |
17A |
| S167 |
Cargo lift gate switch |
23A |
| SI 91/1 |
Selector lever retarder switch |
48L |
| SI 91/1xl |
Selector lever retarder switch connector |
47H |
| S193 |
Gas/gasoline selection switch |
56L |
| S199 |
Backup warning OFF button |
34A |
| S199 |
Backup warning OFF button |
36A |
| S98 |
AAC [KLA] control and operating unit |
29A |
| S98 |
AAC [KLA] control and operating unit |
60A |
| U30 |
Valid for long cab version |
10A |
| U31 |
Valid for panel van version with head liner |
10A |
| U32 |
Val id for MPV version |
10B |
| U34 |
Valid for panel van version without head liner |
10B |
| U53 |
Valid for vehicles with three-sided dumper |
14A |
| U54 |
Valid for cargo lift gate retrofit preinstallation |
21A |
| U55 |
Valid for rear heater/air conditioning |
25A |
| U55 |
Valid for rear heater/air conditioning |
58A |
| U60 |
Valid for CNG gaseous fuel engine |
53A |
| U72 |
Valid for all except USA, Canada |
14A |
| U72 |
Valid for all except USA, Canada |
42H |
| U72 |
Valid for all except USA, Canada |
41A |
| U72 |
Valid for all except USA, Canada |
46A |
| U72 |
Valid for all except USA, Canada |
53A |
| W1/3 |
CLS cockpit ground point 1 |
50G |
| W1/3 |
CLS cockpit ground point 1 |
54G |
| W9/7 |
Left front ground point 2 |
41D |
| X167 |
Three-way dump truck connector |
17L |
| X168 |
Cargo lift gate connector |
24L |
| X169 |
Backup camera connector |
39J |
| X170 |
Backup camera monitor connector |
39D |
| X18/23 |
COC/roof connector |
1G |
| X18/51 |
COC/roof connector 2 |
10E |
| X18/54 |
HLS/roof connector 3 |
37K |
| X18/55 |
HLS/COC connector 3 |
15E |
| X18/55 |
HLS/COC connector 3 |
43E |
| X18/55 |
HLS/COC connector 3 |
55E |
| X18/55 |
HLS/COC connector 3 |
59E |
| X26/38 |
Engine wiring harness connector |
29H |
| X26/44 |
Engine wiring harness connector |
31H |
| X26/50 |
Engine wiring harness connector 1 |
31H |
| X26/55 |
Engine wiring harness connector 1 |
31H |
| X39/67 |
Radio preinstallation connector |
6A |
| X97 |
Retarder connector |
53L |
| Y113 |
PTO solenoid valve |
42A |
| Z129 |
Three-way dump truck connector sleeve |
17D |
| Z129/2 |
Three-way dump truck connector sleeve |
20G |
| Z221/1 |
2nd refrigerant compressor connector sleeve |
31D |
| Z223 |
Retarder connector sleeve |
52E |
| Z28/1 |
Left rear speaker connector sleeve |
2H |
| Z28/2 |
Left rear speaker connector sleeve |
3H |
| Z28/3 |
Right rear speaker connector sleeve |
6H |
| Z28/4 |
Right rear speaker connector sleeve |
7H |
| Z28/80 |
Left sliding door/rear end speaker connector sleeve |
4E |
| Z28/81 |
Left sliding door/rear end speaker connector sleeve |
5E |
| Z28/82 |
Right sliding door/rear end speaker connector sleeve |
6E |
| Z28/83 |
Right sliding door/rear end speaker connector sleeve |
7E |
| Z3/63 |
ADR tml. 15 connector sleeve |
44G |
| Z3/69 |
Tml. 15 connector sleeve |
37G |
| Z38/2 |
Backup lamp connector sleeve |
34G |
| Z7/117 |
Tml. 87 connector sleeve |
56A |
| Z81/5 |
Tml. 58d connector sleeve |
57G |
