| A2/18 |
Antenna amplifier |
19L |
| B25/15 |
Hands-free system microphone LHD |
13L |
| B25/16 |
Hands-free system microphone RHD |
13L |
| F55/2 |
Fuse block (9 fuses) |
2L |
| F55/2f2 |
Fuse 11 (7.5 A), mobile phone, tachograph |
1K |
| H4/27 |
Center front speaker |
10L |
| H4/33 |
Left front door tweeter |
8L |
| H4/34 |
Right front door tweeter |
12L |
| N123/5 |
Bluetooth hands-free system radio preinstallation |
12A |
| N123/5 |
Bluetooth hands-free system radio preinstallation |
4A |
| N123/5 |
Bluetooth hands-free system radio preinstallation |
18A |
| U70 |
Valid for USA, Canada |
14G |
| U72 |
Valid for all except USA, Canada |
14G |
| W1/3 |
CLS cockpit ground point 1 |
2E |
| X30/25 |
Interior CAN bus connector |
16L |
| X39/67 |
Radio preinstallation connector |
5L |
| Z28/68 |
Left cockpit speaker connector sleeve |
3G |
| Z28/69 |
Left cockpit speaker connector sleeve |
4G |
| Z28/70 |
Right cockpit speaker connector sleeve |
5G |
| Z28/71 |
Right cockpit speaker connector sleeve |
6G |
| Z28/86 |
Left cockpit speaker connector sleeve |
8G |
| Z28/87 |
Left cockpit speaker connector sleeve |
9G |
| Z28/88 |
Right cockpit speaker connector sleeve |
11G |
| Z28/89 |
Right cockpit speaker connector sleeve |
12G |
