| A2/18 |
Antenna amplifier |
24L |
| A2/91 |
Bluetooth antenna |
30L |
| A28/7 |
HF switch antenna splitter |
28L |
| A34/18 |
Mobile phone bracket with Bluetooth module |
13L |
| B25/15 |
Hands-free system microphone LHD |
10L |
| F55/2 |
Fuse block (9 fuses) |
2L |
| F55/2f1 |
Fuse 10 (15/20 A), radio |
1K |
| M4/12 |
Radio additional fan |
21L |
| N87/6 |
Radio/radio with navigation NG |
3A |
| N87/6 |
Radio/radio with navigation NG |
11A |
| N87/6 |
Radio/radio with navigation NG |
20A |
| N87/6 |
Radio/radio with navigation NG |
28A |
| W1/3 |
CLS cockpit ground point 1 |
2E |
| X30/25 |
Interior CAN bus connector |
4L |
| X37/2 |
Antenna splitter connector |
25H |
| X39/45 |
AUX connection connector |
19L |
| Z28/84 |
Radio additional fan connector sleeve |
22E |
