| E3/6 |
Left taillamp |
12L |
| E4/6 |
Right taillamp |
10L |
| F55/1 |
Fuse block (9 fuses) |
2L |
| F55/1f9/1 |
Fuse 9 (10 A), additional turn signal module |
2K |
| F55/4 |
Fuse block (9 fuses) |
2L |
| F55/4f4 |
Fuse 13 (10 A), additional turn signal module |
2K |
| N10 |
SAM control unit |
5L |
| N10 |
SAM control unit |
9L |
| N9/1 |
Additional turn signal module |
4A |
| N9/1 |
Additional turn signal module |
12A |
| U29 |
Valid for short cab version |
7H |
| U30 |
Valid for long cab version |
7H |
| W52/7 |
Left rear crossmember ground point |
13H |
| W71/1 |
Driver seat frame ground point 1 |
4E |
| W71/3 |
Driver seat frame ground point 3 |
3F |
| X52/10 |
Right rear additional turn signal lamps connector |
14L |
| X52/9 |
Left rear additional turn signal lamps connector |
13L |
| Z30/13 |
Left turn signal indicator connector sleeve |
8G |
| Z30/14 |
Right turn signal indicator connector sleeve |
9G |
