| E19/1 |
Left license plate lamp |
36L |
| E19/2 |
Right license plate lamp |
35L |
| E21 |
Center high-mounted stop lamp |
20L |
| E3 |
Left tai1 lamp |
3L |
| E3/6 |
Left tail lamp |
46L |
| E3/6e1 |
Turn signal lamp |
47L |
| E3/6e2 |
Tail lamp |
44L |
| E3/6e3 |
Backup lamp |
48L |
| E3/6e4 |
Stop lamp |
45L |
| E3/6e5 |
Rear fog lamp |
46L |
| E3/6e6 |
Side-marker lamp |
45L |
| E3e1 |
Turn signal lamp |
4L |
| E3e2 |
Tail lamp |
1L |
| E3e3 |
Backup lamp |
3L |
| E3e4 |
Stop lamp |
2L |
| E3e5 |
Rear fog lamp |
2L |
| E4 |
Right tail lamp |
17L |
| E4/6 |
Right tai1 lamp |
51L |
| E4/6e1 |
Turn signal lamp |
53L |
| E4/6e2 |
Tail lamp |
51L |
| E4/6e3 |
Backup lamp |
50L |
| E4/6e4 |
Stop lamp |
51L |
| E4/6e5 |
Rear fog lamp |
50L |
| E4/6e6 |
Side-marker lamp |
51L |
| E45/1 |
Left rear fog lamp |
9L |
| E45/2 |
Right rear fog lamp |
11L |
| E4e1 |
Turn signal lamp |
16L |
| E4e2 |
Tail lamp |
17L |
| E4e3 |
Backup lamp |
18L |
| E4e4 |
Stop lamp |
17L |
| E4e5 |
Rear fog lamp |
16L |
| F55/3 |
Fuse block (9 fuses) |
43L |
| F55/3f2 |
Fuse 2 (30 A), rear wiper |
43K |
| M14/7 |
Rear-end door ZV actuator |
26L |
| M21/8 |
Left vent window motor |
28L |
| M21/9 |
Right vent window motor |
29L |
| M6/10 |
Left rear-end door wiper motor |
38L |
| M6/11 |
Right rear-end door wiper motor |
41L |
| N10 |
SAM control unit |
4A |
| N10 |
SAM control unit |
12A |
| N10 |
SAM control unit |
20A |
| N10 |
SAM control unit |
28A |
| N10 |
SAM control unit |
36A |
| N10 |
SAM control unit |
45A |
| N10 |
SAM control unit |
52A |
| N10 |
SAM control unit |
61A |
| N10 |
SAM control unit |
68A |
| U1 |
Valid for left-hand drive vehicles |
10F |
| U1 |
Valid for left-hand drive vehicles |
11C |
| U2 |
Valid for right-hand drive vehicles |
8F |
| U2 |
Valid for right-hand drive vehicles |
8C |
| U29 |
Valid for short cab version |
44A |
| U3 |
Valid for vehicles with all-wheel drive |
8G |
| U3 |
Valid for vehicles with all-wheel drive |
10G |
| U30 |
Valid for long cab version |
44A |
| U32 |
Val id for MPV version |
1A |
| U4 |
Valid for vehicles without all-wheel drive |
8C |
| U4 |
Valid for vehicles without all-wheel drive |
11C |
| U58 |
Valid for vehicles with 2-wing rear-end door (270 degrees) |
30D |
| U70 |
Valid for USA, Canada |
65A |
| U72 |
Valid for all except USA, Canada |
8G |
| U72 |
Valid for all except USA, Canada |
10G |
| U72 |
Valid for all except USA, Canada |
4E |
| U72 |
Valid for all except USA, Canada |
8D |
| U72 |
Valid for all except USA, Canada |
14E |
| U72 |
Valid for all except USA, Canada |
56D |
| W29/8 |
Left D-pillar ground point |
3H |
| W29/8 |
Left D-pillar ground point |
18H |
| W29/8 |
Left D-pillar ground point |
36C |
| W29/8 |
Left D-pillar ground point |
39E |
| W52/7 |
Left rear crossmember ground point |
9G |
| W52/7 |
Left rear crossmember ground point |
12G |
| W52/7 |
Left rear crossmember ground point |
49H |
| W71/2 |
Driver seat frame ground point 2 |
60G |
| W71/2 |
Driver seat frame ground point 2 |
64G |
| W71/3 |
Driver seat frame ground point 3 |
60H |
| W71/3 |
Driver seat frame ground point 3 |
64H |
| X145/8 |
Body manufacturer illumination connector |
66L |
| X176/1 |
Low frame connector 1 |
58L |
| X176/2 |
Low frame connector 2 |
63L |
| X18/52 |
HLS/roof connector |
10E |
| X18/52 |
HLS/roof connector |
22E |
| X18/53 |
HLS/roof connector 2 |
42H |
| X18/54 |
HLS/roof connector 3 |
9E |
| X49/11 |
Left rear fog lamp connector |
9H |
| X49/12 |
Right rear fog lamp connector |
11H |
| X8/20 |
Right roof/rear-end door connector |
25E |
| X8/21 |
Right roof/rear-end door connector |
40H |
| X8/22 |
Left roof/rear-end door connector |
35E |
| X8/23 |
Left roof/rear-end door connector |
38H |
| X8/47 |
License plate lamp connector |
31E |
| Z21/16 |
CL [ZV] control circuit 1 connector sleeve |
23G |
| Z21/17 |
CL [ZV] control circuit 1 connector sleeve |
24G |
| Z3/59 |
Rear-end door wiper motor tml. 15 connector sleeve |
41E |
| Z30/11 |
Left turn signal indicator connector sleeve |
5G |
| Z30/12 |
Right turn signal indicator connector sleeve |
15G |
| Z30/13 |
Left turn signal indicator connector sleeve |
47G |
| Z30/14 |
Right turn signal indicator connector sleeve |
53G |
| Z38 |
Backup lamp connector sleeve |
2G |
| Z38 |
Backup lamp connector sleeve |
18G |
| Z38/2 |
Backup lamp connector sleeve |
48G |
| Z38/2 |
Backup lamp connector sleeve |
61G |
| Z6/129 |
License plate lamp ground connector sleeve |
32G |
| Z81/16 |
Tml. 58 connector sleeve |
31G |
| Z82/17 |
Rear-end door ZV connector sleeve |
26G |
