| AO |
Color code key |
32L |
| Code ED8 |
Electrical system preinstallation, parameterizable special module |
11D |
| Code M53 |
Constant rpm control |
13A |
| Code MT4 |
Variable electronic rpm regulator |
13A |
| F55/3 |
Fuse block 3 (9-pin) |
29L |
| F55/3f4 |
AAG/tachograph/ADR fuse 4 |
27K |
| F55/4 |
Fuse block 4 (9-pin) |
4L |
| F55/4f8 |
Parameterizable special module (PSM) fuse 17 |
2K |
| F55/4f9 |
Parameterizable special module (PSM) fuse 18 |
3K |
| N10 |
SAM control unit |
25L |
| N26/15 |
Parameterizable special module (PSM) control unit |
4A |
| N26/15 |
Parameterizable special module (PSM) control unit |
12A |
| N26/15 |
Parameterizable special module (PSM) control unit |
20A |
| S161/1 |
Working speed control ON switch |
21L |
| S162 |
Working speed control button |
15L |
| U200 |
Valid without code N05 (Countershaft power take-off (2c) without flange) |
13B |
| U201 |
Valid without code N07 (Countershaft power take-off (2b) with flange) |
13B |
| W1/3 |
CLS cockpit ground point 1 |
16G |
| W1/3 |
CLS cockpit ground point 1 |
22G |
| W71/1 |
Driver seat frame ground point 1 |
6E |
| X18/55 |
MWH [HLS]/cockpit electrical connector 3 |
18E |
| X18/56 |
MWH [HLS]/cockpit electrical connector |
27H |
| X30/24 |
Interior CAN electrical connector |
8L |
| X30/39 |
CAN-B preinstallation/parameterizable special module (PSM) control unit electrical connector |
12L |
| Z3/63 |
Working speed control (ADR) circuit 15 connector sleeve |
20G |
| Z81/5 |
Circuit 58d connector sleeve |
22F |
