| AO |
Color code key |
72L |
| B38/2 |
Rain/light sensor |
64L |
| B44 |
Front interior protection sensor |
60L |
| B44/1 |
Center interior protection sensor |
57L |
| B44/2 |
Rear interior protection sensor |
54L |
| B84/11 |
ERA-Glonass control unit |
35L |
| B84/11x1 |
ERA-Glonass control unit electrical connector |
34K |
| Code ECO |
eCall Russia (ERA-GLONASS) incl. camera |
29D |
| Code FF8 |
1-DIN slot at front under head liner |
6C |
| Code FY1 |
Theft protection package |
37C |
| Code FY1 |
Theft protection package |
51C |
| Code FY1 |
Theft protection package |
43C |
| Code FY1 |
Theft protection package |
29D |
| Code FY1 |
Theft protection package |
25D |
| Code FZ4 |
Anti-theft alarm system with interior protection and tow-away protection |
51D |
| Code FZ4 |
Anti-theft alarm system with interior protection and tow-away protection |
43D |
| Code FZ4 |
Anti-theft alarm system with interior protection and tow-away protection |
29D |
| Code FZ4 |
Anti-theft alarm system with interior protection and tow-away protection |
25D |
| Code FZ5 |
Anti-theft alarm system |
43D |
| Code FZ5 |
Anti-theft alarm system |
29D |
| Code FZ5 |
Anti-theft alarm system |
25D |
| Code JA5 |
Light/rain sensor |
62C |
| Code JA5 |
Light/rain sensor |
29E |
| Code JA5 |
Light/rain sensor |
25D |
| Code LDO |
Overhead control panel with two reading lamps |
21D |
| F55/1 |
Fuse block (1, 9-pin) |
41L |
| F55/1f8 |
ATA rotating beacon/tone sequence fuse 8 |
40K |
| F55/2 |
Fuse block 2 (9-pin) |
13L |
| F55/2f4 |
Air heater timer/FleetBoard fuse 13 |
11K |
| F55/3 |
Fuse block 3 (9-pin) |
9L |
| F55/3f3 |
Start-off assist, heater timer, reversing camera, telephone fuse 3 |
7K |
| F55/5 |
Fuse block 5 (9-pin) |
4L |
| F55/5f1 |
Overhead control panel (OCP [DBE]) fuse 19 |
2K |
| H3/1 |
Battery-operated horn |
38L |
| N10 |
SAM control unit |
23L |
| N10 |
SAM control unit |
49L |
| N10 |
SAM control unit |
19L |
| N10 |
SAM control unit |
31L |
| N10 |
SAM control unit |
27L |
| N70 |
Overhead control panel (OCP [DBE]) control unit |
4A |
| N70 |
Overhead control panel (OCP [DBE]) control unit |
12A |
| N70 |
Overhead control panel (OCP [DBE]) control unit |
20A |
| N70 |
Overhead control panel (OCP [DBE]) control unit |
28A |
| N70 |
Overhead control panel (OCP [DBE]) control unit |
36A |
| N70 |
Overhead control panel (OCP [DBE]) control unit |
44A |
| N70 |
Overhead control panel (OCP [DBE]) control unit |
52A |
| N70 |
Overhead control panel (OCP [DBE]) control unit |
60A |
| S62/41 |
Engine hood switch |
46L |
| U188 |
Valid without code ECO (eCall Russia (ERA-Glonass) incl. camera) |
25C |
| U97 |
Valid for vehicles without anti-theft alarm system |
45C |
| W38 |
Roof ground point |
55H |
| W38 |
Roof ground point |
59E |
| W38 |
Roof ground point |
4F |
| W38 |
Roof ground point |
15H |
| W9/7 |
Left front ground point 2 |
38H |
| W9/7 |
Left front ground point 2 |
47L |
| X178 |
Front roof electrical connector |
15L |
| X18/53 |
MWH [HLS]/roof electrical connector 2 |
2E |
| X18/54 |
MWH [HLS]/roof electrical connector 3 |
38E |
| X18/54 |
MWH [HLS]/roof electrical connector 3 |
7E |
| X18/75 |
Cockpit and roof electrical connector 5 |
11H |
| X42/28 |
Anti-theft alarm system (ATA [EDW]) electrical connector |
58H |
| Z24/5 |
Anti-theft alarm system (ATA [EDW]) interior sensor connector sleeve |
53E |
| Z3/69 |
Tml. 15 connector sleeve |
7G |
| Z37/79 |
ERA-Glonass CAN bus (low) connector sleeve |
31F |
| Z37/80 |
ERA-Glonass CAN bus (high) connector sleeve |
30F |
| Z7/62 |
Anti-theft alarm system (ATA [EDW]) circuit 30 connector sleeve |
54E |
| Z81/15 |
Circuit 58d connector sleeve |
18E |
