| A0 |
Color code key |
39L |
| A102 |
AdBlue® tank module |
21L |
| A9/10 |
Refrigerant compressor with magnetic clutch |
33L |
| B162 |
COLLISION PREVENTION ASSIST control unit |
8A |
| Code CV1 |
Winter service vehicle preinstallation |
1G |
| Code JA6 |
COLLISION PREVENTION ASSIST |
6A |
| Code L44 |
|
11H |
| Code LG0 |
Bi-xenon headlamps |
6H |
| Code LG1 |
Bi-xenon headlamps with cornering lights |
6H |
| Code MA4 |
Low-emission vehicle Euro 5b+ Gr. III |
9B |
| Code MA4 |
Low-emission vehicle Euro 5b+ Gr. III |
19A |
| Code MA6 |
Low-emission vehicle, Euro 6 Gr. III |
9C |
| Code MA6 |
Low-emission vehicle, Euro 6 Gr. III |
19B |
| Code MB6 |
Low-emission vehicle, Euro 6 Gr. 1 |
9D |
| Code MB6 |
Low-emission vehicle, Euro 6 Gr. 1 |
19B |
| Code MH5 |
Low-emission engine EPA 14/CARB |
14B |
| Code MP6 |
Euro VI engine version |
9C |
| Code MP6 |
Euro VI engine version |
19B |
| Code ZU7 |
Canada national version |
14B |
| Code ZU8 |
USA national version |
14B |
| E2/7 |
Right lamp unit |
5L |
| E2/8 |
Right XENON lamp unit |
8L |
| E22/2 |
Right additional turn signal lamp |
12L |
| E5/2 |
Right fog lamp |
10L |
| K9 |
Additional fan relay |
30L |
| K9/2 |
Additional fan relay (mono) |
26L |
| M4/13 |
Air conditioning additional fan 1 |
25L |
| M4/13 |
Air conditioning additional fan 1 |
31L |
| M89/2 |
Front AdBlue® delivery pump |
19L |
| M91 |
Electric fan |
21A |
| N3/28 |
CDI control unit |
12A |
| N3/33 |
CDI control unit |
17A |
| R15 |
Air conditioning mono fan resistor |
28L |
| R51/2 |
Front AdBlue® tank fill heating element |
17L |
| R52 |
AdBlue® injection line heating element |
16L |
| R52/4 |
AdBlue® injection line heating element |
23L |
| U67 |
Val id for AC mono fan |
24F |
| U68 |
Val id for AC duo fan |
29F |
| U74 |
Valid for front AdBlue® tank |
14F |
| W2 |
Right front lamp unit ground point |
14F |
| X24/14 |
Right additional headlamp electrical connector |
2L |
| X26/65 |
Engine wiring harness electrical connector 4 |
33E |
| X64/13 |
Double auxiliary fan electrical connector |
28E |
| Y74/5 |
Pressure regulator valve |
35L |
| Z234/14 |
Capillary stopper connector sleeve |
22G |
| Z234/6 |
Capillary stopper connector sleeve |
20G |
| Z5/5 |
A/C fan circuit 31 connector sleeve |
26G |
| Z5/5 |
A/C fan circuit 31 connector sleeve |
29G |
| Z6/113 |
Ground connection connector sleeve |
33G |
