| A0 |
Color code key |
144L |
| A1 |
Instrument cluster |
51A |
| A1 |
Instrument cluster |
138A |
| A56 |
Tachograph |
11A |
| A56 |
Tachograph |
56A |
| A96 |
Backup camera monitor |
83L |
| B84/3 |
Backup camera |
96L |
| B84/3 |
Backup camera |
90L |
| Code CV1 |
Winter service vehicle preinstallation |
19H |
| Code CV1 |
Winter service vehicle preinstallation |
67A |
| Code ED5 |
Parameterizable special module |
58A |
| Code ED5 |
Parameterizable special module |
63A |
| Code ED5 |
Parameterizable special module |
67A |
| Code EN7 |
Audio 15 |
73H |
| Code ER0 |
Radio preinstallation |
39A |
| Code ER0 |
Radio preinstallation |
141F |
| Code EV3 |
|
38G |
| Code F66 |
|
43H |
| Code FF8 |
1-DIN slot at front under head liner |
92E |
| Code FR7 |
Backup Assist electrical system preinstallation |
77E |
| Code FR7 |
Backup Assist electrical system preinstallation |
85E |
| Code FR7 |
Backup Assist electrical system preinstallation |
136E |
| Code FR8 |
Backup camera |
73G |
| Code FR8 |
Backup camera |
94E |
| Code FR8 |
Backup camera |
81E |
| Code FR8 |
Backup camera |
88E |
| Code FR8 |
Backup camera |
136F |
| Code FY9 |
|
34G |
| Code G40 |
Automatic transmission |
4A |
| Code G42 |
7G-TR0NIC PLUS |
4A |
| Code H11 |
Warm air auxiliary heater |
106E |
| Code H12 |
Auxiliary water heater |
17G |
| Code H72 |
Electric roof ventilator |
29G |
| Code HZ9 |
Heater booster |
14G |
| Code J19 |
Automatic tachograph, 1 day/2 driver (EC) |
9A |
| Code J19 |
Automatic tachograph, 1 day/2 driver (EC) |
53A |
| Code JA6 |
COLLISION PREVENTION ASSIST |
116A |
| Code JA7 |
Blind spot assist |
116A |
| Code JD2 |
EC digital tachograph with rpm+additional recorder |
9A |
| Code JD2 |
EC digital tachograph with rpm+additional recorder |
53A |
| Code JD4 |
EU digital tachograph, download-capable |
9B |
| Code JD4 |
EU digital tachograph, download-capable |
53B |
| Code JV6 |
Tachograph preinstallation |
9B |
| Code JV6 |
Tachograph preinstallation |
53B |
| Code JW3 |
Shutoff for backup warning system |
36G |
| Code JW5 |
Lane Keeping Assist |
116B |
| Code L72 |
|
23G |
| Code LA1 |
High Beam Assist |
116B |
| Code LB7 |
|
19G |
| Code LB8 |
|
19G |
| Code LD4 |
Load/passenger compartment comfort illumination |
12G |
| Code LG1 |
Bi-xenon headlamps with cornering lights |
122A |
| Code LV1 |
|
21G |
| Code M53 |
Constant rpm control |
25G |
| Code M53 |
Constant rpm control |
71G |
| Code M53 |
Constant rpm control |
58B |
| Code M53 |
Constant rpm control |
63B |
| Code MT4 |
Variable electronic rpm regulator |
25G |
| Code MT4 |
Variable electronic rpm regulator |
27G |
| Code MT4 |
Variable electronic rpm regulator |
71H |
| Code MT4 |
Variable electronic rpm regulator |
58B |
| Code MT4 |
Variable electronic rpm regulator |
63B |
| Code MW1 |
Engine run-on control (MWS) |
10G |
| Code MW1 |
Engine run-on control (MWS) |
58A |
| Code MZ2 |
Natural gas engine M271 |
8G |
| Code N05 |
Countershaft power take-off (2c) without flange |
68G |
| Code N05 |
Countershaft power take-off (2c) without flange |
58B |
| Code N07 |
Countershaft power take-off (2b) with flange |
68H |
| Code N07 |
Countershaft power take-off (2b) with flange |
58B |
| Code P57 |
|
32G |
| Code V85 |
Smoker"s package |
40G |
| Code YM1 |
FleetBoard vehicle computer |
46H |
| Code YM1 |
FleetBoard vehicle computer |
94E |
| Code YM1 |
FleetBoard vehicle computer |
102E |
| Code YM1 |
FleetBoard vehicle computer |
58C |
| Code ZG1 |
All-wheel drive, engageable |
4G |
| Code ZG3 |
Engageable all-wheel drive with gear reduction |
4G |
| Code ZG3 |
Engageable all-wheel drive with gear reduction |
6G |
| Code ZJ8 |
Mercedes-Benz Minibus (MBM) scope of supply |
139E |
| Code ZU7 |
Canada national version |
44A |
| Code ZU7 |
Canada national version |
119F |
| Code ZU7 |
Canada national version |
63A |
| Code ZU8 |
USA national version |
44A |
| Code ZU8 |
USA national version |
119G |
| Code ZU8 |
USA national version |
63B |
| E1/7 |
Left lamp unit |
128L |
| E1/7m1 |
Headlamp range adjustment motor |
128L |
| E1/8 |
Left XENON lamp unit |
130L |
| E1/8m1 |
Headlamp range adjustment motor |
130L |
| E13/1 |
Glove box lamp |
44L |
| E2/7 |
Right lamp unit |
124L |
| E2/7m1 |
Headlamp range adjustment motor |
124L |
| E2/8 |
Right XENON lamp unit |
126L |
| E2/8m1 |
Headlamp range adjustment motor |
126L |
| F55/3 |
Fuse block 3 (9-pin) |
75A |
| F55/3 |
Fuse block 3 (9-pin) |
111A |
| F55/3f3 |
Start-off assist, heater timer, reversing camera, telephone fuse 3 |
75B |
| F55/3f4 |
AAG/tachograph/ADR fuse 4 |
73B |
| F55/7 |
Fuse block 7 (9-pin) |
118A |
| K40/9 |
Fuse and relay module |
47A |
| K40/9 |
Fuse and relay module |
121L |
| K41 |
Circuit 15 relief relay |
111L |
| N10 |
SAM control unit |
18A |
| N149 |
FleetBoard control unit |
104L |
| N149 |
FleetBoard control unit |
99L |
| N15/5 |
Electronic selector lever module control unit |
7A |
| N26/15 |
Parameterizable special module (PSM) control unit |
60A |
| N26/15 |
Parameterizable special module (PSM) control unit |
65A |
| N26/15 |
Parameterizable special module (PSM) control unit |
70A |
| N34 |
Heater timer |
108L |
| N71 |
Headlamp range adjustment (HRA [LWR]) control unit |
125A |
| R3 |
Illuminated cigar lighter |
42L |
| S1 |
Light switch |
49L |
| S1/1 |
Headlamp range controller |
133L |
| S157/1 |
Rotating beacon switch |
20L |
| S157/3 |
Rotating beacon with tone sequence switch |
22L |
| S160 |
Body manufacturer electrical system switch |
24L |
| S161 |
Power take-off switch |
70L |
| S161/1 |
Working speed control ON switch |
26L |
| S161/1 |
Working speed control ON switch |
72L |
| S162 |
Working speed control button |
28L |
| S163 |
Roof ventilator switch |
31L |
| S164 |
Transmission neutral position switch |
75L |
| S165 |
Dumper vehicle switch |
33L |
| S167 |
Cargo lift gate switch |
39L |
| S18/1 |
Rear dome lamp switch |
13L |
| S193 |
Gas/gasoline selection switch |
9L |
| S194 |
KEYLESS-ENTRY & SLIDE button |
35L |
| S198 |
Engine run-on button |
11L |
| S199 |
Backup warning system OFF button |
37L |
| S21/2 |
Passenger-side power window switch |
3L |
| S46/10 |
Heater booster button |
15L |
| S46/11 |
Heater booster/stationary heater button |
18L |
| S76/11 |
All-wheel drive engagement button |
5L |
| S76/12 |
All-wheel drive gear ratio button |
7L |
| S98 |
AC control and operating unit |
22A |
| U153 |
Valid without code FR7 (Backup assist electrical system preinstallation) |
141E |
| U153 |
Valid without code FR7 (Backup assist electrical system preinstallation) |
139F |
| U154 |
Valid without code FR8 (Reversing camera) |
141F |
| U154 |
Valid without code FR8 (Reversing camera) |
139F |
| U162 |
Valid without code EN7 (Audio 15) |
77E |
| U162 |
Valid without code EN7 (Audio 15) |
81E |
| U162 |
Valid without code EN7 (Audio 15) |
88E |
| U162 |
Valid without code EN7 (Audio 15) |
85E |
| U166 |
Valid without code ERO (Radio preinstallation) |
139F |
| U166 |
Valid without code ERO (Radio preinstallation) |
136F |
| U213 |
|
2G |
| U72 |
Valid for all except USA, Canada |
44B |
| U72 |
Valid for all except USA, Canada |
119G |
| W1/3 |
CLS cockpit ground point 1 |
134H |
| W9/6 |
Left front lamp unit ground point |
125L |
| XI45/11 |
Minibus body manufacturer electrical connector |
140L |
| X162 |
Transmission neutral position electrical connector |
75H |
| X169 |
Backup camera electrical connector |
95H |
| X169 |
Backup camera electrical connector |
86L |
| X169 |
Backup camera electrical connector |
89H |
| X169/3 |
Body manufacturer reversing camera electrical connector 1 |
74L |
| X170 |
Reversing camera monitor electrical connector |
79L |
| X170 |
Reversing camera monitor electrical connector |
82H |
| X170 |
Reversing camera monitor electrical connector |
138L |
| X178 |
Front roof electrical connector |
93L |
| X18/54 |
MWH [HLS]/roof electrical connector 3 |
97D |
| X18/55 |
MWH [HLS]/cockpit electrical connector 3 |
64F |
| X18/55 |
MWH [HLS]/cockpit electrical connector 3 |
80D |
| X18/56 |
MWH [HLS]/cockpit electrical connector |
2E |
| X18/56 |
MWH [HLS]/cockpit electrical connector |
132H |
| X18/56 |
MWH [HLS]/cockpit electrical connector |
72E |
| X18/56 |
MWH [HLS]/cockpit electrical connector |
139G |
| X18/67 |
MWH [HLS]/roof electrical connector 4 |
107E |
| X198/1 |
Fleetboard electrical connector |
47L |
| X35/2 |
Front passenger door electrical connector |
2H |
| X39/67 |
Radio preinstallation electrical connector |
42A |
| X39/67 |
Radio preinstallation electrical connector |
142L |
| Z3/11 |
Circuit 15 (fused) connector sleeve |
48F |
| Z3/54 |
Circuit 15R connector sleeve |
46G |
| Z3/55 |
Tml. 15 connector sleeve |
110E |
| Z3/56 |
Headlamp range adjustment (HRA [LWR]) circuit 15 connector sleeve |
123E |
| Z3/63 |
Working speed control (ADR) circuit 15 connector sleeve |
69G |
| Z3/69 |
Tml. 15 connector sleeve |
75E |
| Z3/72 |
Tml. 15 connector sleeve |
107G |
| Z3/72 |
Tml. 15 connector sleeve |
95F |
| Z36/12 |
Headlamp range adjustment (HRA [LWR]) control bus connector sleeve |
126F |
| Z6/103 |
Headlamp range adjustment (HRA [LWR]) ground connection connector sleeve |
125G |
| Z61 |
Vehicle speed signal connector sleeve |
138D |
| Z81/5 |
Circuit 58d connector sleeve |
18F |
