| C4/1 |
Right interference suppression capacitor |
2L |
| C4/1 |
Right interference suppression capacitor |
30L |
| F55/1 |
Fuse block (9 fuses) |
5A |
| F55/1 |
Fuse block (9 fuses) |
33A |
| F55/1f5 |
Fuse 5 (7.5/10 A) motors circuit 87 (5) |
3B |
| F55/1f5 |
Fuse 5 (7.5/10 A) motors circuit 87 (5) |
31B |
| K40/9 |
Fuse/relay box (SRB) |
23L |
| K40/9 |
Fuse/relay box (SRB) |
41L |
| K41 |
Tml. 15 relief relay |
25L |
| K41 |
Tml. 15 relief relay |
43L |
| K88 |
Body manufacturer tml. 15 relay |
28L |
| K88 |
Body manufacturer tml. 15 relay |
45L |
| N118/5 |
Fuel pump control unit |
26A |
| N118/5 |
Fuel pump control unit |
44A |
| N3/20 |
CDI control unit |
8l |
| N3/20 |
CDI control unit |
38A |
| N3/21 |
CDI control unit |
8L |
| N3/27 |
CDI control unit |
12L |
| N3/28 |
CDI control unit |
12L |
| N3/29 |
ME-SFI [ME] control unit |
16L |
| N3/30 |
CDI control unit |
19L |
| N3/30 |
CDI control unit |
34L |
| N83/1 |
DC/DC converter control unit |
22A |
| S164 |
Transmission neutral position switch |
13A |
| S2/6 |
Engine start/stop switch |
15A |
| S9/1 |
Stop lamp switch |
24A |
| S9/1 |
Stop lamp switch |
41A |
| U10 |
Valid for engine start/stop (MSS) |
14A |
| U10 |
Valid for engine start/stop (MSS) |
21A |
| U28 |
Val id for engine 272 |
1H |
| U28 |
Val id for engine 272 |
29H |
| U70 |
Val id for USA, Canada |
29A |
| U72 |
Valid for all except USA. Canada |
1A |
| U8 |
Val id for engine 646 |
4H |
| X162 |
Transmission neutral position connector |
12E |
| X18/56 |
HLS/COC connector |
15E |
| X26/38 |
Engine wiring harness connector |
9E |
| X26/38 |
Engine wiring harness connector |
35E |
| X26/44 |
Engine wiring harness connector |
3E |
| X26/44 |
Engine wiring harness connector |
31E |
| X26/47 |
Engine wiring harness connector |
11E |
| Y31/14 |
Boost pressure control pressure transducer |
5L |
| Y77 |
Waste gate pressure transducer |
6L |
| Z3/65 |
Tml. 15 connector sleeve |
24E |
| Z3/65 |
Tml. 15 connector sleeve |
41G |
| Z7/112 |
Ignition coil tml. 87 connector sleeve |
IIB |
| Z7/48 |
Tml. 87 connector sleeve |
9B |
| Z7/48 |
Tml. 87 connector sleeve |
35B |
| Z7/77 |
Tml. 87 connector sleeve |
8G |
| Z7/77 |
Tml. 87 connector sleeve |
34G |
| Z7/93 |
Tml. 87 connector sleeve |
IE |
| Z7/93 |
Tml. 87 connector sleeve |
29E |
| Z7/95 |
Tml. 87 connector sleeve |
3L |
| Z7/95 |
Tml. 87 connector sleeve |
31L |
