| A46 |
Tone signal generator |
34A |
| E3/6 |
Left tail lamp |
29L |
| E4/6 |
Right tail lamp |
30L |
| F55/1 |
Fuse block (9 fuses) |
9L |
| F55/2 |
Fuse block (9 fuses) |
2A |
| F55/4 |
Fuse block (9 fuses) |
11L |
| F55/5 |
Fuse block (9 fuses) |
20A |
| F55/6 |
Fuse block (9 fuses) |
23L |
| F59 |
Fuse box |
4A |
| F59 |
Fuse box |
12A |
| F59 |
Fuse box |
18A |
| F59. 5 |
Tml. 30 SAM/SRB fuse (150 A) |
4B |
| F59. 6 |
Tml. 30 current bridge |
17B |
| F68 |
Windshield heater fuse (80A) |
13L |
| F69 |
Air conditioning fuse (50A) |
15L |
| H1 |
Signaling horn |
39L |
| H3/4 |
Backup warning horn |
26L |
| K110 |
AdBlue®, relay |
20L |
| K121 |
Backup warning OFF relay |
32L |
| K39/3 |
EDW horn relay |
37L |
| K40/9 |
Fuse/relay box (SRB) |
5L |
| K40.-9 |
Fuse/relay box (SRB) |
37A |
| K41 |
Tml. 15 relief relay |
18L |
| K41/2 |
Tml. 15R relief relay |
16L |
| N10 |
SAM control unit |
28A |
| S199 |
Backup warning OFF button |
32A |
| U29 |
Valid for short cab version |
26A |
| U30 |
Valid for long cab version |
26A |
| U70 |
Val id for USA, Canada |
19G |
| U72 |
Valid for all except USA, Canada |
33A |
| U77 |
Valid for backup warning system |
31B |
| V22/1 |
Tone sequence/horn decoupling diode |
36L |
| V22/2 |
Horn/tone sequence decoupling diode |
34L |
| X169/3 |
Body manufacturer backup camera connector 1 |
28L |
| X18/55 |
HLS/COC connector 3 |
32E |
| X4/49 |
Tml. 30 connector |
1H |
| Z219 |
Signaling horn actuation connector sleeve |
36E |
| Z38/2 |
Backup lamp connector sleeve |
27G |
| Z7/102 |
Tml. 30 connector sleeve |
1E |
| Z7/74 |
Tml. 30 connector sleeve |
4E |
| Z7/75 |
Tml. 30 connector sleeve |
17E |
