| A1 |
Instrument cluster |
16A |
| A96 |
Backup camera monitor |
36L |
| E13/1 |
Glove compartment lamp |
22L |
| F55/3 |
Fuse block (9 fuses) |
27L |
| F55/3 |
Fuse block (9 fuses) |
30A |
| F55/3f3 |
Fuse 3 (5 A), start-off assist, heater timer, backup camera, telephone |
30B |
| F55/3f4 |
Fuse 4 (7.5 A), A AG, tachograph, ADR |
27K |
| K40/9 |
Fuse/relay box (SRB) |
19A |
| N10 |
SAM control unit |
7A |
| N15/5 |
EWM control unit |
3A |
| N26/15 |
PSM control unit |
25A |
| R3 |
Illuminated cigar lighter |
14L |
| R3 |
Illuminated cigar lighter |
21L |
| S1 |
Rotary light switch |
18L |
| S160 |
Body manufacturer electrical system switch |
8L |
| S161/1 |
ADR ON switch |
9L |
| S161/1 |
ADR ON switch |
25L |
| S162 |
ADR button |
10L |
| S163 |
Roof ventilator switch |
11L |
| S164 |
Transmission neutral position switch |
29L |
| S167 |
Cargo lift gate switch |
13L |
| S167 |
Cargo lift gate switch |
24L |
| S18/1 |
Rear dome lamp switch |
5L |
| S193 |
Gas/gasoline selection switch |
12A |
| S21/2 |
Front passenger power window switch |
2L |
| S46/10 |
Heater booster button |
6L |
| S46/11 |
Heater booster/stationary heater button |
7L |
| S98 |
AAC [KLA] control and operating unit |
10A |
| X162 |
Transmission neutral position connector |
28H |
| X169/3 |
Body manufacturer backup camera connector 1 |
30L |
| X169/7 |
Backup camera connector |
36E |
| X170 |
Backup camera monitor connector |
36H |
| X178 |
Front roof connector |
34L |
| X18/52 |
HLS/roof connector |
33E |
| X18/54 |
HLS/roof connector 3 |
34E |
| X18/55 |
HLS/COC connector 3 |
25E |
| X18/56 |
HLS/COC connector |
2E |
| X18/56 |
HLS/COC connector |
27H |
| X198/1 |
Fleetboard connector |
23A |
| X35/2 |
Front passenger door connector |
1H |
| X35/2 |
Front passenger door connector |
3H |
| X39/67 |
Radio preinstallation connector |
14A |
| X39/67 |
Radio preinstallation connector |
22A |
| Z3/11 |
Tml. 15 (fused) connector sleeve |
18E |
| Z3/54 |
Tml. 15R connector sleeve |
20E |
| Z3/63 |
ADR tml. 15 connector sleeve |
25G |
| Z3/69 |
Tml. 15 connector sleeve |
30E |
| Z81/5 |
Tml. 58d connector sleeve |
7E |
