| A1 |
Instrument cluster |
27A |
| A56 |
Tachograph |
IIA |
| A56 |
Tachograph |
35A |
| A96 |
Backup camera monitor |
44L |
| B84/3 |
Backup camera |
49L |
| E13/1 |
Glove compartment lamp |
33L |
| F55/3 |
Fuse block (9 fuses) |
41L |
| F55/3 |
Fuse block (9 fuses) |
44A |
| F55/3f3 |
Fuse 3 (5 A), start-off assist, heater timer, backup camera, telephone |
44B |
| F55/3f4 |
Fuse 4 (7.5 A), AAG, tachograph, ADR |
41K |
| K40/9 |
Fuse/relay box (SRB) |
30A |
| N10 |
SAM control unit |
14A |
| N149 |
FleetBoard control unit |
46L |
| N15/5 |
EWM control unit |
7A |
| N34 |
Heater timer |
52L |
| N97 |
Electronic level control [ENR] control unit |
24A |
| R3 |
Illuminated cigar lighter |
26L |
| R3 |
Illuminated cigar lighter |
32L |
| S1 |
Rotary light switch |
30L |
| S157/1 |
Rotating beacon switch |
12L |
| S157/3 |
Rotating beacon with tone sequence switch |
13L |
| S160 |
Body manufacturer electrical system switch |
14L |
| S161 |
PTO switch |
16L |
| S161 |
PTO switch |
38L |
| S161/1 |
ADR ON switch |
17L |
| S161/1 |
ADR ON switch |
39L |
| S161/2 |
Power take-off limit switch |
39A |
| S162 |
ADR button |
18L |
| S163 |
Roof ventilator switch |
19L |
| S164 |
Transmission neutral position switch |
42L |
| S165 |
Three-way dump truck switch |
20L |
| S167 |
Cargo lift gate switch |
21L |
| S167 |
Cargo lift gate switch |
35L |
| S18/1 |
Rear dome lamp switch |
7L |
| S193 |
Gas/gasoline selection switch |
20A |
| S194 |
Keyless Entry button |
22L |
| S198 |
Engine run-on button |
23L |
| S199 |
Backup warning OFF button |
24L |
| S2/6 |
Engine start/stop switch |
6L |
| S21/2 |
Front passenger power window switch |
2L |
| S46/10 |
Heater booster button |
8L |
| S46/11 |
Heater booster/stationary heater button |
9L |
| S76/11 |
All-wheel drive engagement button |
10L |
| S76/12 |
All-wheel drive reduction button |
11L |
| S77/1 |
ELC lock button |
27L |
| S77/2 |
ELC raise/lower button |
28L |
| S98 |
AAC [KLA] control and operating unit |
18A |
| U76 |
Val id for FleetBoard |
45F |
| X162 |
Transmission neutral position connector |
42G |
| X169 |
Backup camera connector |
48J |
| X170 |
Backup camera monitor connector |
43J |
| X178 |
Front roof connector |
50L |
| X18/52 |
HLS/roof connector |
48E |
| X18/54 |
HLS/roof connector 3 |
46H |
| X18/54 |
HLS/roof connector 3 |
50E |
| X18/55 |
HLS/COC connector 3 |
43G |
| X18/55 |
HLS/COC connector 3 |
38E |
| X18/56 |
HLS/COC connector |
2E |
| X18/56 |
HLS/COC connector |
40G |
| X18/67 |
HLS/roof connector 4 |
51E |
| X198/1 |
Fleetboard connector |
36L |
| X35/2 |
Front passenger door connector |
2H |
| X35/2 |
Front passenger door connector |
3H |
| X39/67 |
Radio preinstallation connector |
21A |
| X39/67 |
Radio preinstallation connector |
33A |
| Z3/11 |
Tml. 15 (fused) connector sleeve |
29E |
| Z3/54 |
Tml. 15R connector sleeve |
31E |
| Z3/63 |
ADR tml. 15 connector sleeve |
38G |
| Z3/69 |
Tml. 15 connector sleeve |
44E |
| Z3/72 |
Tml. 15 connector sleeve |
51H |
| Z81/5 |
Tml. 58d connector sleeve |
15E |
